2016 KIA Optima Owner's Manual

97
Specifications & Consumer information
LubricantVolumeClassification
Coolant 1.6 T-GDI
7.1l(7.50 US qt.)
Mixture of antifreeze and water
(Ethylene-glycol with phosphate based coolant for
cooling device)
2.0 T-GDI
7.5 l(7.92 US qt.)
2.4 GDI
7.2l(7.60 US qt.)
Brake fluid
0.45 l(0.47 US qt.) FMVSS116 DOT-3 or DOT-4
Fuel70l (18.5 US gal.)Unleaded gasoline
JF CAN (ENG) 9.qxp 11/5/2015 4:31 PM Page 7

Specifications & Consumer information
89
Recommended SAE viscosity
number
Always be sure to clean the area
around any filler plug, drain plug, or
dipstick before checking or draining
any lubricant. This is especially impor-
tant in dusty or sandy areas and when
the vehicle is used on unpaved roads.
Cleaning the plug and dipstick areas
will prevent dirt and grit from entering
the engine and other mechanisms
that could be damaged. Engine oil vis-
cosity (thickness) has an effect on fuel
economy and cold weather operating
(engine start and engine oil flowabili-
ty). Lower viscosity engine oils can
provide better fuel economy and cold
weather performance; however, high-
er viscosity engine oils are required
for satisfactory lubrication in hot
weather. Using oils of any viscosity
other than those recommended could
result in engine damage. When
choosing an oil, consider the range of
temperature your vehicle will be oper-
ated in before the next oil change.
Proceed to select the recommended
oil viscosity from the chart.
Temperature Range for SAE Viscosity Numbers
Temperature°C
(°F)-30 -20 -10 0 10 20 30 40 50 -10 0 20 40 60 80 100 120
Gasoline Engine Oil
(Theta II 2.0 T-GDI,
Gamma 1.6 T-GDI) *
1
20W-50
10W-30
15W-40
5W-30, 5W-40
*1: For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE 5W-30 (ACEA A5). However, if the engine oil
is not available in your country, select the proper engine oil using
the engine oil viscosity chart.
*
2: For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE 5W-20 (API SM / ILSAC GF-4 / ACEA A5).
However, if the engine oil is not available in your country, select the
proper engine oil using the engine oil viscosity chart.
Gasoline Engine Oil(
Theta II 2.4 GDI) *210W-30
5W-20, 5W-30
JF CAN (ENG) 9.qxp 11/5/2015 4:31 PM Page 8

99
Specifications & Consumer information
VEHICLE IDENTIFICATION NUMBER (VIN)
The vehicle identification number
(VIN) is the number used in register-
ing your vehicle and in all legal mat-
ters pertaining to its ownership, etc.
The number is punched on the front
side wall of the engine room.The VIN is also on a plate attached
to the top of the dashboard. The
number on the plate can easily be
seen through the windshield from
outside.
The vehicle certification label
attached on the driver’s side center
pillar gives the vehicle identification
number (VIN).
VEHICLE CERTIFICATION
LABEL
OJFA085013
■
Frame number
OUM084005
■VIN label
OJF085003
JF CAN (ENG) 9.qxp 11/5/2015 4:31 PM Page 9

Specifications & Consumer information
10
9
The tires supplied on your new vehi-
cle are chosen to provide the best
performance for normal driving.
The tire label located on the driver's
side center pillar gives the tire pres-
sures recommended for your vehicle.
The engine number is stamped on the
engine block as shown in the drawing.
ENGINE NUMBER
TIRE SPECIFICATION AND
PRESSURE LABEL
OJF085012
OJF085005
OUM084007
OLF084008N
■ Gasoline engine (THETA 2.4L GDI)
■Gasoline engine (THETA 2.0L T-GDI)
■Gasoline engine (1.6 T-GDI)
JF CAN (ENG) 9.qxp 11/5/2015 4:31 PM Page 10

Index
II
JF CAN (ENG) Index.qxp 9/23/2015 4:32 PM Page 1

Index
2I
Advanced smart cruise control system (ASCC) ............6-66Limitations of the system............................................6-7\
6
Speed setting (ASCC) ................................................6-67
To adjust the sensitivity of Advanced Smart Cruise Control ................................................6-75
To convert to cruise control mode: ............................6-76
Vehicle to vehicle distance setting (ASCC)................6-71
Air bag - advanced supplemental restraint system ........3-43 Adding equipment to or modifying your air bag-equipped vehicle ..........................................3-70
Air bag warning label ................................................3-70
Air bag warning light ..................................................3-46
Curtain air bag ............................................................3-63
Driver's and passenger's front air bag ........................3-59
How does the air bag system operate? ......................3-44
Occupant Detection System (ODS) ............................3-50
Side air bag ................................................................3-61
SRS Care ....................................................................3-69\
SRS components and functions ..................................3-47
Air cleaner ....................................................................8-35\
Filter replacement ......................................................8-35
Air conditioning system ..................................................9-5
Appearance care ............................................................8-93 Exterior care ................................................................8-93
Interior care ................................................................8-98 Around view monitoring system (AVM) ....................4-102
Audio (With Touch Screen) ..........................................5-57
Bluetooth®Wireless Technology ................................5-90
Features of Your Audio ..............................................5-58
Media Mode ................................................................5-74
Phone Mode ................................................................5-89
Radio Mode ..............................................................5-69
Setup Mode ..............................................................5-105
SiriusXM Radio Mode ................................................5-72
Voice Recognition Mode ............................................5-97
Audio (Without Touch Screen) ........................................5-8 Features of Your Audio ................................................5-9
Media Mode ................................................................5-26
Phone Mode ................................................................5-32
Radio Mode ................................................................5-22
Setup Mode ................................................................5-46
SiriusXM Radio Mode ................................................5-24
Voice Recognition Mode ............................................5-37
Audio System ..................................................................5-2 Antenna ........................................................................\
5-2
Aux, USB port ..............................................................5-4
How vehicle audio works ............................................5-5
Steering wheel audio controls ......................................5-3
A
JF CAN (ENG) Index.qxp 9/23/2015 4:32 PM Page 2

I3
Index
Automatic climate control system ..............................4-128Automatic heating and air conditioning ..................4-129
Checking the amount of air conditioner refrigerant and compressor lubricant ..............................................4-138
Climate control air filter ..........................................4-138
Manual heating and air conditioning ........................4-130
System operation ......................................................4-136
Automatic transaxle ......................................................6-13 Automatic transaxle operation ....................................6-13
Good driving practices ................................................6-19
Paddle shifter ..............................................................6-17
Shift lock system ........................................................6-18
Autonomous emergency braking (AEB)/ Forward collision warning (FCW) ..............................6-51AEB warning message and system control ................6-54
Brake operation ..........................................................6-55
Limitations of the system............................................6-5\
8
Recognizing pedestrians ............................................6-61
Sensor to detect the distance from the vehicle in front (front radar) ..............................................................6-56
System malfunction ....................................................6-57
System setting and activation ....................................6-51 Battery........................................................................\
....8-43
For best battery service ..............................................8-43
Recharging the battery ................................................8-44
Reset items ..................................................................8-45
Before driving ..................................................................6-4 Before entering vehicle ................................................6-4
Before starting ..............................................................6-4
Necessary inspections ..................................................6-4
Blind spot detection system (BSD) ..............................6-85 BSD (Blind Spot Detection) / LCA (Lane Change Assist) ......................................6-86
Limitations condition condition ..................................6-91
RCTA (Rear Cross Traffic Alert) ................................6-89
Brake fluid ....................................................................8-32\
Checking the brake fluid level ....................................8-32
Brake system..................................................................6-28 Anti-lock brake system (ABS)....................................6-42
Auto hold ....................................................................6-38\
Electronic parking brake (EPB) ..................................6-31
Electronic stability control (ESC) ..............................6-44
Good braking practices ..............................................6-50
Hill-start assist control (HAC) ....................................6-49
Parking brake - Foot type ..........................................6-30
Power brakes ..............................................................6-28
Vehicle stability management (VSM) ........................6-48
Warning messages ......................................................6-40
Bulb wattage ....................................................................9-3B
JF CAN (ENG) Index.qxp 9/23/2015 4:32 PM Page 3

Index
4I
Child restraint system (CRS) ........................................3-32Children Always in the Rear ......................................3-32
Installing a Child Restraint System (CRS) ................3-36
Selecting a Child Restraint System (CRS) ................3-33
Climate control air filter ................................................8-37 Filter inspection ..........................................................8-37
Cruise Control system ..................................................6-62 To cancel cruise control ..............................................6-64
To decrease the cruising speed ..................................6-64
To increase cruise control set speed ..........................6-63
To resume cruising speed at more than approximately 30 km/h (20 mph) ............................6-65
To set cruise control speed..........................................6-63
To temporarily accelerate with the cruise control on ..6-64
To turn cruise control off ............................................6-65
Declaration of Conformity ..........................................5-114 IC ........................................................................\
......5-114
Defroster ......................................................................4-\
117 Rear window defroster ..............................................4-117
Dimensions ......................................................................9-\
2 Door locks......................................................................4-\
21
Child-protector rear door lock ....................................4-24
Impact sensing door unlock system ............................4-24
Operating door locks from inside the vehicle ............4-22
Operating door locks from outside the vehicle ..........4-21
Drive mode integrated control system ..........................6-82 DRIVE mode ..............................................................6-82
Dual clutch transmission (DCT)....................................6-20 Dual clutch transmission operation ............................6-20
Good driving practices ................................................6-27
Economical operation ....................................................6-97
Emergency starting ..........................................................7-5 Jump starting ................................................................7-5
Push-starting ................................................................7-6
Emission control system ..............................................8-100 Crankcase emission control system ..........................8-100
Evaporative emission control (including ORVR: Onboard Refueling
Vapor Recovery) system ........................................8-100
Exhaust emission control system ..............................8-101
Engine ........................................................................\
......9-2
Engine compartment ................................................2-6, 8-3
D
C
E
JF CAN (ENG) Index.qxp 9/23/2015 4:32 PM Page 4
