Rear Temperature Control
To change the temperature in the rear of the vehicle,
rotate the temperature knob counterclockwise to lower
the temperature, and clockwise to increase the tempera-
ture. The rear temperature settings are displayed in the
front ATC panel.
When rear controls are locked by the front system, the
Rear Temperature Lock symbol on the temperature knob
is illuminated and any rear overhead adjustments are
ignored.
Rear Mode Control
Auto Mode
The rear system automatically maintains the correct
mode and comfort level desired by the rear seat occu-
pants.Headliner Mode
Air comes from the outlets in the headliner. Each
of these outlets can be individually adjusted to
direct the flow of air. Moving the air vanes of the outlets
to one side will shut off the airflow.
Bi-Level Mode
Air comes from both the headliner outlets and the
floor outlets.
NOTE: In many temperature positions, the Bi-Level
mode is designed to provide cooler air out of the head-
liner outlets and warmer air from the floor outlets.
Floor Mode
Air comes from the floor outlets.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 477
Reclining............................ .199
Stow N Go (Fold in Floor) ................205
Security Alarm .......................... .339
Arm The System ........................18
Disarm The System .......................18
Tamper Alert ...........................20
Selection Of Coolant (Antifreeze) ..............682
SENTRY KEY FCC General Information ..................17
Key Programming .......................17
Sentry Key (Immobilizer) ....................15
Sentry Key Replacement .....................16
Service Assistance ........................ .695
Service Contract ......................... .697
Service Manuals ......................... .700
Settings, Personal ........................ .368
Setting The Clock ...................377, 386, 401
Shift Lever Override ...................... .627
Shoulder Belts ............................65 Signals, Turn
...............128, 235, 351, 677, 678
Sliding Door .............................50
SmartBeams ............................ .236
Snow Chains (Tire Chains) ...................548
Snow Tires ............................. .541
Spare Tire ....................... .543, 544, 604
Spark Plugs ............................ .682
Speed Control (Cruise Control) ................247
Starting ............................... .485
Automatic Transmission ..................486
Cold Weather ......................... .489
Engine Fails To Start .....................489
Remote ...............................30
Starting And Operating .....................485
Starting Procedures ....................... .485
Steering Power ........................... .507, 508
Tilt Column .......................... .242
Wheel, Heated ........................ .243
10
INDEX 719
