2016.5 VAUXHALL ASTRA J trip computer

100Instruments and controlsInstruments and
controlsControls ..................................... 101
Steering wheel adjustment ......101
Steering wheel controls ...........101
Heated steering wheel .............101
Horn ......................................... 102
Windscreen wiper/washer .......102
Rear window wiper/washer .....104
Outside temperature ................104
Clock ....................................... 105
Power outlets ........................... 106
Cigarette lighter .......................107
Ashtrays .................................. 107
Warning lights, gauges and indi‐ cators ......................................... 108
Instrument cluster ....................108
Speedometer ........................... 108
Odometer ................................ 108
Trip odometer .......................... 108
Tachometer ............................. 108
Fuel gauge .............................. 109
Fuel selector ............................ 109
Engine coolant temperature gauge ..................................... 109
Service display ........................ 110Control indicators ....................111
Turn signal ............................... 114
Seat belt reminder ...................114
Airbag and belt tensioners .......114
Airbag deactivation ..................114
Charging system .....................115
Malfunction indicator light ........115
Service vehicle soon ...............115
Brake and clutch system .........115
Operate pedal .......................... 115
Electric parking brake ..............115
Electric parking brake fault ......116
Antilock brake system (ABS) ...116
Upshift ..................................... 116
Power steering ........................ 116
Lane departure warning ..........116
Ultrasonic parking assist .........117
Electronic Stability Control off . 117
Electronic Stability Control and Traction Control system .........117
Traction Control system off .....117
Preheating ............................... 117
Diesel particle filter ..................117
Tyre pressure monitoring system .................................... 118
Engine oil pressure ..................118
Low fuel ................................... 118
Immobiliser .............................. 119
Reduced engine power ...........119
Exterior light ............................ 119High beam............................... 119
High beam assist .....................119
Adaptive forward lighting .........119
Fog light ................................... 119
Rear fog light ........................... 119
Low washer fluid ......................119
Cruise control .......................... 119
Adaptive cruise control ............119
Vehicle detected ahead ...........120
Door open ................................ 120
Information displays ...................120
Driver Information Centre ........120
Graphic-Info-Display, Colour- Info-Display ............................ 124
Smartphone controller .............126
Vehicle messages ......................126
Warning chimes .......................129
Battery voltage ........................ 129
Trip computer ............................. 130
Vehicle personalisation ..............132
OnStar ....................................... 137

Instruments and controls123reset knob between speedometer
and Driver Information Centre with
the ignition on.
On vehicles with trip computer, more
submenus are available.
Selection and indication can be
different between Midlevel-Display
and Uplevel-Combi-Display.
Trip/Fuel Information Menu, Trip
Computer 3 130.
ECO Information Menu
Press MENU to select s in the top
line of the Uplevel-Combi-Display.
Turn the adjuster wheel to select a
submenu. Press SET/CLR to confirm.Submenus are:
●Shift indication : Current gear is
indicated inside an arrow. The
figure above recommends
upshifting for fuel saving
reasons.
Eco index display : The current
fuel consumption is indicated on a segment display. For
economical driving, adapt your driving characteristic to keep the
filled segments within the Eco
area. The more segments are
filled, the higher the fuel
consumption. Simultaneously
the current consumption value is
indicated.
● Top Consumers : List of top
comfort consumers currently
switched on is displayed in
descending order. Fuel saving
potential is indicated. A switched off consumer disappears from
the list and the consumption
value will be updated.
During sporadic driving
conditions, the engine will
activate the heated rear window
automatically to increase the
engine load. In this event, the
heated rear window is indicated
as one of the top consumers,
without activation by the driver.

130Instruments and controls1. Switch off immediately anyelectric consumers which are not
required for a safe ride, e.g. seat
heating, heated rear window or
other main consumers.
2. Charge the vehicle battery by driving continuously for a while or
by using a charging device.
The warning message or warning
code will disappear after the engine
has been started twice consecutively
without a voltage drop.
If the vehicle battery cannot be
recharged, have the cause of the fault
remedied by a workshop.Trip computer
The menus and functions can be selected via the buttons on the turn
signal lever 3 120.
Press MENU to select the Trip/Fuel
Information Menu , or select W on
the Uplevel-Combi-Display.
Trip/Fuel Information Menu on
Uplevel-Combi-Display
Turn the adjuster wheel to select the
submenus:

Instruments and controls131
● trip odometer 1
● average consumption 1
● average speed 1
● trip odometer 2
● average consumption 2
● average speed 2
● digital speed
● range
● instantaneous consumption
● route guidance
Trip computer 1 and 2 The information of two trip computerscan be reset separately for odometer,
average consumption and average
speed by pressing SET/CLR, making
it possible to display different trip
information for different drivers.
Trip odometer
Trip odometer displays the recorded
distance since a certain reset.
Trip odometer counts up to a distance
of 2000 miles and then restarts at 0.
To reset, press SET/CLR for a few
seconds.
Range Range is calculated from current fuel
tank content and current
consumption. The display shows
average values.
After refuelling, the range is updated
automatically after a brief delay.
