2016 Ram 2500 Owner's Manual

1. Position the folded Tonneau Cover on the truck bedand push the Cover forward against the front of the
truck bed. The Tonneau Cover centers itself when
placed on the vehicle.
2. Pull down on the first set of clamp handles to release the clamps from the stowed position. 3. Push clamp wires up and under the flange of box (or
flange of Ram Box rail, if equipped) to the semi
clamped position.
Stowed Position
Semi Clamped Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279

4. Push clamp handles upward to the clamped positionto properly engage the clamps.
NOTE: Once clamped, be sure the clamps are not par-
tially clamped to the truck bed flange. 5. Disengage the stowage straps.
Clamped Position
Improper Clamp Position
280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Unfold Tonneau Cover to the intermediate position.
NOTE:The vehicle cannot be driven when the Tonneau
Cover is in this position. 7. Completely unfold the Tonneau Cover.
Intermediate Position (Vehicle Cannot Be Driven)
Fully Unfolded Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 281

8. Pull down on the second set of clamp handles torelease the clamps from the stowed position. 9. Push clamp wires up and under the flange of box (or
flange of Ram Box rail, if equipped) to the semi
clamped position.
Stowed Position
Semi Clamped Position
282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

10. Push clamp handles upward to the clamped positionto properly engage the clamps. NOTE:
Once clamped, be sure the clamps are not par-
tially clamped to the truck bed flange.
Clamped PositionImproper Clamp Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 283

The Tonneau Cover clamps can be locked when in the
clamped position by placing a lock through the locking
hole.CAUTION!
It is the driver ’s responsibility to ensure the Tonneau
Cover is properly installed on the vehicle. Failure to
follow this procedure can result in detachment of the
Tonneau Cover from the vehicle and/or damage to
the vehicle/Tonneau Cover.
Tri-Fold Tonneau Cover Cleaning
For proper cleaning of the Tonneau Cover use MOPAR
Whitewall & Vinyl Top Cleaner and MOPAR Leather &
Vinyl Conditioner/Protectant.
Locking Hole
284 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
