> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
.Do not apply overload to the SD card when
inserting it to the slot. Doing so may result in
a malfunction of the device.
. The SD card may be hot when it is removed
from the device. This does not indicate a
malfunction.
Opening/Closing monitorGUID-B2435AE4-F7E8-4D3F-B32A-8F56F1BA3519
5GH0382X
Open the monitor to insert/eject a CD or an SD
card.
CAUTION * 8 , ' ' & ( ) ) $ ' $ $ ( $ $ $ $ & .Be careful not to pinch your hand or
fingers while the monitor is moving
to its open or closed position. This
may cause injury to your hand or
fingers. .
Do not force the monitor to open or
close. Doing so may damage the
monitor.
When
monitor is closed, the monitor will open. When
open, the monitor will close.
Adjusting monitor angleGUID-5422795A-E69E-4C6D-9C04-613205AF8489
LNC0003X
The angle of the monitor can be adjusted to
select from 3 different angles. Once the angle of
the monitor is selected and memorized in the
system, the selected angle is always set after
performing the open/close operation of the
monitor. Push and hold
sounds. When the button is released, the next
preset angle will be selected. Continue this
procedure until the preferred angle is obtained.
& R Q G L W L R Q
1-4
1. Getting started
Page 33 of 264
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
INFO:
. Default menus on the HOME MENU screen
are subject to change without notice.
. A SiriusXM Travel Link or SiriusXM Traffic
subscription is necessary to receive SXM
information services.
Customizing HOME MENU screenENJN1502-6891DABF-54F5-4264-BFFC-F75F8C5E4B9BThe HOME MENU screen can be personalized
by selecting which Shortcuts and Widgets to be
displayed and where to place them on the
screen.
5GH0257X
1. Push and hold
Page 49 of 264
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
off is displayed. When the climate control
system is turned off, the distance the vehicle
can drive less if the climate control system is
turned on is displayed.
*3Instant:
The system shows the distance that the
vehicle can travel using 1kWh.
*4Average:
The average energy economy from the
previous to the next resets is displayed.
*5[Reset]:
Touch [Reset] to reset the average energy
economy. After resetting the average energy
economy, it is stored in the history.
VIEWING ENERGY ECONOMY HIS-
TORY
GUID-18F7EDB5-0FDE-478F-8532-64DEF12CD4A0The previous 10 histories of the average energy
economy are displayed.
1. Push<
>and touch [Energy Info].
2. Touch [History].
5GH0398X
*1Driving Range:
The possible driving distance based on the
current charging status is displayed.
*2Variable distance:
When the climate control system is turned
on, the additional distance the vehicle can
drive by turning the climate control system
off is displayed. When the climate control
system is turned off, the distance the vehicle
can drive less if the climate control system is
turned on is displayed.
*3Previous Reset Intervals:
The average energy economy history is
displayed from along with the average for
previous Reset-to-Reset period.
*4Current Period:
The latest average energy economy is
displayed.
VIEWING ENERGY USAGE INFOR-
MATION
GUID-3715F22B-E74A-4655-8D2A-2686F907E695Estimated driving range and energy usage of
various systems are displayed.
1. Push <
>and touch [Energy Info].
2. Touch [Energy Usage].
5GH0399X
*1Driving Range:
The possible driving distance based on the
current charging status is displayed.
*2Variable distance:
When the climate control system is turned
on, the additional distance the vehicle can
drive by turning the climate control system
off is displayed. When the climate control
system is turned off, the distance the vehicle
can drive less if the climate control system is
turned on is displayed.
& R Q G L W L R Q
2-9
2. Unique EV functions
Page 50 of 264
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
*3Electric Motor:
Energy usage by the motor and regenerated
energy are displayed.
*4Climate Control:
Energy usage by the climate control func-
tion is displayed.
*5Other Systems:
Energy usage by other equipment (head-
lights, windshield wiper, etc.) is displayed.
TIMER FUNCTION OPERATIONGUID-EEDA8390-1E82-49CC-9175-669B5EB0B395This function enables the batteries to be charged
and the climate control to be turned on
automatically at a regular time and day of the
week.
SETTING TIMER CHARGEGUID-EC12A080-CA41-4007-B4AA-AD2E260188A1Use charging timer to schedule when the Li-ion
battery charges. You can save two timer settings
that include the charging start time and end time.
One of the timer settings can be applied to each
day of the week. The vehicle automatically begins
charging at the scheduled times when the
charge connector is connected to the vehicle.
The timers do not need to be reset each time the
Li-ion battery needs to be charged.
1. Push<
>and touch [Charging Timer].
5GH0378X
INFO:
Touch [Estimated Time] to view approximate
time required to reach 100% charge.
2. Touch [Edit Schedule]. Timer charge setting screen is displayed.
3. Set preferred time and day of the week for vehicle charging.
4. After entering the information, touch [Save]. A confirmation screen is displayed.
5. Touch [OK] to confirm the setting, push the power switch to the OFF position, and then
connect the charge connector to the vehicle.
Timer Charge setting screenGUID-3F85527A-E5C4-4BC2-BFA9-D7121A626CD3Two different timer setting can be registered (one
on the left side and another on the right side of
the screen) .
& R Q G L W L R Q
2-10
2. Unique EV functions
Page 55 of 264
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
UNIQUE EV FUNCTION SET-
TINGS
GUID-A273154B-E5DA-401D-BEBB-D35B2AB0863DEV unique function settings can be changed.
An active NissanConnectSMEV subscription is
needed to remotely check charge status, battery
status, use remote charging, remotely start
heating and cooling and to receive e-mails/text
messages.
1. Push <
>and touch [Zero Emission Set-
tings].
2. Touch the item you wish to set.
Setting items Action
[Battery & Power Alerts] [Use All Battery & Power Alerts] Displays all battery and power alerts on the navigation screen.
[Limited Power] Displays a message on the touch screen display to inform the driver that the
power output is restricted for various reasons.
ªLimited Power Noticeº (page 2-18)
[Low Battery] Displays the Low Battery message on the touch screen display to inform the drive
that the Li-ion battery charge is low.
ªLow Batteryº (page 2-17)
[Dest. out of Range] Displays a message on the navigation screen to inform the driver that the battery
should be charged soon. This will be indicated if the estimated driving range is
less than the remaining distance to the destination when a route to the
destination is set.
ªCharge recommendation guidanceº (page 2-17)
[Charging Messages] Sends a notification to a preset e-mail address. This notification includes the
charge connector status and the charge completion.
ªNissanConnectSMEV settingsº (page 5-11)
& R Q G L W L R Q
2-15
2. Unique EV functions
Page 119 of 264
![NISSAN LEAF 2016 1.G Navigation Manual
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
[Speed Limit Indication on Map]
Turns on/off the speed limit display function. When this ite](/manual-img/5/478/w960_478-118.png "NISSAN LEAF 2016 1.G Navigation Manual
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
[Speed Limit Indication on Map]
Turns on/off the speed limit display function. When this ite")
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
[Speed Limit Indication on Map]
Turns on/off the speed limit display function. When this item is turned on, speed limit indicator will appear on the map screen when available.
[Others]
Setting itemAction
[Map Scrolling Information] [Address Book Icons] Information about the location, on which the center of the cross pointer is placed by scrolling on the map, can be set to be displayed.
ªDisplaying map scrolling informationº (page 3-15)
[Destination/Waypoint Icons]
[Show pop-up for POIs]
[Latitude/Longitude Info]
[Customize Nearby POIs] Item 1 - Item 4
Customizes the nearby categories to show the categories that you frequently use.
[Reset] Resets the nearby categories to default.
[Keyboard Type] [QWERTY] The keyboard layout of the character input screens can be selected.
[ABC]
[Tracking Dots Displayed on
Map] [Show Tracking Dots on Map] Turns the route tracking dots display on/off.
[Dist. Between Tracking Dots] Select tracking dot interval.
[Delete Track to Current Lo-
cation] Deletes the route tracking dots up to the current location.
[Adjust Current Location] If the vehicle icon indicating the current vehicle location is not in the correct position, the location
of the vehicle icon on the map screen can be adjusted.
[Delete Stored Items]
Deletes a stored location or route.
ªDeleting stored item individuallyº (page 3-58)
& R Q G L W L R Q
3-61
3. Navigation
Page 120 of 264
![NISSAN LEAF 2016 1.G Navigation Manual
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
[Delete Previous Destinations]
Deletes all or one of the previous destinations or a previous](/manual-img/5/478/w960_478-119.png "NISSAN LEAF 2016 1.G Navigation Manual
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
[Delete Previous Destinations]
Deletes all or one of the previous destinations or a previous")
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
[Delete Previous Destinations]
Deletes all or one of the previous destinations or a previous start point.
ªDeleting stored item individuallyº (page 3-58)
[Reset All Navigation Settings to Default]
This resets various settings (display, volume level, etc.) to the default settings.
& R Q G L W L R Q
3-62
3. Navigation
Page 131 of 264
> ( G L W 0 R G H O ( 1 - 1 ( 9 1 $ 0 1 & * . @
*8
Push to open the monitor to access the CD
slot.
*9CD slot:
Insert a CD with the label side facing up.
*10<>:
Push to eject a CD.
STEERING WHEEL MOUNTED
AUDIO CONTROL BUTTONS
ENJN1502-8D8B77B0-542F-4040-8910-08948E84EDF4
5GA0115X
*1
Push the switch to change the mode to
available audio source.
*2<>/<>:
Tilting the switch up/down while the audio
system is turned on can operate the audio system such as changing tracks and radio
preset stations or channels.
*3<-+ >
(Volume control):
Push + or - side of the switch to adjust the
volume.
AUDIO OPERATIONSENJN1502-8910DA01-FA52-4035-BC56-AEEA46A2B06E
AUDIO MAIN OPERATIONENJN1502-120906-21A3D1F2-D88E-4CCE-B170-B9485A368E7F
Turning audio system on/offENJN1502-120906-DEC1D39C-0B79-4535-9FBF-86BD31187CDDThe power switch must be pushed to the ACC or
ON position to turn on the audio system. Push
<
> to turn on the last audio source that was
playing immediately before the system was
turned off. Touching [Audio] on the Launch Bar
will also turn on the audio system and the
corresponding audio screen will be displayed for
operation. To turn off the audio system, push
<
> again.
INFO:
Even when the audio system is turned off,
operating the buttons/keys for audio may turn
on the audio system.
& R Q G L W L R Q
4-11
4. Audio system
