2016 Ram ProMaster City automatic transmission fluid

NOTE:The torque converter clutch will not engage until
the transmission fluid is warm [usually after 1 to 3 miles
(2 to 5 km) of driving]. Because the engine speed is higher
when the torque converter clutch is not engaged, it may
seem as if the transmission is not shifting properly when
cold. This is normal. The torque converter clutch will
function normally once the transmission is sufficiently
warm.
Electronic Range Select (ERS) Operation
The Electronic Range Select (ERS) shift control allows the
driver to limit the highest available gear. For example, if
you set the transmission gear limit to 5 (fifth gear), the
transmission will not shift above fifth gear, but will shift
through the lower gears normally.
You can switch between DRIVE and ERS mode at any
vehicle speed. When the shift lever is in the DRIVE
position, the transmission will operate automatically,
shifting between all available gears. Moving the shift lever to the ERS position (beside
DRIVE) will activate ERS mode, display the current gear
in the instrument cluster, and set that gear as the top
available gear. Once in ERS mode, moving the shift lever
forward (-) or rearward (+) will change the top available
gear and it will be displayed in the instrument cluster.
To exit ERS mode, simply return the shift lever to the
DRIVE position.WARNING!
Do not downshift for additional engine braking on a
slippery surface. The drive wheels could lose their
grip and the vehicle could skid, causing a collision or
personal injury.
NOTE: To select the proper gear position for maximum
deceleration (engine braking), move the shift lever into
the ERS position, then simply press and hold it forward
236 STARTING AND OPERATING

CAUTION!
Do not use chemical flushes in your power steering
system as the chemicals can damage your power
steering components. Such damage is not covered by
the New Vehicle Limited Warranty.
WARNING!
Fluid level should be checked on a level surface and
with the engine off to prevent injury from moving
parts and to ensure accurate fluid level reading. Do
not overfill. Use only manufacturer’s recommended
power steering fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to “Fluids, Lubricants, And Genuine
Parts” in “Maintaining Your Vehicle” for further informa-
tion.
PARKING BRAKE
Before leaving the vehicle, make sure that the parking
brake is fully applied. Also, be certain to leave an
automatic transmission in PARK, or manual transmission
in REVERSE or first gear.
The parking brake lever is located in the center console.
To apply the parking brake, pull the lever up as firmly as
possible. To release the parking brake, pull the lever up
slightly, press the center button, then lower the lever
completely.
5
STARTING AND OPERATING 241

▫Brake System ....................... .372
▫ Power Steering Fluid ...................374
▫ Automatic Transmission ................375
▫ Appearance Care And Protection From
Corrosion .......................... .377
 FUSES ............................. .383
▫ Underhood Fuses ..................... .384
▫ Interior Fuses ....................... .387
▫ Central Unit Fuse Panel .................390
 VEHICLE STORAGE ....................391
 REPLACEMENT BULBS .................392
 BULB REPLACEMENT ..................393
▫ Headlamps ......................... .393▫
Front Turn Signal Lamps ................394
▫ Parking And Daytime Running Lights .......394
▫ Front/Rear Side Marker Lamps ............394
▫ Rear Tail, Stop, Backup And Turn Signal
Lamps ............................ .395
▫ Third Brake Light (Center Mount) ..........395
▫ License Plate Lights ....................396
 FLUID CAPACITIES ....................396
 FLUIDS, LUBRICANTS, AND GENUINE
PARTS ............................. .397
▫ Engine ............................ .397
▫ Chassis ........................... .399
348 MAINTAINING YOUR VEHICLE

Automatic Transmission
Selection Of Lubricant
It is important to use the proper transmission fluid to
ensure optimum transmission performance and life. Use
only the manufacturer’s specified transmission fluid.
Refer to “Fluids, Lubricants, And Genuine Parts” in this
section for fluid specifications. It is important to maintain
the transmission fluid at the correct level using the
recommended fluid.
NOTE:
No chemical flushes should be used in any trans-
mission; only the approved lubricant should be used.
CAUTION!
Using a transmission fluid other than the manufac-
turer ’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder. Refer to “Fluids, Lubricants, And Genuine
Parts” in this section for fluid specifications.
Special Additives
The manufacturer strongly recommends against using
any special additives in the transmission. Automatic
Transmission Fluid (ATF) is an engineered product and
its performance may be impaired by supplemental addi-
tives. Therefore, do not add any fluid additives to the
transmission. Avoid using transmission sealers as they
may adversely affect seals.
7
MAINTAINING YOUR VEHICLE 375

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission Use only MOPAR ZF 8&9 Speed ATF Automatic Transmission Fluid, or equivalent.
Failure to use the correct fluid may affect the function or performance of your
transmission.
Brake Master Cylinder We recommend you use MOPAR DOT 4.
Power Steering Reservoir Use Pentosin CHF 11S power steering fluid meeting FCA Material Standard MS-11655.
7
MAINTAINING YOUR VEHICLE 399

Adding Engine Coolant (Antifreeze)............368
Additives, Fuel .......................... .286
AirBag.................................47 Advance Front Air Bag ....................49
Air Bag Operation .......................50
Air Bag Warning Light ....................58
Driver Knee Air Bag ......................51
Enhanced Accident Response ................57
Event Data Recorder (EDR) .................60
FrontAirBag...........................47
If A Deployment Occurs ...................56
Knee Impact Bolsters .....................51
Maintaining Your Air Bag System ............59
Transporting Pets ........................85
Air Bag Deployment ........................47
Air Bag Light ...................... .58, 88, 154
Air Bag Maintenance .......................59
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . .358
Air Conditioner Maintenance .................360Air Conditioning Refrigerant
..............360, 361
Air Conditioning System ....................360
Air Filter .............................. .358
Air Pressure, Tires ........................ .266
Air Recirculation ......................... .208
Alarm (Security Alarm) ......................16
Alarm System (Security Alarm) ................16
Alterations/Modifications, Vehicle ...............7
Antifreeze (Engine Coolant) ...............367, 396
Disposal ............................. .370
Anti-Lock Brake System (ABS) ................244
Appearance Care ........................ .377
Ashtray ............................... .134
Audio Systems (Radio) .....................201
Auto Down Power Windows ..................27
Automatic Transaxle .....................12, 223
Automatic Transmission ..............226, 228, 376
Adding Fluid ...................... .376, 399
Fluid And Filter Changes ..................376
