2016 AUDI A3 ESP

,....,
N
0 > co ,...., smash the child seat and child against the
backrest, center armrest, door or roof.
- Always install rear-facing child seats on the
rear seat.
- If you must install a rearward facing child
seat on the front passenger seat because of
exceptional circumstances and the
PASSEN­
GER AIR BAG OFF
light does not come on
and stay on, immediately install the rear­
facing child seat in a rear seating position
and have the airbag system inspected by
your Audi dealer.
A WARNING
Objects between you and the airbag will in­
crease the risk of injury in a crash by interfer­
ing with the way the airbag unfolds or by be­
ing pushed into you as the airbag inflates.
- Never hold things in your hands or on your
lap when the vehicle is in use.
- Never transport items on or in the area of
the front passenger seat . Objects could
move into the area of the front airbags dur­
ing braking or other sudden maneuvers and
become dangerous projectiles that can
cause serious personal injury if the airbags
inflate.
- Never place or attach accessories or other objects (such as cup holders, telephone
brackets, large, heavy or bulky objects) on
the doors, over or near the area marked "AIRBAG" on the steering wheel, instru­
ment panel, seat backrests or between
those areas and yourself. These objects
could cause injury in a crash, especially
when the airbags inflate.
- Never recline the front passenger's seat to
transport objects. Items can also move into
the area of the side airbag or the front air­ bag during braking or in a sudden maneu­
ver. Objects near the airbags can become
projectiles and cause injury, particularly
when the seat is reclined.
- Never place or transport objects on the front passenger seat. Objects on the front passenger seat could cause the capacitive
sensor in the seat to signal to airbag system
Airbag system
that the seat is occupied by a person when it
in fact is not, or that the person on the seat
is heavier than he or she actually is. The
change in electric capacitance because of
such objects can cause the passenger front
airbag to be turned on when it should be
off, or can cause the airbag to work in a way
that is different from the way it would have
worked without objects on the seat.
- Always make sure that there is nothing on
the front passenger seat that will cause the
capacitive passenger detection system in
the seat to signal to the Airbag System that
the seat is occupied by a person when it is not, or to signal that it is occupied by some­
one who is heavier than the person actually
sitting on the seat. The presence of an ob­
ject could cause the passenger front airbag to be turned on when it should be off, or
could cause the airbag to work in a way that is different from the way it would have
worked without the object on the seat.
_LD. WARNING
The fine dust created when airbags deploy can cause breathing problems for people with a
history of asthma or other breathing condi­
tions.
- To reduce the risk of breathing problems,
those with asthma or other respiratory con­
ditions should get fresh air right away by
getting out of the vehicle or opening win­
dows or doors.
- If you are in a collision in which airbags de­ ploy, wash your hands and face with mild
soap and water before eating .
- Be careful not to get the dust into your eyes,
or into any cuts or scratches.
- If the residue should get into your eyes, flush them with water .
195

Airbag system
If the PASSENGER AIR BAG light still does
not come on ...
If the PASSENGER AIR BAG OFF light still does
not come on and does not stay on continuously
(when the ignition is switched on),
- take the child restraint off the front passenger
seat and install it properly at one of the rear
seat positions. Have the airbag system inspect­
ed by your Audi dealer immediately .
- move the chi ld to a rear seat position and make
sure that the child is properly restrained in a
child restraint that is appropriate for its size
and age .
The PASSENGER AIR BAG light should NOT
come on ...
The PASSENGER AIR BAG OFF light should NOT
come on when the ignition is on and an adult is
sitting in a proper seating position on the front
passenger seat. If the
PASSENGER AIR BAG OFF
light comes on and stays on or flashes for about
S seconds while driving, under these circumstan­
ces, make s ure that:
- the adult on the front passenger seat is proper­
ly seated on the center of the seat cushion with
his or her back up against the backrest and the
backres t is not recl ined,
- the adu lt is not taking weight off the seat by
holding on to the passenger assist handle
above the front passenger door or supporting
their weight on the armrest,
- the safety belt is being properly worn and that
there is not a lot of slack in the safety belt web­
bing,
- there are no aftermarket seat covers or cush­
ions or other things (such as blankets) on the
front passenger seat that might cause the ca­
pacitive passenger detection system to miscal­
culate electrical capacitance.
Important safety instructions on
monitoring the Advanced Airbag System
A WARNING
- If the status of the Adv a need Airbag System
has changed while the vehicle is moving, the
PASSENGER AIR BAG OFF light blinks for
198
about S seconds to catch the driver's atten­
tion. If this happens, always stop as soon as
it is safe to do so and check the steps descri­
bed above .
- If the
PASSENGER AIR BAG OFF light does
not go off when an adult who is not very
small is sitting on the front passenger seat
after taking the steps described above, make sure the adult is properly seated and
restrained at one of the rear seating posi­
tions. Have the airbag system inspected by
your authorized Audi dealer befo re trans­
porting anyone on the front passenger seat.
A WARNING
An airbag system that is not functioning prop­
erly cannot provide supplemental protection in a fronta l crash.
- If the airbag indicator light~
page 21
comes when the vehicle is being used, have
the system inspected immediately by your
authorized Audi dealer.
It is possible that
the airbag will inflate when it is not sup­
posed to, or wi ll not inflate when it should.
A WARNING
If the front airbag inflates, a ch ild without a
chi ld restraint, or in a rearward-facing child
safety seat, or in a forward-fac ing ch ild re­
straint that has not been properly insta lled
will be seriously injured and can be killed.
- Even though you r vehicle is equipped with
an Advanced A irbag System, make certain
that a ll children, especially 12 years and
younger, always ride on the back seat prop­
erly restrained for their age and size.
-Always install forward or rear-facing child seats on the rear seat -even with an Ad­
vanced Airbag System.
- If you must install a rearward-facing child
seat on the front passenger seat because of
except ional circumstances and the
PASSEN·
GER AIR BAG OFF
light does not appear and
stay on, immediately install the rear-facing
child seat in a rear seat ing position and have
the airbag system inspected by your Audi
dea le r.
~

,....,
N
0 > co ,...., -If, in exceptiona l circumstances, you must
insta ll a forward-fac ing ch il d restraint on
the front passenger seat, always move the
seat into its rearmost pos ition in the seat's
fore and aft adjustment range, as far away
from the airbag as possib le . The backrest
must be ad justed to an up right posit ion.
Make sure that the
PASSENGER AIR BAG
OFF
light comes on and stays on all the time
whenever the ignition is switched on .
A WARNING
-If the PASSENGER AIR BAG OFF light does
not go out when an ad ult is sitting on the
front passenger seat after taking the steps
described above, make sure the adu lt is
properly seated and restrained at one of the
rear seat ing pos itions .
- Have the airbag system inspected by your
Audi dealer before transport ing anyone on
the front passenger seat .
If the capacitive passenger detection system
determines that the front passenger seat is
empty, the frontal airbag on the passenge r
side w ill be tu rned off, and the
PASSENGER
AIR BAG OFF
light will stay on .
Repair, care and disposal of the airbags
Pa rts of t he air bag system are i nstalled at many
d ifferen t places on your Aud i. Insta lling , remov­
ing, servi cing or repa iring a part in an area of the
ve hicle can damage a part of an airbag system
and prevent that system from working properly
in a co llision .
There are some important things you have to
know to mak e sure that the effectiveness of the
system wi ll not be impaired and that discarded
components do not cause injury or poll ute the
env ironment.
A WARNING
Improper care, serv icing and repa ir proce­
dures can increase the r isk of personal injury
and death by preventing an airbag from de-
-
Airb ag sys tem
ploying when needed or deploy ing an a irbag
unexpectedly:
- Never cover, obstruct, or change the steer­
ing wheel ho rn pad or airbag cover or the in­
strument panel or modify them in any way.
- Never attach any ob jects s uch as c up ho lders
or telephone mountings to the surfaces cov­
ering the a irbag un its.
- For cleaning the horn pad or instr ument
panel, use only a soft, dry cloth or one mois­
tened with p lain water. Solvents or cleaners
could damage the airbag cove r or change
the st iffness o r strength of the material so
that the ai rbag cannot deploy and p rotect
p rope rly.
- Never repair, adjust, or change any parts of
the airbag system.
- All work on the steering wheel, inst rument
panel, front seats or e lectr ica l system ( in­
cludi ng the ins tall ation of a udio eq uipment,
cellular telephones and C B radios , etc.)
m ust be performed by a qualif ied techn ic ian
who has the t raining and spec ial equ ipment
necessary.
- For any wo rk on the airbag system, we
strong ly recommend that you see yo ur au­
thor ized Audi dealer or qualif ied workshop .
- Never modify the front bumpe r or parts of
the vehicle body.
- Always make sure that the s ide a irbag can
inflate w ithout interference:
- Never install seat covers or replacement
upholste ry ove r the front seatbacks that
have not been specifica lly approved by
Audi .
- Never use additional seat c ushions that
cove r the areas where the sid e airbags in­
flate.
- Damage to the orig inal seat cove rs or to
the seam in the area of the s ide airbag
module must always be repaired immedi­
ate ly by an au thori ze d Aud i dealer .
- The airb ag system can deploy on ly once. Af­
ter an airb ag h as been deployed, i t must be
replaced with new replacement parts de­
signed and approve d espec ially for your
Audi mo del version . Replacement of com­
p lete airbag systems or airbag components
199

Airbag syste m
Although they are not a soft pillow, they can
"cushion" the impact and in this way they can
he lp to reduce the risk of injury to the lower ex­
tremities .
All of this takes place in the blink of an eye, so
fast that many people don't even realize that the airbags have deployed. The a irbags also inflate
with a great deal of force and it is important for
occupant safety that nothing should be in their
way when they deploy .
Fully inflated airbags in comb ination with proper­
ly worn safety belts slow down and limit the oc­
cupant's forward movement and help to reduce
the risk of inju ry.
Important safety instructions on the knee
airbag system
App lies to veh icles : with knee a irbags
Airbags are only supplemental restraints . Always
wear safety belts correctly and ride in a proper
seating position.
There is a lot that you and your passengers must
know and do to help the safety belts and airbags
to provide supplemental protection .
,&. WARNING
An inflating knee airbag can cause ser ious in ­
jury. Wearing safety bel ts incorrectly and im­
proper seating positions increase the r isk of
serious personal injury and death whenever a
vehicle is being used.
- The knee airbag system cannot protect you properly if you are seated too close to any of
the airbag locat ions. When adjusting their
seat positions, it is important that both the driver and the front passenger keep their
upper bodies and knees at the following
min imum safe distances:
- at least 10 inches (25 cm) between the
chest and the steering wheel/instrument panel.
- at least 4 inches (10 cm) between the
knees and the lower part of the instru­ ment panel.
- The risk of persona l injury increases if you
lean forward or to the s ide, or if the seat is
202
improperly positioned and you are not wear­
ing your safety belt. The risk increases even
more should the airbag deploy.
- Always make sure that the knee a irbag can
inflate w ithout interference. Objects be­
tween you and the airbag can increase the
r isk of injury in an accident by interfering
w ith the way the airbag deploys or by being
pushed i nto you as the a irbag deploys.
- Never let anybody, especia lly children or
anima ls ride in the footwell in front of the
passenger seat. If the airbag deploys, this
can result in serious or fatal injuries .
- Never carry objects of any kind in the foot ­
well area in front of the driver's or pas­ senger's seat. Bulky objects (shopp ing
bags, for example) can interfere with or
prevent proper dep loyment of the a irbag.
Small objects can be thrown through the
vehicle if the airbag deploys and injure you
or your passengers.
- Ma ke sure there are no crac ks, deep scratch­
es o r other damage in the area of the i nst ru­
ment panel where the knee airbags are lo ­
cated .
- If children are incorrec tly seated, their risk
of injury increases in a coll is ion
c:::> page 209, Child safety.
Side airbags
Description of side airbags
The airbag system can provide supplemental
protection to properly restrained occupants .
Fig. 169 S ide a irbag locatio n in the driver 's seat

Airbag syste m
_& WARNING
-Safety belts and the a irbag system w ill only
provide protection when occupants are in
the proper seating position
¢ page 204 .
-If the airbag indicator light r::!;> page 21
comes when the vehicle is being used, have
the system inspected immediate ly by your
authorized Audi dealer. It is possible that
the airbag will inflate when it is not sup­ posed to, or will not inflate when it should.
How supplemental side airbags work
Side airbags deploy instantly and can help re­
duce the risk of upper torso injuries for occu­
pants who are properly restrained .
Fig. 170 Side impact protect ion : inflated s ide a irbags (ex ­
amp le)
When the system is triggered, the airbag is filled
with propellant gas and breaks through a seam in the seat surface area marked "AIRBAG" .
It ex­
pands between the s ide trim panel and the pas­
senger . In order to help provide this additional
protection, the side airbag must inflate within a
fract ion of a second at very high speed and with
great fo rce. The supplementa l side airbag could
injure you if your seating position is not proper or
upright or if items are located in the area where
the supplemental side airbag expands. This ap­ plies especially to children
¢ page 209, Child
safety .
Supplemental side airbags inflate be­
tween the occupant and the door pane l on the
side of the vehicle that is struck in certa in side
coll is ion
r::!;> fig. 170.
Although they are not a soft pillow, they can
"cushion" the impact and in th is way they can
204
help to reduce the risk of injury to the upper part
of the body.
A fine d ust may develop when the a irbag dep loys.
This is norma l and does not mean there is a fire
in the vehicle.
Important safety instructions on the side
airbag system
Airbags are only supplemental restraints. Always
properly wear safety belts and ride in a proper
seating position .
There is a lot that you and your passengers must
know and act according ly to he lp the safety belts
and airbags do their job to provide supplemental protect ion.
_& WARNING
An inflating side a irbag can cause serious or
fata l injury. Improperly wearing safety belts
and improper seating posit ions increase the
risk of serious persona l injury and death
whenever a vehicle is being used.
- In order to reduce the risk of injury when
the supplemental side airbag inflates:
- Always s it in an upr ight position and never
l ean against the area where the supple-
mental side airbag is located.
- Never let a child or anyone e lse rest their
head against the side trim panel in the
area where the supplementa l side airbag
i nflates .
- Always make sure that safety belts are
worn correctly,
- Do not let anyone s itting in the front seat
put their hand or any other parts of their
body out of the window .
- Always make sure that the side a irbag can
inflate without interference.
- Never ins tall sea t covers or replacement
u pholstery ove r the fron t seatbacks that
have not been specifica lly approved by
Audi.
- Never use additional seat c ushions that
cover the areas where the side airbags de- ploy . ..,.

..... N
0 > CX)
..... I.Cl U"I
..... I.Cl ..... How side curtain airbags work
Side curtain airbags can work together with side
airbags to help reduce the risk of head and upper torso injuries for occupants who are properly re­
strained.
Fig. 172 Ill ustra tion of prin ciple : Inflated s ide cur ta in air ­
bags on th e left side ( example )
The side curtain airbags inflate between the oc­
cupant and the windows on the side of the vehi­
cle that is st ruck in a side collision
¢ fig. 1 72 .
When the system is triggered, the side curtain
airbag is filled with propellant gas and breaks
through a seam above the front and rear side
windows identified by the AIRBAG label. In order
to help provide this additional protection, the
side cur tain airbag mus t inflate within the blink
of an eye at very high speed and with great force .
The side curtain airbag could injure you if your
seating position is not proper or upright or if
items are located in the area where the supple­
mental side curtain airbag inflates . This applies
especially to children
9 page 209.
Although they are not a soft pillow, side curtain
airbags can "cushion " the impact and in this way
they can help to reduce the risk of injury to the
head and the upper part of the body.
A fine dust may develop when the airbag deploys .
This is quite normal and does not mean there is a
fire in the vehicle.
Airbag system
Important safety instructions on the side
curtain airbag system
Airbags are only supplemental restraints . Always
properly wear safety belts and ride in a proper seating position .
There is a lot that you and your passengers must
know and do to help the safety belts and airbags
do their job to provide supplemental protection.
A WARNING ~
Improperly wearing safety belts and improper
seating positions increase the risk of serious personal injury and death whenever a vehicle
is being used.
- Never let occupants place any parts of their
bodies in the area from which the side cur­
tain airbag inflate.
- Always make sure that the side curtain air­
bags can inflate without interference .
- Use the built-in coat hooks only for light­
weight clothing. Never leave any heavy or sharp-edged objects in the pockets that may
interfere with airbag deployment and can
cause personal injury in a collision.
- Never use hangers to hang clothes on the
hooks.
- Only use factory-installed sun shades or, if
shades installed after the vehicle leaves the
factory, use only genuine Audi sun shades.
- Never swing the sun visors over to the side
windows if things such as pens, garage door
openers, hands-free speakers, etc . are at ­
tached to the sun visors. They could come
loose and cause serious injury if the side cur­
tain airbag inflates.
- A deploying airbag inflates in a fraction of a
second and with great force.
- Never attach objects to the cover or in the
deployment zone of a side curtain airbag.
- The airbag deployment zones must be kept clear at all times. Make sure there are no
objects, pets, or other persons in the space
between any vehicle occupant and any air­
bag at any time.
- Do not attach any accessories to the doors.
207

,....,
N
0 > co ,...., Child safety
Important information
Introduction
The rear seat is generally the safest place in a
collision .
The physical principles of what happens when
your vehicle is in a crash apply also to children
c:> page 177, What happens to occupants not
wearing safety belts? .
But unlike adults and
teenagers, their muscles and bones are not fully
developed. In many respects children are at
greater r isk of serious injury in crashes than
adults .
Because children's bodies are not fu lly devel­
oped, they requ ire restraint systems especially
des igned for their size, we ight , and body struc­
ture. Many countr ies and all states of the United
States and provinces of Canada have laws requir­
ing the use of approved child restraint systems
for infants and small children .
In a frontal crash at a speed of 20-3 5 mph
(30-56 km/h) the forces acting on a 13-pound
(6 kg) infant will be more than 20 times the
weight of the child . This means the weight of the
child would suddenly be more than 260 pounds
(120 kg) . Under these conditions, only an appro­
priate child restraint properly used can reduce
the risk of serious injury . Child restra ints, like
adult safety belts, must be used properly to be
effect ive. Used improperly, they can increase the
risk of serious injury in an accident .
Consult the child safety seat manufacturer's in­
structions in order to be sure the seat is right for
your child's size
c:> page 212, Important safety
instructions for using child safety seats .
Please
be sure to read and heed all of the important in­
formation and WARNINGS about child safety,
Advanced Airbags, and the installation of child restraints in this chapter.
There is a lot you need to know about the Ad­
vanced Airbags in your vehicle and how they work
when infants and children in chi ld restraints are
on the front passenger seat . Because of the large
amount of important information, we cannot re-
Ch ild safety
peat it all here. We urge you to read the detailed
information in this owner's manual about airbags
and the Advanced Airbag System in your vehicle
and the very important information about trans­
porting children on the front passenger seat.
Please be sure to heed the WARNINGS -they are
extremely important for your safety and the safe­
ty of your passengers, especially infants and small chi ldren.
_& WARNING
- Accident statistics have shown that children
are generally safer in the rear seat area than in the front seating position . Always restrain
any child age 12 and under in the rear.
- All vehicle occupants and especially children must be restrained properly whenever riding
in a vehicle. An unrestrained or improperly restrained child cou ld be injured by striking
the inter ior or by being ejected from the ve­
h icle during a sudden maneuver or impact .
An unrestrained or improperly restrained
child is a lso at greater risk of injury or death
through contact w ith an inflating a irbag.
-A suitable ch ild restraint properly installed
and used at one of the rear seating positions
provides the h ighest degree of protect ion
for infants and small children in most acci­
dent situat ions .
_& WARNING
f"-"---
Children on the front seat of any car even with
Advanced Airbags can be seriously injured or
even killed when an airbag inflates . A child in
a rearward-facing chi ld safety seat installed
on the front passenger seat will be seriously i njured and can be killed if the front airbag in­
flates .
- The inflating airbag will h it the ch ild safety
seat or infant carr ier with great force and
will smash the child safety seat and child aga inst the backrest, center armrest, or
door.
- Always install rear-fac ing child safety seats
on the rear seat .
- If you must install a rearward facing child
safety seat on the front passenger seat in
209

,....,
N
0 > co ,...., Advanced front airbag system and children
Your vehicle is equipped with a front "Advanced
Airbag System" in compliance w ith United States
F edera l Motor Vehicle Safety Standard ( FMVSS)
208, as well as Canada Motor Vehicle Safety
Standard (CMVSS) 208 as applicable at the time
your veh icle was manufactured.
The Advanced Airbag system in your vehicle has been certified to meet the "low-risk" require ­
ments for 3- and 6-year old children on the pas­
senger side and small adults on the driver side.
The low risk deployment criteria are intended to
reduce the risk of injury through interaction with
the airbag that can occur, for example, by being
too close to the steering wheel and instrument panel when the airbag inflates. In addition, the
system has been certified to comply with the
"s uppress ion " req uirements of the Safety Stand­
a rd, to turn off the front ai rbag for infants up to
12 months who are restrained on the front pas­
senger seat in child restraints that are listed in
the Standard.
E ven though your vehicle is equipped with an Ad ·
vanced Airbag system, all children, especially
those 12 years and younger, should always ride
in the back seat properly restra ined for their age
and si ze. The airbag on the passenger side makes
the front seat a potentially dangerous place for a
child to r ide . The front seat is not the safest place
for a child in a forward-facing child safety seat .
It
can be a very dangerous place for an infant or a
l arger child in a rearward -facing seat.
The vehicle's Advanced A irbag System has a ca ­
pac itive passenger detect io n system in the front
passenger seat cush ion that can detect the pres­
ence of a baby or a child in a ch ild restraint sys­
tem on this seat .
The capacit ive passenger detection system regis­
ters the changes that result in an electrical fie ld
when a ch ild, a child restra int, and a baby blanket
are on the front passenge r seat. The change in
the measured capacitance due to the presence of
a child, a child restraint, and a baby b lanket on
the front passenger seat is related to the child restraint system resting on the seat. The meas­
ured capacitance of a child restraint system var-
Ch ild safety
ies depending on the type of system and specific
make and mode l.
T he elect rical capac itance of the va rious types,
makes, and models of chi ld restra ints specified
by the U.S .National Highway Traff ic Safety Ad­
ministration (NHTSA) in the relevant safety
standard are stored in the Advanced Airbag Sys­
tem control unit together with the capacitances
typ ical of infants and a 1-year old child. When a
child restraint is used on the front passenger
seat w it h a typical 1 year-old infant, the Ad­
vanced Airbag System compares the capacitance measured by the capacitive passenge r detection
system with the data stored in the electronic co n­
t rol unit.
Child restraints and Advanced front airbag
system
Regardless of the ch ild restraint that you use,
make sure that it has been certified to meet Safe­
ty Standards and has been cert ified by its manu ­
facturer for use w ith an airbag . Always be sure
that the c hild rest raint is p roperly installed at
one of the rear seating positions . If in exception­
al circumstances you must use it on the front
passenge r seat, carefu lly read a ll of the informa­
tion on child safety and Advanced Airbags and heed all of the applicable WARNINGS . Make cer ­
tain that the chi ld and child restraint are correct­
ly recognized by the capac itive passenger detec­
t ion system in the front passenger seat, that the
front passenger a irbag is turned off, and that the
airbag status is always correctly s ignaled by the
PASSENGER AIR BAG OFF light .
Many types and models of child restra ints have
been available over the years, new models are in ­
troduced regu larly incorporating new and im­
proved designs and older models a re take n out of
production. Child restra ints are no t standa rdized.
Child res tra ints of the same type typically have
different weights and sizes and different "foot­
prints", the size and shape of the bottom of the
chi ld restraint that sits on th e seat, when they
are installed on a vehicle seat. These d ifferences
make it virtually impossib le to certify compliance
with the requirements for advanced a irbags w ith
each and every child restra int that has ever been ..,.
21 1
