Vehicle Care 283
Number Usage45 Battery regulated voltage control
46 Engine control module battery
47 –
48 –
*49 Trailer module 50 Door lock security
51 Rear closure release
52 –
53 –
54 Door lock security
55 –
*56 Fuel door
* OptionalWheels and Tires
Tires
Every new GM vehicle has
high-quality tires made by a
leading tire manufacturer. See
the warranty manual for
information regarding the tire
warranty and where to get
service. For additional
information refer to the tire
manufacturer.
{Warning
.Poorly maintained and
improperly used tires are
dangerous.
.Overloading the tires can
cause overheating as a
result of too much
flexing. There could be a
blowout and a serious
crash. See Vehicle Load
Limits 0187.
(Continued)
Warning (Continued)
.Underinflated tires pose
the same danger as
overloaded tires. The
resulting crash could
cause serious injury.
Check all tires frequently
to maintain the
recommended pressure.
Tire pressure should be
checked when the tires
are cold.
.Overinflated tires are
more likely to be cut,
punctured, or broken by
a sudden impact —such
as when hitting a pothole.
Keep tires at the
recommended pressure.
.Worn or old tires can
cause a crash. If the
tread is badly worn,
replace them.
(Continued)

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
Service and Maintenance 323
At your dealer, you can be certain
that you will receive the highest
level of service available. Your
dealer has specially trained service
technicians, uses genuine
replacement parts, as well as,
up-to-date tools and equipment to
ensure fast and accurate
diagnostics.
The proper replacement parts,
fluids, and lubricants to use are
listed inRecommended Fluids and
Lubricants 0327 andMaintenance
Replacement Parts 0328. We
recommend the use of genuine
parts from your dealer.
Rotation of New Tires
Tire rotation is not recommended if
the vehicle has different size tires
on the front and rear wheels. If tire
rotation is recommended for the
vehicle, to maintain ride, handling,
and performance of the vehicle, it is
important that the first rotation
service for new tires be performed.
Tires should be rotated every
service. See Tire Rotation 0292.Maintenance
Schedule
When the Change Engine Oil
Soon Message Displays
Change engine oil and filter. See
Engine Oil 0254. An Emission
Control Service.
When the CHANGE ENGINE OIL
SOON message displays, service is
required for the vehicle as soon as
possible, within the next 1 000 km/
600 miles. If driving under the best
conditions, the engine oil life system
may not indicate the need for
vehicle service for up to a year. The
engine oil and filter must be
changed at least once a year and
the oil life system must be reset.
Your dealer has trained service
technicians who will perform this
work and reset the system. If the
engine oil life system is reset
accidentally, service the vehicle
within 5 000 km/3,000 miles since
the last service. Reset the oil life
system whenever the oil is changed.
See Engine Oil Life System 0256.
Every Engine Oil Change
.
Change engine oil and filter.
Reset oil life system. See
Engine Oil 0254 and Engine Oil
Life System 0256. An Emission
Control Service.
. Engine coolant level check. See
Engine Coolant 0261.
. Engine cooling system
inspection. Visual inspection of
hoses, pipes, fittings, and
clamps and replacement,
if needed.
. Windshield washer fluid level
check. See Washer Fluid 0266.
. Windshield wiper blade
inspection for wear, cracking,
or contamination and windshield
and wiper blade cleaning,
if contaminated. See Exterior
Care 0313. Worn or damaged
wiper blade replacement. See
Wiper Blade
Replacement 0271.
. Tire inflation pressures check.
See Tire Pressure 0286.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
324 Service and Maintenance
.Tire wear inspection. See Tire
Inspection 0292.
. Rotate tires if necessary. See
Tire Rotation 0292.
. Fluids visual leak check (or
every 12 months, whichever
occurs first). A leak in any
system must be repaired and the
fluid level checked.
. Engine air cleaner filter
inspection. See Engine Air
Cleaner/Filter 0258.
. Brake system inspection (or
every 12 months, whichever
occurs first). See Exterior
Care 0313.
. Steering and suspension
inspection. Visual inspection for
damaged, loose, or missing
parts or signs of wear.
. Body hinges and latches, key
lock cylinders, folding seat
hardware, and sunroof (if
equipped) lubrication. See
Recommended Fluids and
Lubricants 0327. More frequent
lubrication may be required
when the vehicle is exposed to a corrosive environment. Applying
silicone grease on weatherstrips
with a clean cloth makes them
last longer, seal better, and not
stick or squeak.
. Restraint system component
check. See Safety System
Check 069.
. Fuel system inspection for
damage or leaks.
. Exhaust system and nearby heat
shields inspection for loose or
damaged components.
Additional Required Services
Every Service
.Rotate tires. Tires should be
rotated every service. See Tire
Rotation 0292.
At Each Fuel Stop
. Engine oil level check. See
Engine Oil 0254.
. Engine coolant level check. See
Engine Coolant 0261.
. Windshield washer fluid level
check. See Washer Fluid 0266. Once a Month
.
Tire inflation check. See Tire
Pressure 0286.
. Tire wear inspection. See Tire
Inspection 0292.
. Sunroof track and seal
inspection, if equipped. See
Sunroof 048.
Once a Year
. See Starter Switch Check 0270.
. See Automatic Transmission
Shift Lock Control Function
Check 0270.
. See Park Brake and P (Park)
Mechanism Check 0270.
. Accelerator pedal check for
damage, high effort, or binding.
Replace if needed.
. Underbody flushing service.
. Hood/Trunk Support Gas Strut
Service: Visually inspect gas
strut, if equipped, for signs of
wear, cracks, or other damage.
Check the hold open ability of
the gas strut. Contact your
dealer if service is required.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
Service and Maintenance 325
.Engine air cleaner filter
replacement or every 20 000 km/
12,500 Miles. See Engine Air
Cleaner/Filter 0258. If driving in
dusty conditions, inspect the
filter at each oil change or more
often as needed.
Every 40 000 km/25,000 Miles
. Passenger compartment air filter
replacement (or every
24 months, whichever occurs
first). More frequent replacement
may be needed if you drive in
areas with heavy traffic, areas
with poor air quality, or areas
with high dust levels.
Replacement may also be
needed if you notice reduced air
flow, windows fogging up,
or odors. Your dealer can help
you determine when it is the
right time to replace the filter.
Every 72 000 km/45,000 Miles
. Replace brake fluid (or every
three years, whichever occurs
first).
. Rear axle fluid (If equipped with
limited slip). Every 80 000 km/50,000 Miles
.
Evaporative control system
inspection. Check all fuel and
vapor lines and hoses for proper
hook-up, routing, and condition.
Every 100 000 km/60,000 Miles
(2.0L Turbo and 3.6L Twin Turbo
Engines)
. Spark plug replacement and
spark plug wire inspection. An
Emission Control Service.
Every 160 000 km/100,000 Miles
(2.5L and 3.6L Engines)
. Spark plug replacement and
spark plug wire inspection. An
Emission Control Service.
Every 240 000 km/150,000 Miles
. Engine cooling system drain and
refill (or every five years,
whichever occurs first). See
Cooling System (Engine) 0259
or Cooling System (Intercooler)
0 261. An Emission Control
Service. .
Engine drive belts inspection for
fraying, excessive cracks,
or obvious damage (or every
10 years, whichever occurs
first). Replace, if needed.
Severe Conditions Requiring
More Frequent Maintenance*
.Public service, military,
or commercial use vehicles to
include the following:
‐Ambulances, police cars and
emergency rescue vehicles.
‐ Civilian vehicles such as light
duty pick-up trucks, SUVs and
passenger cars that are used
in military applications.
‐ Recovery vehicles such as
tow trucks and flatbed single
vehicle carriers or any vehicle
that is consistently used in
towing trailers or other loads.
‐ High use commercial vehicles
such as courier delivery
vehicles, private security patrol
vehicles or any vehicles that
operate on a 24 hour basis.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
Technical Data 333
ApplicationCapacities
Metric English
Wheel Nut Torque –ATS-V (Blue Tint Nut) 150 Y110 lb ft
Wheel Nut Torque –ATS-V (Silver Tint Nut) 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.
Engine Specifications
Engine VIN Code Horsepower TorqueSpark Plug Gap
2.0L L4 Engine X203 kW@ 5600 rpm
(272 hp@ 5600 rpm) 400
Y@ 3800 rpm
(295 lb ft @
3800 rpm) 0.75–0.90 mm (0.030–
0.035 in)
2.5L L4 Engine A151 kW@ 6300 rpm
(202 hp@ 6300 rpm) 258
Y@ 4400 rpm
(190 lb ft @ 4400 rpm) 0.95–1.10 mm (0.037–
0.043 in)
3.6L V6 Engine 3239 kW@ 6800 rpm
(321 hp@ 6800 rpm) 372
Y@ 4800 rpm
(274 lb ft @ 4800 rpm) 0.80–0.90 mm (0.031–
0.035 in)
3.6L V6 Twin Turbo
Engine Y
339 kW@ 5750 rpm
(455 hp@ 5750 rpm) 603
Y@ 3500 rpm
(445 lb ft @ 3500 rpm) 0.75–0.90 mm (0.030–
0.035 in)

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
338 Index
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 245
Accessory Power . . . . . . . . . . . . . . . 195
Adaptive Cruise Control . . . . . . . . 214
Adaptive Forward Lighting (AFL) . . . . . . . . . . . . . . . . . 154
Adaptive Forward Lighting (AFL) Light . . . . . . . . . . . . . . . . . . . . 125
Add-On Electrical Equipment . . . 243
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . 56
Thigh Support . . . . . . . . . . . . . . . . . . 56
Air Cleaner/Filter, Engine . . . . . . . 258
Air Filter, Passenger
Compartment . . . . . . . . . . . . . . . . . 174
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 173
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . 82
How Does an Airbag
Restrain? . . . . . . . . . . . . . . . . . . . . . 75
Passenger Sensing System . . . . 76
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 75
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . . . 75
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 73 Airbag System (cont'd)
Where Are the Airbags? . . . . . . . . 72
Airbags Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 81
Passenger Status Indicator . . . .117
Readiness Light . . . . . . . . . . . . . . .116
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 81
System Check . . . . . . . . . . . . . . . . . . 70
Alarm Vehicle Security . . . . . . . . . . . . . . . . 41
Alert Lane Change . . . . . . . . . . . . . . . . . 230
Side Blind Zone (SBZA) . . . . . . 230
All-Season Tires . . . . . . . . . . . . . . . . 284
Antilock Brake System (ABS) . . . 201 Warning Light . . . . . . . . . . . . . . . . . 121
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 313
Interior . . . . . . . . . . . . . . . . . . . . . . . . 317
Armrest Storage . . . . . . . . . . . . . . . . 101
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 226
Assistance Systems for Parking and Backing . . . . . . . . . . 222
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . 37

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
Index 339
Automatic (cont'd)Headlamp System . . . . . . . . . . . . 153
Transmission . . . . . . . . . . . . . . . . . 198
Transmission Fluid . . . . . . . . . . . 257
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 200
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 270
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . 268Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 157
Jump Starting . . . . . . . . . . . . . . . . . 307
Power Protection . . . . . . . . . . . . . 157
Voltage and Charging
Messages . . . . . . . . . . . . . . . . . . . 132
Blade Replacement, Wiper . . . . . 271
Brake System Warning Light . . . . . . . . 120
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 266 Antilock . . . . . . . . . . . . . . . . . . . . . . . 201
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 204
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Parking . . . . . . . . . . . . . . . . . . 202, 203
System Messages . . . . . . . . . . . . 132
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 177
Break-In, New Vehicle . . . . . . . . . . 190
Bulb Replacement . . . . . . . . . . . . . . 274 Bulb Replacement (cont'd)
Back-up Lamps . . . . . . . . . . . . . . . 273
Halogen Bulbs . . . . . . . . . . . . . . . . 272
Headlamp Aiming . . . . . . . . . . . . . 272
Headlamps . . . . . . . . . . . . . . . . . . . 272
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 272
License Plate Lamps . . . . . . . . . 273
Buying New Tires . . . . . . . . . . . . . . . 294C
Capacities and
Specifications . . . . . . . . . . . . . . . . . 332
Carbon Fiber . . . . . . . . . . . . . . . . . . . 191
Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . 197
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Winter Driving . . . . . . . . . . . . . . . . 185
Cargo
Tie-Downs . . . . . . . . . . . . . . . . . . . . 102
Caution, Danger, and Warning . . . . 2
Chains, Tire . . . . . . . . . . . . . . . . . . . . 298
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . 109
Charging System Light . . . . . . . . . 117
Check Malfunction IndicatorEngine Light . . . . . . . . . . . . . . . . .118 Child Restraints
Infants and Young Children . . . . . 84
Lower Anchors and Tethers
for Children . . . . . . . . . . . . . . . . . . . 89
Older Children . . . . . . . . . . . . . . . . . . 83
Securing . . . . . . . . . . . . . . . . . . . . 95, 96
Systems . . . . . . . . . . . . . . . . . . . . . . . . 86
Circuit Breakers . . . . . . . . . . . . . . . . 275
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 313
Interior Care . . . . . . . . . . . . . . . . . . 317
Climate Control Systems Dual Automatic . . . . . . . . . . 164, 168
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Cluster, Instrument . . . . . . . . . . . . . 111
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . 100
Competitive Driving Mode . . . . . . 208
Compressor Kit, Tire Sealant . . . 300
Control Traction and Electronic
Stability . . . . . . . . . . . . . . . . . . . . . 205
Control of a Vehicle . . . . . . . . . . . . . 177
Convex Mirrors . . . . . . . . . . . . . . . . . . 43
Coolant Engine . . . . . . . . . . . . . . . . . . . . . . . . 261
Engine Temperature Gauge . . .115

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-9369639) -
2016 - crc - 12/9/15
340 Index
Coolant (cont'd)Engine Temperature
Warning Light . . . . . . . . . . . . . . . 123
Cooling System . . . . . . . . . . . . 259, 261
Engine Messages . . . . . . . . . . . . 134
Courtesy Lamps . . . . . . . . . . . . . . . . 155
Cruise Control . . . . . . . . . . . . . . . . . . 211 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Messages . . . . . . . . . . . . . . . . . . . . 133
Cruise Control, Adaptive . . . . . . . . 214
Cupholders . . . . . . . . . . . . . . . . . . . . . 101
D
Danger, Warning, and Caution . . . . 2
Data Recorder Performance . . . . . . . . . . . . . . . . . . 158
Data Recorders, Event . . . . . . . . . 336
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 152
Defensive Driving . . . . . . . . . . . . . . . 177
Delayed Locking . . . . . . . . . . . . . . . . . 37
Distracted Driving . . . . . . . . . . . . . . . 176
Dome Lamps . . . . . . . . . . . . . . . . . . . 155
Door Ajar Messages . . . . . . . . . . . . . . . 133
Delayed Locking . . . . . . . . . . . . . . . . 37
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Power Locks . . . . . . . . . . . . . . . . . . . . 37
Rear Seat Pass-Through . . . . . . . 64 Drive Belt Routing, Engine . . . . . . 335
Driver Assistance Systems . . . . . 221
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . . 126
Driver Mode Control . . . . . . . . . . . . 207
Driving Assistance Systems . . . . . . . . . . 226
Characteristics and
Towing Tips . . . . . . . . . . . . . . . . . 238
Competitive . . . . . . . . . . . . . . . . . . . 208
Defensive . . . . . . . . . . . . . . . . . . . . . 177
For Better Fuel Economy . . . . . . . 27
Hill and Mountain Roads . . . . . . 184
If the Vehicle is Stuck . . . . . . . . . 186
Loss of Control . . . . . . . . . . . . . . . 179
Off-Road Recovery . . . . . . . . . . . 178
Track Events and Competitive . . . . . . . . . . . . . . . . . 179
Vehicle Load Limits . . . . . . . . . . . 187
Wet Roads . . . . . . . . . . . . . . . . . . . 184
Winter . . . . . . . . . . . . . . . . . . . . . . . . 185
Dual Automatic Climate Control System . . . . . . . . . . . 164, 168
E
Easy Entry Seat . . . . . . . . . . . . . . . . . 53
Electrical Equipment,Add-On . . . . . . . . . . . . . . . . . . . . . . . 243
Electrical System
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 275
Fuses and Circuit Breakers . . . 275
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 278
Overload . . . . . . . . . . . . . . . . . . . . . 274
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 281
Engine
Air Cleaner/Filter . . . . . . . . . . . . . 258
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . .118
Compartment Overview . . . . . . . 247
Coolant . . . . . . . . . . . . . . . . . . . . . . . 261
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . .115
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 123
Cooling System . . . . . . . . . . 259, 261
Cooling System Messages . . . 134
Drive Belt Routing . . . . . . . . . . . . 335
Exhaust . . . . . . . . . . . . . . . . . . . . . . 197
Oil Life System . . . . . . . . . . . . . . . 256
