2016 MERCEDES-BENZ GL CD player

Cargo compartment cover
Notes/how to use ........................ .3 46
Cargo compartment enlargement
Important safety notes .................. 344
Cargo compartment floor
Important safety notes .................. 347
Opening/closing ............................ 347
Stowage well (under) ..................... 347
Cargo tie down rings ......................... 345
CD player (on-board computer) ....... .2 79
Center console
Lower section .................................. 39
Upper section .................................. 38
Central locking
Automatic locking (on-board com-
puter) ............................................. 285
Locking/unlocking (SmartKey) ....... .8 2
Changing bulbs
Brake lamps .................................. .1 39
High-beam headlamps ................... 138
Low-beam headlamps .................... 138
Child
Restraint system .............................. 62
Child seat
Forward-facing restraint system ...... 66
LATCH-type (ISOFIX) child seat
anchors ............................................ 63
On the front-passenger seat ............ 65
Rearward-facing restraint system .... 66
Top Tether ....................................... 64
Child-proof locks
Important safety notes .................... 66
Rear doors ....................................... 67
Children
Special seat belt retractor ............... 61
Cigarette lighter ................................ 352
Cleaning
Mirror turn signal ........................... 380
Trailer tow hitch ............................. 381
Climate control
3-zone automatic climate control
with additional rear-compartment
climate control ............................... 150
Automatic climate control (3-
zone) .............................................. 148
Controlling automatically ............... 154
Cooling with air dehumidification .. 153
Defrosting the windows ................. 158 Defrosting the windshield .............. 157
Dual-zone automatic cli mate con-
tro l ................................................. 145
General notes ................................ 144
Indicator lamp ................................ 154
Information about using auto-
matic climate control ..................... 152
Information about using dual-zone
automatic climate control .............. 147
Maximum cooling .......................... 157
Overview of systems ...................... 144
Problem with the rear window
defroster ........................................ 159
Problems with cooling with air
dehumidification ............................ 154
Rear control panel ......................... 148
Rear control panel (3-zone auto-
matic climate control with addi-
tional rear-compartment climate
control) .......................................... 150
Refrigerant ..................................... 453
Refrigerant filling capacity ............. 454
Setting the air distribution ............. 156
Setting the air vents ...................... 160
Setting the airflow ......................... 156
Setting the climate mode (AIR
FLOW) ............................................ 155
Setting the temperature ................ 155
Switching air-recirculation mode
on/off ............................................ 159
Switching on/off ........................... 152
Switching residual heat on/off ...... 159
Switching the rear window
defroster on/off ............................ 158
Switching the ZONE function on/
off .................................................. 157
Coat hooks ......................................... 347
Cockpit
Overview .......................................... 34
see Instrument cluster
COLLISION PREVENTION ASSIST
Operation/notes .............................. 70
COMAND
ON&OFFROAD menu ..................... 262
see separate operating instructions
COMAND display
Cleaning ......................................... 381
Combination switch .......................... 132Index 7

tion display only shows the station preset if
station D is saved in the memory.X
Switch on COMAND and select Radio; see
the separate operating instructions. X
Press the Y or e button on the steer-
ing wheel to select the Audio
menu.X
To select a stored station: briefly press
c or d .X
To select a station from the station list:
press and briefly hold the c or d
button.
If no station list is received: X
To select a station using the station
search: press and briefly hold the c
or d button.
i SIRIUS XM satellite radio functions like a
normal radio.
You can find further information on radio
mode in the "Satellite radio" section of the
separate operating instructions.
Operating an audio player or audio
media
Audio data from various audio devices or
media can be played, depending on the equip-
ment installed in the vehicle. X
Switch on COMAND and select audio CD or
MP3 mode; see the separate operating
instructions. X
Press the Y or e button on the steer-
ing wheel to select the Audio
menu.X
To select the next/previous track:
briefly press the c or d button.X
To select a track from the track list
(rapid scrolling): press and hold the c or d button until the desired track C
has been reached.
If you press and hold c or d , the
rapid scrolling speed is increased. Not all
audio drives or data carriers support this
function.
If track information is stored on the audio
device or medium, the multifunction display
will show the number and title of the track.
The current track does not appear in audio
AUX mode ( Aux iliary audio mode: external
audio source connected).
Video DVD operation X
Switch on COMAND and select video DVD
(see the separate operating instructions). X
Press the Y or e button on the steer-
ing wheel to select the Audio
menu.X
To select the next or previous scene:
briefly press the c or d button.X
To select a scene from the scene list
(rapid scrolling): press and hold the c
or d button until desired scene C has
been reached.
Telephone menu
Introduction
G WARNING
If you operate information systems and com-
munication equipment integrated in the vehi-
cle while driving, you will be distracted from
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate the equipment when the traffic
situation permits. If you are not sure that this
is possible, park the vehicle paying attentionMenus and submenus 279
On-board computer and displays Z

Stowage compartment under the arm-
rest X
To open: pull handle C up.
The armrest folds out.
In the stowage compartment, there is a stow-
age tray.
i Depending on the vehicle equipment, a
USB connection or a Media Interface is
installed in the stowage compartment.
A Media Interface is a universal interface
for mobile audio equipment, e.g. for an
iPod ®
or MP3 player (see the separate
COMAND Operating Instructions).
i There is a removable stowage tray in the
storage compartment, in which objects
such as an iPod ®
can be stored.
Eyeglasses compartment X
To open: press marking C .
The eyeglasses compartment opens down. X
To close: press marking C again and the
eyeglasses compartment moves up and
engages.
Make sure that the eyeglasses compartment
is always closed while the vehicle is in motion.
Stowage compartment in the front cen-
ter console X
To open: slide cover C forwards.
Stowage compartment D appears.X
To close: pull cover C back as far as it will
go.
Stowage compartment in the rear cen-
ter console
X
To open: briefly press the stowage com-
partment marking.
The stowage compartment opens.
i Depending on the vehicle's equipment,
there may be open stowage spaces above
and below the stowage compartment.342
Stowage areas
Stowage and features
