2016 NISSAN JUKE rear view mirror

NEW SYSTEM FEATURES
Around View® Monitor with Moving Object Detection (MOD) (if so equipped)...............2
SiriusXM Travel Link and SiriusXM Traffic (if so equipped) ............................... 4
Siri
® Eyes Free (if so equipped) ..................................................... 4
ESSENTIAL INFORMATION
Fuel Efficient Driving............................................................... 5
Tire Pressure Monitoring System (TPMS) ............................................. 5
Loose Fuel Cap ................................................................... 6
Fuel-filler Door .................................................................... 6
Towing Your Vehicle ............................................................... 6
USB (Universal Serial Bus) Connection Port/Aux Jack and iPod
® Interface .................. 7
Setting Display Brightness and Button Brightness ......................................7
Clock Set/Adjustment ............................................................. 7
FIRST DRIVE FEATURES
NISSAN Intelligent Key® System ....................................................9
Liftgate Release ................................................................. 10
Seat Adjustments ................................................................ 10
Heated Seats (if so equipped) ..................................................... 10
Outside Mirror Control Switch ..................................................... 11
Starting/Stopping the Engine ...................................................... 11
Headlight Control Switch .......................................................... 12
Wiper and Washer Switch ......................................................... 13
Heater and Air Conditioner (automatic) (with Integrated Control Syste\
m) (if so equipped) ....14
Drive Mode (with Integrated Control System) (if so equipped) ........................... 15
FM/AM/SiriusXM
® Satellite Radio with CD Player (if so equipped) ....................... 16
Cruise Control ................................................................... 17
SYSTEM GUIDE
Trip Computer................................................................... 18
NissanConnectSM Mobile Apps ..................................................... 18
Text Messaging .................................................................. 19
Bluetooth
® Hands-free Phone System ............................................... 20
• System Operating Tips ........................................................ 20
Bluetooth
® System without Navigation (if so equipped) .................................20
Bluetooth® System with Navigation (if so equipped) ................................... 22
Navigation System (if so equipped) ................................................. 24
TAB LE OF CONTE NTS
Please see your Owner’s Manual for important safety information and system operation limitations.
• A cellular telephone should not be used for any purpose while driving
so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured
in child restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)”\
,
the “Heater, air conditioner, audio and phone systems (section 4)” and the “Starting and driving (section 5)”
of your Owner’s Manual.
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System
Owner’s Manual and at www.nissanusa.com.
1905578_16a_Juke_US_pQRG_081915.indd 58/19/15 11:07 AM

14
HEATER AND AIR CONDITIONER (automatic)
(with Integrated Control System) (if so equipped)
1 CLIMATE BUTTON

Press the CLIMATE button to access the Climate Control Mode.

When in Climate Control Mode, the selected temperature, air flow and au\
tomatic
mode or manual mode are indicated on the display.
2 AUTO BUTTON/TEMPERATURE CONTROL DIAL

The automatic mode can be used year-round. Press the AUTO button to turn
the system on, and the fan speed, air flow distribution and temperatur\
e will be
automatically maintained.

Turn the temperature control dial left for cooler air or right for warmer\
air.
3 FAN SPEED CONTROL DIAL

Turn the fan speed control dial to the left to decrease fan speed or to the right to
increase fan speed.
4 AIR FLOW CONTROL BUTTONS

Press the preferred air flow control button to select one of the follo\
wing
air flow outlets:

Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the front defroster and foot vents.
5 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front defroster button to turn the system on. The A/C automatically
turns on when the front defroster mode is selected. This feature removes humidity
from the air.

Use the temperature control dial 2 to set the desired temperature.

To set the front defroster on high, turn the fan speed control dial 3 to increase the
fan speed to the maximum setting.
6 REAR WINDOW AND OUTSIDE MIRROR (if so equipped)
DEFROSTER SWITCH

Push the rear window and outside mirror defroster switch to turn the system
on or off.
32
1
8
9
756
4
FIRST DRIVE FEATURES
1905578_16a_Juke_US_pQRG_081915.indd 148/19/15 11:08 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

15
2
1
3
4
DRIVE MODE (with Integrated Control System) (if so equipped)
1 DRIVE MODE SELECT BUTTON

Press the D-MODE button 1 to switch the display to the Drive mode. While in
the Drive mode, set-up functions, drive information and ECO information can be
displayed and adjusted.

Your vehicle’s Integrated Control System allows vehicle performance to be adjusted
by selecting from three drive modes: NORMAL, SPORT or ECO.

NORMAL
2 drive mode is recommended for normal, everyday driving.

SPORT
3 drive mode is recommended for an enhanced performance feel. Fuel
economy may be reduced.

ECO
4 drive mode is recommended for maximum fuel economy. Performance
may be reduced.
For more information, refer to the “Instruments and controls (section 2)”, the “Heater, air conditioner, audio and
phone systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
The rear window and outside mirror defroster automatically turns off afte\
r
approximately 15 minutes.
7 AIR INTAKE BUTTON
Press the air intake button to change the air circulation from the air recirculation
mode to the outside air circulation mode.

When the air recirculation indicator light illuminates, the flowing air is
recirculated inside the vehicle. This system is used to avoid outside odors and to
help adjust the inside vehicle temperature more effectively.

The air recirculation mode cannot be activated when the climate control s\
ystem is
in the front defroster mode or the front defroster and foot outlet mode .

When the outside air circulation indicator light
illuminates, the flowing air is
drawn from outside the vehicle.
8 A/C BUTTON

Press the A/C button to manually turn the A/C on or off.
9 OFF BUTTON

Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)”, the “Heater, air conditioner, audio and
phone systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
1905578_16a_Juke_US_pQRG_081915.indd 158/19/15 11:08 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
