2016 Lexus GX460 Navigation Manual / LEXUS 2016 GX460 OWNERS MANUAL QUICK GUIDE (OM60M82U)

33
GX460_QG_OM60M82U_(U)
Four-wheel Drive System
■Four-wheel drive control switch
H4 (high speed position)
Normal driving on all types of roads.
L4 (low speed position)
Driving requiring maximum power and
traction such as climbing or descend-
ing steep hills, off-road driving, and
hard pulling in sand or mud, etc.
The low speed four-wheel drive indi-
cator will come on.
■ Center differential lock/unlock switch
Lock the center differential when your vehi-
cle’s wheels get stuc k in a ditch or when
driving on a slippery or bumpy surface. The center differential lock indicator will
come on.
Unlock the center differential after the
wheels have been freed, or after moving
to a flat, non-slippery surface.
To unlock the center differential, push
the switch again.
Use the four-wheel drive control switch and cent er differential lock/unlock switch to select
the following transfer and center differential modes.
1
2

34
GX460_QG_OM60M82U_(U)
Crawl Control (if equipped)
On/off
The Crawl Control indicator is lit and
the slip indicator flashes when operat-
ing.
Also, the operating status and speed
select status of the Crawl Control are
shown on the multi-information display.
Higher
Lower
Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing
the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on
slippery road surfaces, helping for stable driving.
1
2
3

35
GX460_QG_OM60M82U_(U)
BSM (Blind Spot Monitor) (if equipped)
The Blind Spot Monitor is a system that has 2 functions;
● The Blind Spot Monitor function
Assists the driver in making the decision when changing lanes
● The Rear Cross Traffic Alert function
Assists the driver when backing up
These functions use same sensors.
The Blind Spot Monitor on/off screen and indicator
The Blind Spot Monitor system can be turned on/off on the multi-information display.
When the system is set to on, the indicator illuminates in the meter. The Blind Spot
Monitor function and the Rear Cross Traffic Alert function are turned on/off simulta-
neously.
Outside rear view mirror indicator
The Blind Spot Monitor function:
When a vehicle is detected in the blind sp ot, the outside rear view mirror indicator
comes on while the turn signal lever is no t operated and the outside rear view mirror
indicator flashes while the turn signal lever is operated.
The Rear Cross Traffic Alert function:
When a vehicle approaching from the right or left rear of the vehicle is detected, the
outside rear view mirror indicators flash.
The Rear Cross Traffic Alert buzzer (The Rear Cross Traffic Alert function only)
When a vehicle approaching from the right or left rear of the vehicle is detected, a
buzzer sounds from behind the rear seat.
1
2
3

36
GX460_QG_OM60M82U_(U)
■Turning the Blind Spot Monitor system on
Display the Blind Spot Monitor on/off
screen.
Press the menu switch.
The multi-information display will
change modes to electronic fea-
tures control mode.
Press the “ENTER” switch
upwards or downwards until
“BSM” appears in the multi-infor-
mation display.
Press the “ENTER” switch to change to
“ON”.
The Blind Spot Monitor indicator will
be displayed. Each pressing of the switch turns the
Blind Spot Monitor on and off.
When on, the buzzer sounds to
inform the driver that the system is
operational.
Press the menu switch to change to
the normal display.1
1
2
2

37
GX460_QG_OM60M82U_(U)
Headlights
Ty p e AThe headlights, parking lights,
daytime running lights and so
on turn on and off automati-
cally (when the engine switch
is in IGNITION ON mode).
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all the
lights listed above turn on.
The daytime running lights
turn off.
1
2
3
4

38
GX460_QG_OM60M82U_(U)
Ty p e BThe daytime running lights
turn on.
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all lights
listed above turn on.
The headlights, parking lights,
daytime running lights and so
on turn on and off automati-
cally (when the engine switch
is in IGNITION ON mode).
■Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
When the light switch is in “AUTO”
position, the Automatic High Beam
system will be activated.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
1
2
3
4
1
2

39
GX460_QG_OM60M82U_(U)
Automatic High Beam (if equipped)
■Activating the Automatic High Beam system
Turn the headlight switch to “AUTO”
position.
Push the lever away from you.
The Automatic High Beam indicator
will come on when the headlights are
turned on automatically to indicate that
the system is active.
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of
streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns
high beam on or off as necessary.
1
2
When all of the following conditions are fulfille d, high beam will be automatically turned on
(after approximately 1 second): • Vehicle speed is above approximately 20 mph (32 km/h).
• The area ahead of the vehicle is dark.
• There are no oncoming or preceding vehicles with headlights or tail lights turned on.

40
GX460_QG_OM60M82U_(U)
Windshield Wipers and Washers
■Intermittent windshield wi pers with interval adjuster
Intermittent operation
Low speed operation
High speed operation
Temporary operation
Wiper intervals can be adjusted when intermittent operation is selected.
Increases the intermittent windshield
wiper frequency
Decreases the intermittent windshield
wiper frequency
Washer/wiper dual operation
The wipers will automatically operate a
couple of times after the washer
squirts.
Vehicles with headlight cleaners: If the
headlights are on, the headlight clean-
ers will operate once.1
2
3
4
5
6
7
