2016 Lexus IS200t high beam

3
1
9 8
7 5 4
3
2
10
IS350/300/200t_U (OM53D18U)
6
4-1. Before driving Driving the vehicle ..................... 150
Cargo and luggage.................... 158
Vehicle load limits ......................... 161
Trailer towing ................................. 162
Dinghy towing ...............................163
4-2. Driving procedures Engine (ign ition) switch .............164
Automatic transmission ............169
Turn signal lever ............................ 175
Parking brake ................................ 177
4-3. Operating the lights and wipers
Headlight switch .......................... 178
Automatic High Beam................ 181
Fog light switch ............................ 186
Windshield wipers and washer ...........................................187
4-4. Refueling Opening the fuel tank cap .......194 4-5. Using the driving support
systems
Cruise control .............................. 198
Dynamic radar cruise control ......................................... 202
LDA (Lane Departure Alert).......... 217
Intuitive parking assist .............. 223
Lexus parking assist monitor............................ 230
Driving mode select switch ............................................246
Driving assist systems ...............249
PCS (Pre-Collision System) ......... 255
BSM (Blind Spot Monitor) ..............262
• The Blind Spot Monitor function .................................... 265
• The Rear Cross Traffic Alert function ......................... 267
4-6. Driving tips Winter driving tips ......................270
4Driving

18Pictorial index
IS350/300/200t_U (OM53D18U)
■Switches
Automatic high beam switch*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Windshield wiper de-icer switch
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 372
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . P. 83
Instrument panel light control swit ches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 84
Rear sunshade switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 389
Intuitive parking assist switch
*1, 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
BSM (Blind Spot Monitor) main switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 262
1
2
3
4
5
6
7

782. Instrument cluster
IS350/300/200t_U (OM53D18U)
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to indicate that a system check is being perfor med. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if the light
does not come on, or turn off. Have th e vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
The indicators inform the driver of the operating state of the vehicle’s various sys-
tems.
Indicators
Turn signal indicator
( P. 1 7 5 )
(if equipped)
LDA (Lane Departure
Alert) indicator ( P. 2 1 7 )
(U.S.A.)
Headlight indicator
( P. 1 7 8 )
(if equipped)
Intuitive parking assist indi-
cator ( P. 223)
(Canada)
Tail light indicator
( P. 1 7 8 ) *1, 2
Slip indicator ( P. 2 5 0 )
Headlight high beam indi-
cator ( P. 1 7 9 )
*1VSC OFF indicator
( P. 2 5 1 )
(if equipped)
Automatic High Beam indi-
cator ( P. 1 8 1 )*1, 3
(if equipped)
Pre-collision system warn-
ing light
( P. 2 5 6 )
(if equipped)
Fog light indicator
( P. 1 8 6 )*4, 5
(if equipped)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators ( P. 2 6 2 )
Cruise control indicator
(  P. 1 9 8 , 2 0 2 )
*6Security indicator
( P. 6 9 , 7 1 )
(if equipped)
Dynamic radar cruise con-
trol indicator ( P. 2 0 2 )*7Low outside temperature
indicator ( P. 8 1 )
Cruise control “SET” indica-
tor ( P. 198, 202)
*1Eco Driving Indicator Light
( P. 9 1 )

149
Driving4
IS350/300/200t_U (OM53D18U)
4-1. Before drivingDriving the vehicle ...................... 150
Cargo and luggage .................... 158
Vehicle load limits ......................... 161
Trailer towing ................................. 162
Dinghy towing............................... 163
4-2. Driving procedures Engine (ignition) switch ............ 164
Automatic transmission ............ 169
Turn signal lever ........................... 175
Parking brake .................................177
4-3. Operating the lights and wipers
Headlight switch .......................... 178
Automatic High Beam ............... 181
Fog light switch............................. 186
Windshield wipers and washer........................................... 187
4-4. Refueling Opening the fuel tank cap....... 194 4-5. Using the driving
support systems
Cruise control .............................. 198
Dynamic radar cruise control ......................................... 202
LDA (Lane Departure Alert) ..........217
Intuitive parking assist .............. 223
Lexus parking assist monitor ............................230
Driving mode select switch ........................................... 246
Driving assist systems............... 249
PCS (Pre-Collision System).......... 255
BSM (Blind Spot Moni tor).............. 262
• The Blind Spot Monitor function .................................... 265
• The Rear Cross Traffic Alert function..........................267
4-6. Driving tips Winter driving tips ..................... 270

1794-3. Operating the lights and wipers
4
Driving
IS350/300/200t_U (OM53D18U)
With the headlights on, push the
lever away from you to turn on the
high beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release
it to flash the high beams once.
You can flash the high beams with the
headlights on or off.
■Daytime running light system
●To make your vehicle more visible to other drivers during daytime driving, the daytime
running lights turn on automatically whenever the engine is started with the headlight
switch off (for Canada) or in the or “AUTO” position and the parking brake
released. (Illuminate brighter than the par king lights.) Daytime running lights are not
designed for use at night.
●Compared to turning on the headlights, the daytime running light system offers greater
durability and consumes less electricity, so it can help improve fuel economy.
■Headlight control sensor
■Automatic light off system
When the light switch is in , or : The headlights and tail lights turn off 30
seconds after the engine switch is turned to ACCESSORY mode or turned off and a
door is opened and all of the doors and trunk are closed. (The lights turn off immediately
if on the key is pressed twice after all the doors are closed.)
To turn the lights on again, turn the engine switch to IGNITION ON mode, or turn the
light switch off once and then back to or .
If any of the doors or trunk lid is left open, the lights automatically turn off after 20 min-
utes.
■Automatic headlight leveling system
The level of the headlights is automatically ad justed according to the number of passen-
gers and the loading condition of the vehicle to ensure that the headlights do not inter-
fere with other road users.
Turning on the high beam headlights
1
2
The sensor may not function properly if an
object is placed on the sensor, or anything that
blocks the sensor is affixed to the windshield.
Doing so interferes with the sensor detecting
the level of ambient light and may cause the
automatic headlight system to malfunction.

1814-3. Operating the lights and wipers
4
Driving
IS350/300/200t_U (OM53D18U)
Push the lever away from you with
the headlight switch in the or position.
Press the Automatic High Beam
switch.
The Automatic High Beam indicator will
come on when the headlights are turned
on automatically to indicate that the sys-
tem is active.
Automatic High Beam

: If equipped
The Automatic High Beam uses an in-v ehicle camera sensor to assess the
brightness of streetlights, the lights of oncoming and preceding vehicles, etc.,
and automatically turns the high beam on or off as necessary.
Activating the Automatic High Beam system
1
2

1824-3. Operating the lights and wipers
IS350/300/200t_U (OM53D18U)
When all of the following conditions are met, the high beam will be automatically
turned on (after approximately 1 second):
●Vehicle speed is above approximately 21 mph (34 km/h).
●The area ahead of the vehicle is dark.
●There are no oncoming or preceding vehicles with headlights or tail lights
turned on.
●There are few streetlights on the road ahead.
If any of the following conditions are met, the high beam will be automatically
turned off:
●Vehicle speed drops below approximately 17 mph (27 km/h).
●The area ahead of the vehicle is not dark.
●Oncoming or preceding vehicles have headlights or tail lights turned on.
●There are many streetlights on the road ahead.
■Switching to low beam
Pull the lever to the original position.
The Automatic High Beam indicator
will turn off.
Push the lever away from you to acti-
vate the Automatic High Beam sys-
tem again.
■Switching to high beam
Press the Automatic High Beam
switch.
The Automatic High Beam indicator
will turn off and the high beam indi-
cator will turn on.
Press the switch to activate the Auto-
matic High Beam system again.
High beam automatic turning on or off conditions
Turning the high beam on/off manually

1834-3. Operating the lights and wipers
4
Driving
IS350/300/200t_U (OM53D18U)
■The Automatic High Beam can be operated when
The engine switch is in IGNITION ON mode.
■Camera sensor detection information
●High beam may not be automatically tu rned off in the following situations:
• When oncoming vehicles sudd enly appear from a curve
• When the vehicle is cut in front of by another vehicle
• When oncoming or preceding vehicles are hidden from sight due to repeated
curves, road dividers or roadside trees
●High beam may be turned off if an oncoming vehicle that is using fog lights without
using the headlights is detected.
●House lights, street lights, red traffic signals, and illuminated billboards or signs may
cause the high beam to turn off.
●The following factors may affect the amount of time taken to turn high beam on or off:
• The brightness of headlights, fog lights, and tail lights of oncoming and preceding
vehicles
• The movement and direction of oncoming and preceding vehicles
• When an oncoming or preceding vehicle only has operational lights on one side
• When an oncoming or preceding vehicle is a two-wheeled vehicle
• The condition of the road (gradient, curve, condition of the road surface etc.)
• The number of passengers and amount of luggage
●High beam may be turned on or off when unexpected by the driver.
●Small vehicles, such as bicy cles, may not be detected.
●In the situations below, the system may not be able to correctly detect the surrounding
brightness levels, and may flash or expose nearby pedestrians to the high beam. There-
fore, you should consider turning the high be ams on or off manually rather than relying
on the Automatic High Beam system.
• In bad weather (rain, snow, fog, sandstorms etc.)
• The windshield is obscured by fog, mist, ice, dirt etc.
• The windshield is cracked or damaged.
• The camera sensor is deformed or dirty.
• Surrounding brightness levels are equal to those of headlights, tail lights or fog lights.
• Vehicles ahead have headlights or tail lights that are either switched off, dirty, chang-
ing color, or have improperly adjusted aim.
• When driving through an area of intermit tently changing brightness and darkness.
• When frequently and repeatedly driving ascending/descending roads, or roads with
rough, bumpy or uneven surfaces (such as stone-paved roads, gravel tracks etc.).
• When frequently and repeat edly taking curves or driving on a winding road.
• There is a highly reflective object ahead of the vehicle, such as a sign or a mirror.
• The vehicle’s headlights are damaged or dirty.
• The vehicle is listing or titling, due to a flat tire, a trailer being towed etc.
• The driver believes that the high beam may be causing problems or distress to other
drivers or pedestrians nearby.
