2016 GMC YUKON DENALI fog light
[x] Cancel search: fog lightPage 177 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
176 Climate Controls
Y(Vent) :Air is directed to the
instrument panel outlets.
\(Bi-Level) : Air is divided
between the instrument panel and
floor outlets.
[(Floor) : Air is directed to the
floor outlets, with some to the
windshield, side window outlets, and
second row floor outlets.
-(Defog) : This mode clears the
windows of fog or moisture. Air is
directed to the windshield, floor
outlets, and side window vents.
0(Defrost) : Press to clear the
windshield of fog or frost more
quickly. Air is directed to the
windshield and the side window
vents. The system automatically
forces outside air into the vehicle
and the air conditioning compressor
will run, unless the outside
temperature is close to freezing.
Do not drive the vehicle until all
windows are clear.
See Air Vents 0179. A/C (Air Conditioning) :
Press to
turn the air conditioning system on
or off. An indicator light comes on to
show that the air conditioning is
enabled. If the fan is turned off, the
air conditioner will not run. The A/C
light will stay on even if the outside
temperatures are below freezing.
@(Recirculation) : Press to turn
on recirculation. An indicator light
comes on. Air is recirculated to
quickly cool the inside of the
vehicle. It can also be used to help
reduce outside air and odors that
enter the vehicle. The air
conditioning compressor also comes
on when this mode is activated.
Auto Defog : The climate control
system may have a sensor to
automatically detect high humidity
inside the vehicle. When high
humidity is detected, the climate
control system may adjust to
outside air supply and turn on the
air conditioner. If the climate control
system does not detect possible
window fogging, it returns to normal
operation. To turn Auto Defog off or on, see
“Climate and Air Quality”
under Vehicle Personalization
0 155.
Rear Window Defogger
The rear window defogger uses a
warming grid to remove fog from the
rear window.
K(Rear Window Defogger) :
Press to turn the rear window
defogger on or off. An indicator light
on the button comes on to show that
the rear window defogger is on.
The rear window defogger only
works when the ignition is in ON/
RUN. The defogger turns off if the
ignition is turned to ACC/
ACCESSORY or LOCK/OFF.
Caution
Using a razor blade or sharp
object to clear the inside rear
window can damage the rear
window defogger. Repairs would
not be covered by the vehicle
warranty. Do not clear the inside
rear window with sharp objects.
Page 261 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
260 Vehicle Care
Vehicle Care
General Information
General Information . . . . . . . . . . 261
California Proposition65 Warning . . . . . . . . . . . . . . . . . 261
California Perchlorate Materials Requirements . . . . . 261
Accessories and Modifications . . . . . . . . . . . . . . . . 262
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . 262
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 263
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 264
Engine Oil . . . . . . . . . . . . . . . . . . . . 265
Engine Oil Life System . . . . . . . 267
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . 268
Engine Air Cleaner/Filter . . . . . . 269
Cooling System . . . . . . . . . . . . . . 270
Engine Coolant . . . . . . . . . . . . . . . 271
Engine Overheating . . . . . . . . . . 273
Engine Fan . . . . . . . . . . . . . . . . . . . 275
Washer Fluid . . . . . . . . . . . . . . . . . 275
Brakes . . . . . . . . . . . . . . . . . . . . . . . 276
Brake Fluid . . . . . . . . . . . . . . . . . . . 277
Battery - North America . . . . . . 278 Four-Wheel Drive . . . . . . . . . . . . . 278
Front Axle . . . . . . . . . . . . . . . . . . . . 279
Rear Axle . . . . . . . . . . . . . . . . . . . . 280
Noise Control System . . . . . . . . 280
Starter Switch Check . . . . . . . . . 281
Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 282
Park Brake and P (Park) Mechanism Check . . . . . . . . . . 282
Wiper Blade Replacement . . . . 282
Glass Replacement . . . . . . . . . . 283
Windshield Replacement . . . . . 284Headlamp Aiming
Headlamp Aiming . . . . . . . . . . . . 284
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . 284
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . . . . . . . 284
LED Lighting . . . . . . . . . . . . . . . . . 285
Fog Lamps . . . . . . . . . . . . . . . . . . . 285
Back-Up Lamps . . . . . . . . . . . . . . 285
License Plate Lamp . . . . . . . . . . 286
Replacement Bulbs . . . . . . . . . . . 287
Electrical System
Electrical System Overload . . . 287
Fuses . . . . . . . . . . . . . . . . . . . . . . . . 287
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 288 Instrument Panel Fuse
Block (Left) . . . . . . . . . . . . . . . . . 291
Instrument Panel Fuse Block (Right) . . . . . . . . . . . . . . . . . . . . . . 294
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 296
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 297
All-Season Tires . . . . . . . . . . . . . . 298
Winter Tires . . . . . . . . . . . . . . . . . . 298
Low-Profile Tires . . . . . . . . . . . . . 299
All-Terrain Tires . . . . . . . . . . . . . . . 299
Tire Sidewall Labeling . . . . . . . . 299
Tire Designations . . . . . . . . . . . . . 300
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . . 301
Tire Pressure . . . . . . . . . . . . . . . . . 303
Tire Pressure for High-Speed Operation . . . . . . . . . . . . . . . . . . . 305
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 305
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . 306
Tire Inspection . . . . . . . . . . . . . . . . 309
Tire Rotation . . . . . . . . . . . . . . . . . 309
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 310
Buying New Tires . . . . . . . . . . . . . 311
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . 313
Page 286 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
Vehicle Care 285
LED Lighting
This vehicle has several LED lamps.
For replacement of any LED lighting
assembly, contact your dealer.
Fog Lamps
To replace the front fog lamp bulb:1. Locate the fog lamp under the front bumper.
2. Disconnect the electrical connector from the fog lamp
bulb assembly by pressing the
connector release. 3. Turn the bulb counter
clockwise to remove it from the
housing.
Back-Up Lamps
To replace a back-up bulb:
1. Open the liftgate. See Liftgate
0 36.
2. Remove the taillamp closeout
cover from the lamp assembly
by pulling rearward from the
top and bottom at the same
time to unfasten the snap tabs.
3. Remove the two screws fromthe taillamp assembly.
4. Pull the taillamp assembly straight back to remove.
Page 341 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
340 Vehicle Care
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months
of ownership will reduce tendency
to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not
be damaged. Clean spots with water
and mild soap.
Coated Moldings
Coated moldings should be cleaned.
. When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede
Start by vacuuming the surface
using a soft brush attachment. If a
rotating vacuum brush attachment is
being used, only use it on the floor
carpet. Before cleaning, gently
remove as much of the soil as
possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
. For solid soils, remove as much
as possible prior to vacuuming.
To clean: 1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is
recommended to prevent lint
transfer to the fabric or carpet.
2. Remove excess moisture by gently wringing until water does
not drip from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth to a clean area frequently to
prevent forcing the soil in to the
fabric.
4. Continue gently rubbing the soiled area until there is no
longer any color transfer from
the soil to the cleaning cloth.
5. If the soil is not completely removed, use a mild soap
solution followed only by plain
water.
If the soil is not completely
removed, it may be necessary to
use a commercial upholstery
cleaner or spot lifter. Test a small
hidden area for colorfastness before
using a commercial upholstery
cleaner or spot lifter. If ring
formation occurs, clean the entire
fabric or carpet.
After cleaning, use a paper towel to
blot excess moisture.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
Use a microfiber cloth on high gloss
surfaces or vehicle displays. First,
use a soft bristle brush to remove
Page 386 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
Index 385
Assistance Systems forParking and Backing . . . . . . . . . . 231
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 45
Door Locks . . . . . . . . . . . . . . . . . . . . . 35
Headlamp System . . . . . . . . . . . . 167
Level Control . . . . . . . . . . . . . . . . . 221
Transmission . . . . . . . . . . . . . . . . . 207
Transmission Fluid . . . . . . . . . . . 268
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 209
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 282
Axle, Front . . . . . . . . . . . . . . . . . . . . . . 279
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 280
B
Battery Load Management . . . . . . . . . . . . 171
Power Protection . . . . . . . . . . . . . 172
Voltage and ChargingMessages . . . . . . . . . . . . . . . . . . . 143
Battery - North America . . . . 278, 326
Blade Replacement, Wiper . . . . . 282
Blind Spot Mirrors . . . . . . . . . . . . . . . 45
Brake Pedal and AdjustableThrottle . . . . . . . . . . . . . . . . . . . . . . 198
System Warning Light . . . . . . . . 130 Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Antilock . . . . . . . . . . . . . . . . . . . . . . . 216
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 217
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Parking . . . . . . . . . . . . . . . . . . . . . . . 217
System Messages . . . . . . . . . . . . 144
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 183
Break-In, New Vehicle . . . . . . . . . . 198
Bulb Replacement . . . . . . . . . . . . . . 287
Back-up Lamps . . . . . . . . . . . . . . . 285
Fog Lamps . . . . . . . . . . . . . . 169, 285
Headlamp Aiming . . . . . . . . . . . . . 284
Headlamps . . . . . . . . . . . . . . . . . . . 284
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . 284
License Plate Lamps . . . . . . . . . 286
Buying New Tires . . . . . . . . . . . . . . . 311
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 114
California Fuel Requirements . . . . . . . . . . . 243
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 261
California Proposition
65 Warning . . . . . . . . . .261, 278, 326
Canadian Vehicle Owners . . . . . . . . 2 Capacities and
Specifications . . . . . . . . . . . . . . . . . 358
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 206
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 36
Winter Driving . . . . . . . . . . . . . . . . 191
Cargo
Cover . . . . . . . . . . . . . . . . . . . . . . . . . 108
Tie-Downs . . . . . . . . . . . . . . . . . . . . 108
Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . 107
Chains, Tire . . . . . . . . . . . . . . . . . . . . 316
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . .118
Charging System Light . . . . . . . . . 128
Check Malfunction IndicatorEngine Light . . . . . . . . . . . . . . . . 129
Child Restraints Infants and Young Children . . . . . 87
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 92
Older Children . . . . . . . . . . . . . . . . . . 86
Securing . . . . . . . . . . . . . . . . . 100, 103
Systems . . . . . . . . . . . . . . . . . . . . . . . . 90
Child-View Mirror . . . . . . . . . . . . . . . . 47
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 334
Page 388 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
Index 387
Dual Automatic ClimateControl System . . . . . . . . . . . . . . . . 174
E
Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 259
Electrical System
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 288
Fuses . . . . . . . . . . . . . . . . . . . . . . . . 287
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . 291, 294
Overload . . . . . . . . . . . . . . . . . . . . . 287
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 296
Emergency OnStar
®. . . . . . . . . . . . . . . . . . . . . . 375
Engine Air Cleaner/Filter . . . . . . . . . . . . . 269
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . 129
Compartment Overview . . . . . . . 264
Coolant . . . . . . . . . . . . . . . . . . . . . . . 271
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . 124
Coolant Temperature
Warning Light . . . . . . . . . . . . . . . 133
Cooling System . . . . . . . . . . . . . . . 270
Cooling System Messages . . . 146 Engine (cont'd)
Drive Belt Routing . . . . . . . . . . . . 359
Exhaust . . . . . . . . . . . . . . . . . . . . . . 206
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Heater . . . . . . . . . . . . . . . . . . . . . . . . 202
Oil Life System . . . . . . . . . . . . . . . 267
Oil Messages . . . . . . . . . . . . . . . . . 146
Oil Pressure Gauge . . . . . . . . . . 123
Oil Pressure Light . . . . . . . . . . . . 134
Overheating . . . . . . . . . . . . . . . . . . 273
Power Messages . . . . . . . . . . . . . 147
Running While Parked . . . . . . . . 206
Starting . . . . . . . . . . . . . . . . . . . . . . . 201
Entry Lighting . . . . . . . . . . . . . . . . . . . 171
Equipment, Towing . . . . . . . . . . . . . 251
Event Data Recorders . . . . . . . . . . 372
Exit Lighting . . . . . . . . . . . . . . . . . . . . 171
Extender, Safety Belt . . . . . . . . . . . . 72
Exterior Lamp Controls . . . . . . . . . 165
Exterior Lamps Off Reminder . . . 166
F
Fan Engine . . . . . . . . . . . . . . . . . . . . . . . . 275
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filter, Engine Air Cleaner . . . . . . . . . . . 269
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 166 Flashers, Hazard Warning . . . . . . 168
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 316
Changing . . . . . . . . . . . . . . . . . . . . . 317
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 342
Fluid Automatic Transmission . . . . . . 268
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 277
Four-Wheel DriveTransfer Case . . . . . . . . . . . . . . . 213
Washer . . . . . . . . . . . . . . . . . . . . . . . 275
Fog Lamps
Bulb Replacement . . . . . . . 169, 285
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 234
Four-Wheel Drive . . . . . . . . . . 213, 278
Four-Wheel-Drive Light . . . . . . . . . 131
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 370
Front Automatic Braking (FAB) System . . . . . . . . . . . . . . . . . 236
Front Axle . . . . . . . . . . . . . . . . . . . . . . 279
Front Fog Lamp
Light . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Front Seats Heated and Cooled . . . . . . . . . . . . . 57
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242 Additives . . . . . . . . . . . . . . . . . . . . . 243
Economy Driving . . . . . . . . . . . . . . . 24
Page 390 of 396
GMC Yukon Denali/Yukon XL Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9159308) - 2016 - crc - 6/2/15
Index 389
Infotainment System . . . . . . . . . . . . 373
Instrument Cluster . . . . . . . . . . . . . . 120
Instrument PanelStorage Area . . . . . . . . . . . . . . . . . 106
Interior Rearview Mirrors . . . . . . . . . 46
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 326
K
Key and Lock Messages . . . . . . . . 147
Keyless EntryRemote (RKE) System . . . . . . . . . 27
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
L
Labeling, Tire Sidewall . . . . . . . . . . 299
Lamps Daytime Running (DRL) . . . . . . 166
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 170
Exterior Controls . . . . . . . . . . . . . . 165
Exterior Lamps OffReminder . . . . . . . . . . . . . . . . . . . 166
License Plate . . . . . . . . . . . . . . . . . 286
Malfunction Indicator . . . . . . . . . 129
Messages . . . . . . . . . . . . . . . . . . . . 148
On Reminder . . . . . . . . . . . . . . . . . 136 Lamps (cont'd)
Reading . . . . . . . . . . . . . . . . . . . . . . 170
Lane Change Alert (LCA) . . . . . . . 238
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 240
Lane Keep Assist (LKA) . . . . . . . . 240
Lane Keep Assist Light . . . . . . . . . 132
Lap-Shoulder Belt . . . . . . . . . . . . . . . 67
LATCH System Replacing Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . 100
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 92
LED Lighting . . . . . . . . . . . . . . . . . . . . 285
Level Control
Automatic . . . . . . . . . . . . . . . . . . . . . 221
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . 171
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Illumination Control . . . . . . . . . . . 169
LED . . . . . . . . . . . . . . . . . . . . . . . . . . 285
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Airbag Readiness . . . . . . . . . . . . . 127
Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . 131
Brake System Warning . . . . . . . 130
Charging System . . . . . . . . . . . . . 128 Lights (cont'd)
Cruise Control . . . . . . . . . . . . . . . . 136
Door Ajar . . . . . . . . . . . . . . . . . . . . . 136
Engine Coolant
Temperature Warning . . . . . . . 133
Engine Oil Pressure . . . . . . . . . . 134
Flash-to-Pass . . . . . . . . . . . . . . . . . 166
Four-Wheel-Drive . . . . . . . . . . . . . 131
Front Fog Lamp . . . . . . . . . . . . . . 136
High-Beam On . . . . . . . . . . . . . . . . 135
High/Low Beam Changer . . . . . 166
Low Fuel Warning . . . . . . . . . . . . 135
Safety Belt Reminders . . . . . . . . 126
Security . . . . . . . . . . . . . . . . . . . . . . 135
StabiliTrak
®OFF . . . . . . . . . . . . . 133
Tire Pressure . . . . . . . . . . . . . . . . . 134
Tow/Haul Mode . . . . . . . . . . . . . . . 132
Traction Control System (TCS)/StabiliTrak
®. . . . . . . . . . 133
Traction Off . . . . . . . . . . . . . . . . . . . 132
Locking Rear Axle . . . . . . . . . . . . . . 220
Locks Automatic Door . . . . . . . . . . . . . . . . . 35
Delayed Locking . . . . . . . . . . . . . . . . 35
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Lockout Protection . . . . . . . . . . . . . . 35
Power Door . . . . . . . . . . . . . . . . . . . . . 34
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 35
