2016 MAZDA MODEL 3 4-DOOR display

1–4
Pictorial Index
Interior Overview
Interior Equipment (View B)
SRS air bags ........................................................................\
..................................page 2-40
Active driving display ........................................................................\
...................page 4-18
Climate control system........................................................................\
....................page 5-2
Rear window defogger switch........................................................................\
.......page 4-52
Audio system........................................................................\
................................. page 5-16
CD player ........................................................................\
......................................page 5-16
Accessory sockets ........................................................................\
.......................page 5-137
External input terminal........................................................................\
..................page 5-59
Commander switch ........................................................................\
.......................page 5-36
Shift lever/Selector lever ........................................................................\
......page 4-26, 4-29
Fuse block (Left side) ........................................................................\
...................page 6-63
The equipment and installation position varies by vehicle
Mazda3_8FA4-EA-15G_Edition1.indb 42015/05/11 13:59:57

2–46
Essential Safety Equipment
SRS Air Bags
NOTE
 If it becomes necessary to have the components or wiring system for the \
supplementary
restraint system modified to accommodate a person with certain medical conditions in
accordance with a certified physician, contact an Authorized Mazda Dealer, refer to
“Customer Assistance (U.S.A.)” (page 8-2).
 When an air bag deploys, a loud inflation noise can be heard and some smoke will be
released. Neither is likely to cause injury, however, the texture of the air bags may cause
light skin injuries on body parts not covered with clothing through friction.
 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems
and that familiarization with all instructions about them, from the Owner's Manual, is
important.
 This highly-visible label is displayed which warns against the use of a \
r ear-facing child-
restraint system on the front passenger seat.
(Except Mexico)
(Mexico)
Mazda3_8FA4-EA-15G_Edition1.indb 462015/05/11 14:00:12

4–1*Some models.
4When Driving
Information concerning safe driving and stopping.
Start/Stop Engine ................................4-4
Ignition Switch
...............................4-4
Starting the Engine
.........................4-5
Turning the Engine Off
................4-10
Instrument Cluster and Display
......4-11
Meters and Gauges
.......................4-11
Active Driving Display* ...............4-18
Warning/Indicator Lights
.............4-20
Transaxle
............................................4-26
Manual Transaxle Operation
........4-26
Automatic Transaxle Controls
.....4-29
Switches and Controls
......................4-40
Lighting Control
...........................4-40
Fog Lights* ...................................4-46
Turn and Lane-Change Signals
....4-46
Windshield Wipers and Washer
...4-47
Rear Window Wiper and
Washer
*......................................... 4-51
Rear Window Defogger
...............4-52
Horn
.............................................4-53
Hazard Warning Flasher
...............4-54
HomeLink Wireless Control
System
* .........................................4-54
Brake
..................................................4-58
Brake System
...............................4-58
Hill Launch Assist (HLA)
............4-60 ABS/TCS/DSC
...................................4-62
Antilock Brake System (ABS)
.....4-62
Traction Control System (TCS)
...4-63
Dynamic Stability Control
(DSC)
...........................................4-64
i-ELOOP
............................................4-66
i-ELOOP* .....................................4-66
Fuel Economy Monitor
.....................4-69
Fuel Economy Monitor* ...............4-69
Drive Selection
...................................4-71
Drive Selection* ...........................4-71
Power Steering ................................... 4-73
Power Steering
.............................4-73
Mazda3_8FA4-EA-15G_Edition1.indb 12015/05/11 14:00:32

4–11
When Driving
Instrument Cluster and Display
Meters and Gauges
Type A
Type B
Type C
Steering Switch
(Digital Speedometer Type)
(Analog Speedometer Type (With
Tachometer))
(Analog Speedometer Type (Without Tachometer))
Some models.
Instrument Cluster
Speedometer ........................................................................\
..................................page 4-12
Odometer, Trip Meter and Trip Meter Selector ....................................................page 4-12
Tachometer ........................................................................\
....................................page 4-14
Fuel Gauge ........................................................................\
....................................page 4-14
Dashboard Illumination........................................................................\
................. page 4-15
Outside Temperature Display ........................................................................\
........page 4-16
Cruise Control Set Vehicle Speed Display ............................................................page 4-16
Active Driving Display ........................................................................\
.................page 4-18
Mazda3_8FA4-EA-15G_Edition1.indb 112015/05/11 14:00:35

4–12
When Driving
Instrument Cluster and Display
Trip Computer and INFO Switch ........................................................................\
..page 4-16
Speed Unit Selector ........................................................................\
.......................page 4-12
Speedometer
The speedometer indicates the speed of the
vehicle.
Speed Unit Selector (Type A
Instrument Cluster)
In some countries, you may have to
change the speed units between km/h and
mph.
Press the speed unit selector for 1.5
seconds or more.
The speed units for the speedometer will
change between km/h and mph.
Speedometer
Speed unit selector
Odometer, Trip Meter and Trip
Meter Selector
The display mode can be changed from
odometer to trip meter A to trip meter B
and then back to odometer by pressing the
selector while one of them is displayed.
The selected mode will be displayed. Type A/Type B
Press the selector
Press the selector
Press the selector
Odometer
Trip meter
A
Trip meter B
Type C
Press the selector
Press the selector
Press the selector
Odometer
Trip meter
A
Trip meter B
Mazda3_8FA4-EA-15G_Edition1.indb 122015/05/11 14:00:35

4–13
When Driving
Instrument Cluster and Display
NOTE
When the ignition is switched to ACC or
off, the odometer or trip meters cannot be
displayed, however, pressing the selector
can inadvertently switch the trip meters or
reset them during an approximate ten-
minute period in the following cases:
 After the ignition is switched to off from
ON. After the driver's door is opened.
Odometer
The odometer records the total distance
the vehicle has been driven.
Trip meter
The trip meter can record the total distance
of two trips. One is recorded in trip meter
A, and the other is recorded in trip meter
B.
For instance, trip meter A can record the
distance from the point of origin, and
trip meter B can record the distance from
where the fuel tank is filled.
When trip meter A is selected, pressing
the selector again within one second will
change to trip meter B mode.
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
The trip meter records the total distance
the vehicle is driven until the meter
is again reset. Return it to “0.0” by
depressing and holding the selector for
one second or more. Use this meter to
measure trip distances and to compute fuel
consumption.
NOTE
 (Vehicles with type B audio)
If the fuel economy data is reset using
the fuel economy monitor, or trip A
is reset using the trip meter when the
function which synchronizes the fuel
economy monitor and the trip meter is
on, the fuel economy data and trip A are
reset simultaneously.
Refer to Fuel Economy Monitor on page
4-69. Only the trip meters record tenths of
kilometers (miles). The trip record will be erased when:
 The power supply is interrupted
(blown fuse or the battery is
disconnected).
 The vehicle is driven over 9999.9 km
(mile).
Mazda3_8FA4-EA-15G_Edition1.indb 132015/05/11 14:00:35

4–14
When Driving
Instrument Cluster and Display
*Some models.
Tachometer*
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the
tachometer needle in the RED ZONE.
This may cause severe engine damage.
Type A
*1The range varies depending on the type
of gauge.*
1Striped zone
*
1Red zone
Type B
*1The range varies depending on the type of gauge. *
1Striped zone
*
1Red zone
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
Fuel Gauge
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Type A/Type B instrument cluster
Full
1/4 Full
Type C instrument cluster
Full
1/4 Full
If the low fuel warning light illuminates or
the fuel level is very low, refuel as soon as
possible.
Refer to Warning/Indicator Lights on page
4-20.
Mazda3_8FA4-EA-15G_Edition1.indb 142015/05/11 14:00:36

4–15
When Driving
Instrument Cluster and Display
NOTE
 After refueling, it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve since
the fuel moves in the tank.
 The display indicating a quarter or less
remaining fuel has more segments to
show the remaining fuel level in greater
detail.
 The direction of the arrow () indicates
that the fuel-filler lid is on the left side
of the vehicle.
Dashboard Illumination
When the position lights are turned
on with the ignition switched ON,
the brightness of the instrument panel
illumination is dimmed.
NOTE
When the position lights are turned on,
the position lights indicator light in the
instrument cluster turns on.
Refer to Headlights on page 4-40.
The brightness of the instrument panel and
dashboard illuminations can be adjusted
by rotating the knob.
 The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
 The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for cancelling illumination
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
heard while the instrument cluster is
dimmed with the ignition switched ON.
If the instrument cluster's visibility is
reduced due to glare from surrounding
brightness, cancel the illumination
dimmer.
NOTE
 When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the position lights are
turned on.
 When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
Mazda3_8FA4-EA-15G_Edition1.indb 152015/05/11 14:00:37
