Jumpy _en_Chap02_ouvertures_ed01-2016
With electric sliding side door(s)
F To totally unlock the vehicle
without opening the side door,
press this button.
F
To totally unlock the
vehicle and open the
side door, press and
hold this button until the
door has opened.
Unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold at the same time.
F

P

ress one of these buttons
(depending on equipment) to
unlock the vehicle. F

T
o unlock only the cab doors,
make an initial press on this
button.
F

T
o unlock the loading area
doors (side and rear), press on
this button again.
Total unlocking Selective unlocking
Cab and loading area selectivity
deactivated. Cab
and loading area selectivity
activated.
If fitted to your vehicle, pressing
and holding this button allows the
windows to be opened. The window
stops when you release the button. If fitted to your vehicle, pressing
and holding this button allows the
windows to be opened. The window
stops when you release the button.
F

P
ress on this button to unlock the
loading area o n l y.
If fitted to your vehicle:
Access

59
Jumpy _en_Chap02_ouvertures_ed01-2016
The unlocking, locking or deadlocking
does not take place:
-
i
f the ignition is on,
-

i
f one of the doors or the boot is still
open,
-

i
f the key for the Keyless Entry and
Starting system has been left inside
the vehicle.
When the vehicle is locked (with the
remote control or Keyless Entry and
Starting), if it is unlocked inadvertently,
it will lock itself again automatically after
about thirty seconds unless a door has
been opened.
And if your vehicle has an alarm, this
will be reactivated (with volumetric
monitoring, even if this had been
deactivated).
"Keyless Entry and
Starting" on your person
This allows the unlocking, locking and starting
the vehicle while keeping the remote control on
your person. As a safety measure (children on
board), never leave the vehicle without
taking your Keyless Entry and Starting
remote control, even for a short period.
Guard against theft when the Keyless
Entry and Starting remote control is in
the recognition zone with the vehicle
unlocked.
In order to preserve the charge of the
cell battery in the remote control, the
"hands-free" functions go into extended
stand-by after 21 days of non-use.
To restore these functions, press one of
the remote control buttons or start the
engine with the remote control at the
reader. The folding and unfolding of the door
mirrors by the remote control can be
deactivated by a CITROËN dealer or a
qualified workshop.
In the ignition on (accessories) position,
with the "START/STOP" button, the
hands-free function is deactivated.
For more information on "
Keyless
Entry and Starting " and in particular
the "ignition on" position, refer to the
corresponding section.
2
Access

70
Jumpy _en_Chap02_ouvertures_ed01-2016
Changing the battery
Battery ref.: CR2032 / 3 volts.
This replacement battery is available from a
CITROËN dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement of the battery is needed.Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.
F

P

lace the remote control against the
reader.
F

K

eeping it in place, switch on the ignition
by pressing "START/STOP".
The remote control is fully operational again.
Reinitialisation
Remote control problem
Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F

F
irst, use the integral key in the door lock
to unlock or lock your vehicle.
F

T
hen, reinitialise the remote control.
If the problem persists, contact
a CITROËN dealer or a qualified
workshop as soon as possible.
F

U
nlock the driver's door using the
integral
key.
F

P
ress one of the remote control
buttons.
F

P
lace the integral key in the lock to unlock
your vehicle. F

U
nclip the cover using a small screwdriver
at the cutout.
F

L
ift off the cover.
F

R
emove the flat battery from its location.
F

F
it the new battery into its location
observing the original direction of fitment.
F

C
lip the cover onto the casing.
Access

71
Jumpy _en_Chap02_ouvertures_ed01-2016
Lost keys, remote control
Visit a CITROËN dealer with the vehicle's
registration certificate, your personal
identification documents and if possible, the
label bearing the key code.
The CITROËN dealer will be able to retrieve
the key code and the transponder code
required to order a new key.
Locking the vehicle
Driving with the doors locked may make
access to the passenger compartment by
the emergency services more difficult in an
emergency.
As a safety precaution (with children on
board), remove the key from the ignition
or take the remote control with you when
leaving the vehicle, even for a short time.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the keys in
your possession are the only ones which can
start the vehicle.
Electrical interference
The Keyless Entry and Starting remote
control may not operate if close to certain
electronic devices: telephone, laptop
computer, strong magnetic fields, ...Accumulations (water, dust, grime,
salt...) on the inner sur face of the door
handle may affect detection.
If cleaning the inner sur face of the door
handle using a cloth does not restore
detection, contact a CITROËN dealer or
a qualified workshop.
A sudden splash of water (stream of
water, high pressure jet washer, …) may
be identified by the system as the desire
to open the vehicle.
Remote control
The high frequency remote control is a
sensitive system; do not operate it while it is
in your pocket as there is a possibility that
it may unlock the vehicle, without you being
aware of it.
Do not repeatedly press the buttons of your
remote control out of range and out of sight
of your vehicle. You run the risk of stopping
it from working and the remote control would
have to be reinitialised.
The remote control does not operate when
the key is in the ignition, even when the
ignition is switched off.
Anti-theft protection
Do not make any modifications to the
electronic engine immobiliser system; this
could cause malfunctions.
Do not forget to turn the steering to engage
the steering lock.
2
Access

78
Jumpy _en_Chap02_ouvertures_ed01-2016
Electric sliding side door(s)
The exterior and interior door handles and the interior buttons allow the electrically powered
movement of the door to be started.
Opening and closing of the doors is accompanied by an audible signal.The remote controls buttons are not
active with the ignition switched on.
Opening
From outside
Using the remote controlF Press this button again to reverse the movement of the
d o o r.
Using the handle
F Door unlocked, press and hold this button until the
corresponding sliding side door
has opened. F

D
oor unlocked, pull and release the handle
to start the electrically powered opening of
the door.
F
P
ull the handle again to reverse the
movement of the door.
Access

82
Jumpy _en_Chap02_ouvertures_ed01-2016
The remote controls buttons are not
active with the ignition switched on.
Closing
From outside
F To start the electrically powered opening of the door, press the button for the
corresponding door.
F

P
ressing the button again reverses the
movement of the door.
Using the button(s) at the front
The button is not operational and
pressing it results in an audible signal,
if the speed of the vehicle is above
20
mph (30 km/h).
From inside
Using the remote control
F Press and hold this button until the sliding door has closed.
F

P
ress this button again to
reverse the movement of the
d o o r.
Using the handle
F Pull and release the handle to start the electrically powered opening of the door.
F

P
ull the handle again to reverse the
movement of the door.
Access

125
Jumpy _en_Chap03_ergonomie-et-confort_ed01-2016
Temperature
Air flow
F Turn the knob to obtain
the desired air flow.
If you place the air flow control at
the minimum position (off), the
temperature in the vehicle will no longer
be maintained. However, a slight flow of
air can still be felt due to the movement
of the vehicle.
Heating / Ventilation
F Turn the knob from " LO"
(cold) to " HI" (hot) to
adjust the temperature to
your wishes.
Air distribution
Windscreen and side windows.
Footwells. Centre and side air vents.
The air distribution can be modulated by
pressing additional buttons.
Air intake / Air recirculation
The intake of exterior air avoids misting of the
windscreen and side windows.
The recirculation of interior air insulates the
passenger compartment from exterior odours
and fumes.
Return to exterior air intake as soon as
possible to avoid deterioration of the air
quality and the formation of mist. This allows hot or cold air to be
delivered quickly when required.F

P
ress this button to recirculate
the interior air; its indicator lamp
comes on.
F

P
ress this button again to allow
exterior air into the passenger
compartment; its indicator lamp
goes off.
3
Ease of use and comfort

126
Jumpy _en_Chap03_ergonomie-et-confort_ed01-2016
The air conditioning system only operates with the engine running.
Manual air conditioning
Temperature
F Turn the knob from "LO"
(cold) to " HI" (hot) to
adjust the temperature to
your requirements.
Air flow
F Turn the knob to obtain a comfortable air flow.
If you put the air flow control in the
minimum position
(system off), the
temperature is no longer controlled.
However, a slight flow of air can still be
felt, resulting from the movement of the
vehicle.
Air distribution
Windscreen and side windows.
Footwells. Central and side vents.
The air distribution can be adapted by adding
the corresponding buttons.
Air intake / Air recirculation
The intake of exterior air avoids misting of the
windscreen and side windows.
The recirculation of interior air insulates the
passenger compartment from exterior odours
and fumes.
Return to exterior air intake as soon as
possible to prevent deterioration of the
air quality and the formation of mist. This allows hot or cold air to be
delivered quickly when required.F

P
ress this button to recirculate
the interior air; its indicator lamp
comes on.
F

P
ress this button again to allow
exterior air into the passenger
compartment; its indicator lamp
goes off.
