▫DID Selectable Menu Items..............365
UCONNECT SETTINGS..................379
▫Buttons On The Faceplate................381
▫Buttons On The Touchscreen..............381
▫Customer Programmable Features — Uconnect 5.0
Personal Settings......................381
▫Customer Programmable Features — Uconnect
8.4A/8.4AN Personal Settings............398
UCONNECT RADIOS...................417
iPod/USB/MP3 CONTROL — IF EQUIPPED . . .417
STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED...........................418
▫Radio Operation......................419
▫CD Player — If Equipped................419CD/DVD DISC MAINTENANCE...........419
RADIO OPERATION AND MOBILE DEVICES . .420
▫Regulatory And Safety Information.........420
CLIMATE CONTROLS...................422
▫Manual Climate Controls Without Touchscreen —
If Equipped.........................422
▫Manual Climate Controls With Touchscreen — If
Equipped...........................427
▫Automatic Climate Controls With Touchscreen —
If Equipped.........................432
▫Climate Control Functions...............438
▫Automatic Temperature Control (ATC)......440
▫Operating Tips.......................441
PERSONALIZED MENU BAR.............445
288 UNDERSTANDING YOUR INSTRUMENT PANEL

The system allows the driver to select information by
pushing the following EVIC Control buttons located on
the left side of the steering wheel:•UP Arrow Button
Push and release the UP arrow button to scroll
upward through the main menu items.
•DOWN Arrow Button
Push and release the DOWN arrow button to
scroll downward through the main menu
items.
EVIC Control Buttons
4
UNDERSTANDING YOUR INSTRUMENT PANEL 335

2. Push and release theDOWNarrow button to scroll
downward through the main menu to “Vehicle Info.”
3. Push and release theRIGHTarrow button to access
the ”Vehicle Info” screen, then scroll UP or DOWN to
select “Oil Life.”
4. Push and hold theRIGHTarrow button to select
“Reset,” then push and release theRightarrow button
to select“NO”or“YES”to reset the Oil Life to 100%.
5. Push and release theUParrow button to exit the EVIC
screen.
Vehicles Not Equipped With Passive Entry
1. Without depressing the brake pedal, cycle the ignition
to the ON/RUN position (do not start the engine).
2. Push and release theDOWNarrow button to scroll
downward through the main menu to “Vehicle Info.”3. Push and release theRIGHTarrow button to access
the “Vehicle Info” screen then scrollUPorDOWNto
select “Oil Life.”
4. Push and hold theRIGHTarrow button to select
“Reset,” then select “NO” or “YES” by pushing the
RIGHTarrow then push theRIGHTarrow button to
select reset of the Oil Life to 100%.
5. Push and release theUParrow button to exit the EVIC
screen.
NOTE:If the indicator message illuminates when you
start the vehicle, the Oil Life indicator system did not
reset. If necessary, repeat this procedure.
EVIC Selectable Menu Items
Push and release theUPorDOWNarrow buttons until
the desired Selectable Menu item is highlighted in the
EVIC.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 339

Vehicle Information (Customer Information Features)
The system allows the driver to select information by
pushing the following buttons mounted on the steering
wheel:•UP Arrow Button
Push and release theUParrow button to scroll
upward through the main menu and
submenus.
•DOWN Arrow Button
Push and release theDOWNarrow button to
scroll downward through the main menu and
submenus.
•RIGHT Arrow Button
Push and release theRIGHTarrow button to
access/select the information screens or sub-
menu screens of a main menu item. Push and
hold theRIGHTarrow button for two seconds
to reset displayed/selected features that can be reset.
DID Controls
356 UNDERSTANDING YOUR INSTRUMENT PANEL

•Stop/Start To Restart Push Clutch Or Shift To Neutral
– If Equipped
•Stop/Start Req’d Fault Detected – If Equipped
•Stop/Start Cannot Autostart Hood Open – If
Equipped
•Stop/Start Unavailable Service Battery – If Equipped
•Stop/Start Unavailable Service Stop/Start System – If
Equipped
•Stop/Start To Restart Shift Out Of Park – If Equipped
•Stop/Start Off – If Equipped
•Autostop Duration – If Equipped
The Reconfigurable Telltales section is divided into the
white telltales area on the right, yellow telltales in the
middle, and red telltales on the left.DID Selectable Menu Items
Push and release theUPorDOWNarrow buttons until
the desired Selectable Menu icon/title is highlighted in
the DID.
Digital Speedometer
Push and release theUPorDOWNarrow
button until the Digital display icon is high-
lighted in the DID. Push and release the
RIGHTarrow button to change the display
between mph and km/h.
Vehicle Info
Push and release the UP or DOWN arrow
button until the Vehicle Info icon is highlighted
in the DID. Push and release the RIGHT arrow
button to enter the submenus items of Vehicle
4
UNDERSTANDING YOUR INSTRUMENT PANEL 365

Setting NamesSetting Names Abbreviated
(Left Submenu Layer)Sub-Menus (Right Submenu
Layer)
33 Compass Variance Compass Var 1-15 increments of 1
34 Calibrate Compass Compass Cal Cancel; Calibrate
35 Fuel Saver Display Fuel Saver On; Off
36 Park Assist Front Chime
VolumePark Assist Front Chime
VolumeOn; Off
37 Park Assist Rear Chime Volume Park Assist Rear Chime Volume On; Off
UCONNECT SETTINGS
The Uconnect system uses a combination of buttons on
the touchscreen and buttons on the faceplate located on
the center of the instrument panel that allows you to
access and change the customer programmable features.
Many features can vary by vehicle.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 379

Uconnect 5.0 Buttons On The Touchscreen And Buttons
On The Faceplate
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate
Uconnect 8.4A/8.4AN Buttons On The Touchscreen And
Buttons On The Faceplate
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate 380 UNDERSTANDING YOUR INSTRUMENT PANEL

Buttons On The Faceplate
Buttons on the faceplate are located below the Uconnect
system in the center of the instrument panel. In addition,
there is a Scroll/Enter control knob located on the right
side of the Climate Controls in the center of the instru-
ment panel. Turn the control knob to scroll through
menus and change settings (i.e., 30, 60, 90), push the
center of the control knob one or more times to select or
change a setting (i.e., ON, OFF).
Your Uconnect system may also have Screen Off and
Back buttons located below the Uconnect system.
Push the Screen Off button to turn off the Uconnect
touchscreen. Push the Screen Off button a second time to
turn the touchscreen on.
Push the Back button to exit out of a Menu or certain
option on the Uconnect system.
Buttons On The Touchscreen
Buttons on the touchscreen are accessible on the
Uconnect display.
Customer Programmable Features — Uconnect
5.0 Personal Settings
Push the MORE or SETTINGS button on the faceplate,
then press the “Settings” button on the touchscreen (if
equipped) to display the settings menu screen. In this
mode the Uconnect system allows you to access pro-
grammable features that may be equipped such as Dis-
play, Units, Voice, Clock, Safety & Driving Assistance,
Lights, Doors & Locks, Auto-On Comfort (if equipped),
Engine Off Options, Suspension, Trailer Brake, Audio,
Compass Settings, Phone/Bluetooth, SiriusXM Setup (if
equipped), Restore Settings, Clear Personal Data and
System Information.
NOTE:Only one category may be selected at a time.4
