2016 DODGE CHALLENGER SRT fuse

CavityCartridge Fuse Mini-Fuse Description
54 – –Fuse – Spare
55 – –Fuse – Spare
56 – –Fuse – Spare
57 – –Fuse – Spare
58 – 10 Amp Red Airbag Module
59 –20 Amp Yellow Adjustable Pedals – Police
60 – 5 Amp Tan Heated Washer Nozzles (Charger)
61 – –Fuse – Spare
62 – –Fuse – Spare
63 – –Fuse – Spare
64 –25 Amp Breaker Rear Windows (Charger/300)
65 – 10 Amp Red Airbag Module
66 – –Fuse – Spare
558 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Mini-Fuse Description
67 – 10 Amp Red Rain and Light Sensor / Sunroof /
Inside RR View Mirror / Power Outlet
Illumination (Center Console) / Police
Run Acc Relay
68 – 10 Amp Red Dual USB Power Outlet – R/A Sense
(Charger/300) Rear Sunshade
(Charger/300)
69 – –Fuse – Spare
70 – –Fuse – Spare
