8
NISSAN INTELLIGENT KEY® SYSTE M
The Nissan Intelligent Key® system allows you to
lock or unlock your vehicle, open your liftgate and
remotely start the engine. It is important to make sure
the Intelligent Key is with you (that is, in your pocket
or purse).
REMOTE ENGINE START* (if so equipped)
The remote start operating range is approximately 200 ft (60 m) from the vehicle. The effective operating range may be shorter if there
are walls or other obstructions between the key and the vehicle.
For the remote start to function, the vehicle must be in the P (PARK) position with the ignition off and all doors must be closed and locked. Please see your Owner’s Manual
for additional information.
To start your vehicle remotely:
1. Press the button 1.
2.
W
ithin 5 seconds, press and hold the engine start
button 2 for at
least 2 seconds.
The engine will start, and the parking lights will turn on.
Automatic climate control will begin heating or cooling the vehicle depe\
nding on the
outside air temperature.
The engine will run for 10 minutes and then turn off.
Repeat steps 1 and 2 to extend the time for an additional 1 0-minute period.
•
After two remote st
arts, the ignition switch must be cycled before the remote start
can be used again.
To start driving, depress the brake pedal and press the ignition switch START/STOP button.
LOCKING AND UNLOCKING THE VEHICLE
The lock and unlock operating range of the Intelligent Key is within 31.5 in (80 cm) from
each request switch.
To lock the vehicle, push either door handle request switch
3 once or press the button
1 on the Intelligent Key.
To unlock the vehicle, perform one of the following procedures:
• Push either door handle request
switch
3 once; the corresponding door will unlock.
Push the door handle request switch
3 again within 30 seconds; all other doors
will unlock, or
•
Press the button 4 on the Intelligent Key to unlock the driver’s side door. Press
the
button 4 again; all other doors will unlock.
5124
6
FIRST DRIVE FEATURES
3
*Laws in some communities may restrict the use of remote starters. Check local regulations before using this feature.
2009259_16b_Pathfinder_US_pQRG_121715.indd 812/17/15 5:01 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
