2016 INFINITI Q70 CD player

table of contents
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
Please see your Owner’s Manual for important safety information
and system operation limitations.
•
A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•
Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety — Seats, seat belts and
supplemental restraint system (section 1)”, the “Monitor, climate, audio,
phone and voice recognition systems (section 4)” and the “Starting and
driving (section 5)” of your Owner’s Manual.
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2016/q70 or snap this barcode with an appropriate barcode reader.
new system features Around View® Monitor with Moving Object Detection (MOD)
(if so equipped) ................................................ 2
Automatic Anti-glare Mirrors ...................................... 3
Blind Spot Warning (BSW) and Blind Spot Intervention
® (BSI)
(if so equipped) ................................................ 4
Back-up Collision Intervention (BCI) (if so equipped) .................4
Predictive Forward Collision Warning (PFCW) (if so equipped) ...........4
Forward Emergency Braking (FEB) (if so equipped) ....................5
Lane Departure Warning (LDW) (if so equipped) ...................... 5
essential information Tire Pressure Monitoring System (TPMS) ............................ 6
Warning Systems Switch (if so equipped) ........................... 7
INFINITI Drive Mode Selector .................................... 8
Accessing the Front Cup Holders .................................. 8
Loose Fuel Cap ................................................. 9
Fuel-filler Door ................................................. 9
Clock Set/Adjustment ........................................... 9
first drive features INFINITI Connection™ (if so equipped) ............................ 10
INFINITI Intelligent Key System .................................. 12
Trunk Lid Release .............................................. 13
Front Power Seat Adjustments ................................... 13
Automatic Drive Positioner ...................................... 14
Outside Mirror Control Switch .................................... 14
Starting/Stopping the Engine .................................... 15
Headlight Control Switch ........................................ 15
Wiper and Washer Switch ....................................... 16
Heater and Air Conditioner (automatic) ............................ 17
FM/AM/SiriusXM
® Satellite Radio with CD/DVD (if so equipped) Player ..19
USB (Universal Serial Bus) Connection Port/iPod® Interface ........... 20
Conventional (Fixed Speed) Cruise Control (if so equipped) ...........20
Intelligent Cruise Control (ICC) (if so equipped) .....................21
system guide Trip Computer ................................................. 22
Bluetooth® Hands-free Phone System ............................. 22
System Operating Tips ....................................... 22
Bluetooth
® System with Navigation (if so equipped) ................. 23
Bluetooth® System without Navigation (if so equipped) .............. 25
Bluetooth® Streaming Audio (if so equipped) ....................... 26
Navigation System (if so equipped) ............................... 27
DVD Player (if so equipped) ...................................... 29
HomeLink
® Universal Transceiver ................................. 29
1932611_16a_Q70_US_pQRG_092415.indd 49/24/15 11:06 AM

19
FM/AM/SiriusXM®* Satellite Radio with CD/DVD (if so equipped) Player
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB

Press the ON•OFF button to turn the system on or off.

Turn the VOL (volume) control knob right or left to increase or decrease the volum\
e.
2 AUDIO BUTTON/TUNE/FOLDER KNOB

To manually tune the radio, turn the TUNE/FOLDER knob left or right.

Press the AUDIO button to access the audio settings screen.
3 SEEK•CAT/TRACK BUTTON

To scan quickly and stop at the previous or next broadcast station, pres\
s the or
end of the SEEK•CAT/TRACK button.

For satellite radio, press the or end of the SEEK•CAT/TRACK button to switch to
the first channel of the previous or next category.

To change tracks on a CD, press the or end of the SEEK•CAT/TRACK button.

To rewind or fast forward a track on a CD, press and hold the or end of the
SEEK•CAT/TRACK button.
4 STATION PRESET BUTTONS

Twelve stations can be set for the FM band, six for the AM band and 18 f\
or
satellite radio.

To store a station in a preset, you must first select a radio band by pr\
essing the FM•AM
button
5 or XM button 6 then tune to the desired FM, AM or satellite radio station.

Next press and hold the desired station preset button (1-6) until the preset number is
updated on the display and the sound is briefly muted. The channel indic\
ator will then
display, and the sound will resume. Programing is now complete.

To retrieve a previously set station, select the radio band where the pr\
eset was stored
then press the corresponding station select button (1-6).
*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional\
satellite radio subscription service.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4\
) ” of your
Owner’s Manual.
1
356
2
4
1932611_16a_Q70_US_pQRG_092415.indd 199/24/15 11:09 AM

26
system guide
Bluetooth® Streaming Audio with Navigation (if so equipped)
If you have a compatible Bluetooth® device with streaming audio (A2DP and AVRCP
profiles), you can set up the wireless connection between your Bluetoot\
h® device and your
vehicle’s audio system. This connection allows you to listen to audio\
from the Bluetooth®
device using your vehicle’s speakers.

A cellular telephone should not be used while driving so full attention \
may be given to
vehicle operation.*

To use your connected Bluetooth® device to
stream audio, it will need to be connected as an
audio device. The following procedure will initially
connect a Bluetooth
® device as an audio player and
allow you to switch between devices.
1. Press the SETTING button on the control panel
and touch the “Bluetooth” key on the display.
2. Select “Connected Devices”.
3. Select “Audio Player”.
4. Select the name of the device that you are
attempting to connect as an audio player.
5. Select “Select”.
6. Verify that the system confirms that the device
has been selected as an audio player.

Once your Bluetooth® device has been connected
as an audio device, press the DISC•AUX button on
the control panel to select the Bluetooth
® Streaming
Audio player.

Bluetooth® connectivity issues can usually be
resolved with a reboot of your cellular phone if you
do not regularly turn off your cellular phone. Otherwise, try updating y\
our cellular phone
with the latest software.
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your Owner’s
Manual or visit www.InfinitiUSA.com/bluetooth.
3. Say the registered person’s name. The system acknowledges the command\
and
announces the next set of available commands.
4. Say: “Yes”. The system acknowledges the command and makes the call\
.
RECEIVING/ENDING A CALL

To accept the call, press the button on the steering wheel.

To reject the call, press the button on the steering wheel.

To hang-up, press the button on the steering wheel.
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4\
) ” of your Owner’s
Manual or visit www.InfinitiUSA.com/bluetooth.
1932611_16a_Q70_US_pQRG_092415.indd 269/24/15 11:10 AM

29
DVD Player (if so equipped)
This system allows you to play video files via a DVD
or CD from the front display.

To view movies on the front display, stop the
vehicle in a safe location, move the shift lever to the
P (PARK) position and apply the parking brake.

To reduce driver distraction, movies will not be
shown on the front display while the vehicle is in
any drive position.
For more information, refer to the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
HomeLink® Universal Transceiver
The HomeLink® Universal
Transceiver can learn and
consolidate the functions of
up to three different hand-held
transmitters, operating items
such as garage doors, property
gates, outdoor and indoor lights
or alarm systems.

To program the HomeLink Universal Transceiver:
• Position the handheld transceiver 1-3 in (26-76 mm) away from the Home\
Link surface,
keeping the HomeLink indicator light in view.
• Press and hold the desired HomeLink button and the handheld transmitter \
button
simultaneously until the HomeLink indicator light flashes slowly and the\
n rapidly.
• Both buttons may be released when the indicator light flashes rapidly.

To verify the programing is complete, press and hold the HomeLink button\
and observe the
indicator light:
• A solid, continuous light indicates the programing is complete, and the \
HomeLink button
will activate your device.
• A blinking light that turns to a solid, continuous light after 2 seconds\
indicates additional
steps are required to complete the programing.

An additional person may make the remaining steps easier. To complete th\
e
programing process:
• At the receiver of the device that you are programing to the HomeLink bu\
tton, press
and release the learn or smart button (the name may vary by manufacture\
r, but it is
usually located near where the hanging antenna wire is attached to the u\
nit). You have
approximately 30 seconds to initiate the following step.
• Press and hold the programed HomeLink button for 2 seconds and release.

You may have to repeat the previous two steps up to three times to compl\
ete the
programing process. HomeLink should now activate your device.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink website
at www.homelink.com or call 1-800-355-3515.
HOMELINK
