LIFTGATE RELEASE
It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
To open the liftgate, first unlock the liftgate using
one of the following methods:
• Press the
button 1 on the key fob twice.
• Push the liftgate request switch
2.
Then push the liftgate release
switch
3 and pull the
liftgate up.
For more information, refer to the “Pre-driving
checks and adjustments (section 3)” of
your Owner’s Manual.
HEATED SEATS (if so equipped)
The seats are warmed by built-in heaters. The
switches 1, located on the center console, can
be operated independently of each other.
Push the HI (high) side of the switch for high heat.
Push the LO (low) side of the switch for low heat.
The indicator light on the switch will illuminate
when the heater is on. The indicator light will remain on as long as
the switch is on.
To turn off the heater, return the switch to the level position. Be certain the indicator
light extinguishes.
The heater is controlled by a thermostat, automatically turning the heating element on
and off.
When the vehicle’s interior is warmed or before you leave the vehicle, be sure to turn
the switch off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
SEAT ADJUSTMENTS
To slide the seat forward or backward, pull up on
the lever
1 under the front of the seat and slide
forward or backward. Release the lever to lock
the seat in position.
To recline the seatback, pull up on the lever 2
and lean back. To bring the seatback forward, pull the lever up and lean your body
forward. Release the lever to lock the seatback in position.
SEAT LIFTER (driver’s seat)
To adjust the seat height, pull up or push down on the adjusting lever 3 repeatedly.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (se\
ction 1)”
of
your Owner’s Manual.
123
1
23
FIRST DRIVE FEATURES
