2016 LEXUS LX570 fuse box

473
LX570_OM_OM60N01U_(U)6-3. Do-it-yourself maintenance
6
Maintenance and care
Engine compartment
Power steering fluid reservoir
(P. 4 8 1 )
Engine oil level dipstick (P. 4 7 5 )
Engine coolant reservoir ( P. 4 7 8 )
Engine oil filler cap ( P. 4 76 )Brake fluid reservoir (
P. 4 7 9 )
Fuse box ( P. 505)
Wa s h e r f l u i d t a n k ( P. 4 8 5 )
Battery ( P. 4 8 2 )
Cooling fans
Condenser ( P. 4 7 9 )
Radiator ( P. 4 7 9 )1
2
3
4
5
6
7
8
9
10
11

505
LX570_OM_OM60N01U_(U)6-3. Do-it-yourself maintenance
6
Maintenance and care
Checking and replacing fuses
Turn the engine switch off.
Open the fuse box cover.
Passenger’s side instrument panel
Remove the cover.
Remove the lid.
If any of the electrical components do not operate, a fuse may have blown. If
this happens, check and replace the fuses as necessary.
1
2
Engine compartmentDriver’s side instrument panel
Push the tab in and lift the lid off. Remove the lid.

506
LX570_OM_OM60N01U_(U)6-3. Do-it-yourself maintenance
Remove the fuse with the pull-out tool.
Only type A fuse can be removed using
the pull-out tool.
Check if the fuse is blown.Normal fuse
Blown fuse
Type A and B:
Replace the blown fuse with a new fuse of an appropriate amperage rating. The
amperage rating can be found on the fuse box lid.
Ty p e C a n d D :
Contact your Lexus dealer.
3
4
1
2
Ty p e ATy p e B
Ty p e CTy p e D

LX570_OM_OM60N01U_(U)
5076-3. Do-it-yourself maintenance
6
Maintenance and care
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (P. 5 0 8 )
●If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer.
■If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
■When replacing light bulbs
Lexus recommends that you use genuine Le xus products designed for this vehicle.
Because certain bulbs are connected to circuits designed to prevent overload, non-gen-
uine parts or parts not designed for this vehicle may be unusable.
WA R N I N G
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or injury.
●Never use a fuse of a higher amperage rati ng than indicated, or use any other object
in place of a fuse.
●Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
●Do not modify the fuses or the fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your Lexus dealer,
as soon as possible.

622Alphabetical index
LX570_OM_OM60N01U_(U)
Front passenger occupant classification system ..............................51
Front passenger’s seat belt reminder light ..................................... 526
Front seats ................................................ 140 Adjustment ............................................. 140
Cleaning .................................................. 461
Correct driving posture .................... 28
Driving position memory .................. 151
Head restraints ..................................... 155
Power easy access system .............. 151
Seat heaters ............................................417
Seat ventilators ......................................417
Front side marker lights ..................... 220 Light switch ...........................................220
Replacing light bulbs ......................... 510
Front turn signal lights ..........................216 Turn signal lever .................................. 216
Replacing light bulbs ......................... 510
Fuel ............................................................... 571 Capacity ................................................ 564
Fuel gauge ............................................... 88
Fuel pump shut off system.............523
Gas station inform ation ..................632
Information ............................................. 571
Refueling.................................................239
Type ......................................................... 564
Warning light .......................................526 Fuel consumption information..........105
Fuel filler door........................................ 239
Opener ................................................... 240
Refueling ................................................ 239
Fuel pump shut off system ................ 523
Fuses.......................................................... 505
Gas station information ......................632
Garage door opener...........................446
Gauges........................................................ 88
Glove box ................................................423
Hands-free system (for cellular phone)
*
Head restraints........................................ 155
Headlight cleaner ................................ 238
Headlights ............................................... 220 Automatic headlight leveling ....... 223
Automatic High Beam system ... 224
Light switch........................................... 220
Replacing light bulbs ........................ 510
Wattage ................................................. 570
Head-up display .................................... 100
Heated steering wheel ........................ 416
Heaters Front automatic air conditioning system ....................................................401
Outside rear view mirrors ............ 407
Seat heaters ............................................ 417
High mounted stoplight Replacing ................................................ 510
G
H
