Turn the light switch to the desired position ⇒ fig. 85:
When the ignition is
switched off
When the ignition is switched
on
/ Fog lights, low beams and
parking lights switched off.
Headlights off, daytime running
lights (DRL) on.
!54/ Orientation lighting may be
switched on.
Automatic headlight control ac-
tive; DRL.
 Parking lights switched on.
Low beams off. Parking lights
and DRL stay on.
Parking lights switched on.
 Low beams switched off –
parking lights switched on.
Low beams switched on.

Fog lights switched off. The
DRL may stay on for some
time.
Headlights and fog lights switched
on.

Fog lights:
The indicator light in the headlight switch or the instrument cluster shows that the fog lights are switched on.
x To switch on the fog lights : first turn the light switch to position , then pull the light switch out to the first detent.
x To switch off the fog lights, push the switch back in from the first detent. To then turn off the head-lights, turn the switch to position /.
Acoustic warning when lights are not switched off
In the following situations, a warning chime will sound if you take the key out of the ignition and open the driver door. This is to remind you that lights are still on.
x If the parking lights are switched on ⇒  Switching lights on and off.
x Light switch in position .

WARNING
Daytime running lights and parking lights are not bright enough to let you see ahead or be seen by others when it is dark.
x Always switch on the low beam headlights at dusk or when it is dark and whenever the weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright enough and will not let you see far enough ahead for safety, especially at dusk or when it is dark. Always switch on the low beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on, a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
x Even if automatic headlight control is switched on, the low beam headlights may still not come on by themselves in fog or heavy rain. You have to switch on the low beam headlights manually.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can tempo-rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
The length of time they stay on depends on the vehicle battery charge.
Lights and vision features

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination during cornering.
The Adaptive Front Lighting System can be switched on and off in the Infotainment System.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select the menu item Lights and vision from the list.
x Tap Adaptive front lighting system (AFS) to enable or disable this feature.
The feature is enabled when the check box in the Adaptive front lighting system (AFS) function key is checked =.
Lights with LED-technology
You cannot replace the LEDs. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. (DRL) are not bright enough to light up the roadway and be seen by other motorists. You will not be able to see far enough ahead for safety, especially at dusk or when it is dark. Always switch on the low beam headlights at dusk or when it is dark.
x If automatic headlight control (!54/) is switched on, the low beam headlights still may not be switched on in fog or heavy rain. You have to switch on the low beam headlights yourself.
x The taillights do not come on when the daytime running lights are switched on. A vehicle without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can tempo-rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

“Leaving
home” Action
– Switch on the ignition.

Background lighting in the outside mirrors
The background lighting in the outside mirrors lights up the area close to the doors while you are getting into or out of the vehicle. It is switched on when the vehicle is unlocked, a vehicle door is opened, or the “Coming home” or “Leaving home” feature is activated. If the vehicle is equipped with a light sensor, the background lighting in the outside mirrors is only switched on in darkness.
The lights stay on for about 10 seconds (lighting delay period). The “Coming home” and “Leav-ing home” features can be enabled and disabled in the Infotainment System.
If the “Coming home” feature is switched on and the driver door is opened, no acoustic warning will sound to alert that the light is still on.
Instrument panel lighting and headlight range adjustment

Fig. 86 Next to the steering wheel: Control for instrument cluster lighting.

WARNING
Headlights that are aimed too high because of the way the vehicle is loaded can blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Always adjust headlights to loading conditions so that the light cone do not blind others.
WARNING
If dynamic headlight range adjustment does not work properly or at all, the headlights could blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Have headlight range adjustment checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Interior and reading lights

Lights
up
Possible cause Proper response
F Rain sensor malfunction.
Switch ignition off and on again.
If the indicator light comes on
again and stays on, contact an
authorized Volkswagen dealer or
an authorized Volkswagen Ser-
vice Facility
U Windshield and/or rear win-
dow wiper malfunction.
Switch ignition off and on again.
If the indicator light comes on
again and stays on, contact an
authorized Volkswagen dealer or
an authorized Volkswagen Ser-
vice Facility
Y Windshield and rear window
washer fluid level too low.
Refill windshield washer reservoir
at the next opportunity

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 91 Operating the front windshield wiper.

x Press the CAR Infotainment button.
x Tap the Assist systems function key on the screen.
x Tap the function key Rain sensor to enable or disable the rain sensor.
If the box in the Rain sensor function key is checked =, the feature is enabled.
Possible reasons for changes in the way the rain sensor works
The rain sensor may misread what is happening in the detection zone of its sensitive rain-sensor
surface ⇒ fig. 95 (arrow) and not work for a number of reasons, which include:
x Worn out wiper blades: Worn out wiper blades may leave a film of water or wiping streaks; this can cause the wipers to run longer, to wipe more often, or to wipe continuously at high speed.
x Insects: Insects hitting the sensor cause wiping.
x Salt streaks: Salt streaks on the windshield from winter driving can cause wiping more often or continuously on glass that is almost dry.
x Dirt: Caked-on dust, wax, any other buildup on the windshield (lotus effect), or car-wash detergent residue can lower the rain sensor's sensitivity and cause it to react too slowly or not at all.
x Crack in the windshield: If a stone hits and chips the sensitive surface while the rain sensor is on, this will trigger a wiper cycle. After that, the rain sensor will recognize the change and recalibrate itself to respond to the smaller detection zone. Depending on the size of the chip, the sensor's reaction pattern may or may not change.
WARNING
The rain sensor cannot always recognize rain and activate the wipers.
x Switch the wipers on manually when water on the windshield reduces visibility.
Clean the sensitive area of the rain sensor regularly and check the wiper blades for wear or damage.
To remove wax and coats of polish safely, we recommend using an alcohol-based windshield cleaner.
Checking and refilling windshield washer fluid

Fig. 96 In the engine compartment: Cap of the windshield washer fluid reservoir.

x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Seat settings from the list.
x Check the check box in the Driver seat remote control key = function key.
x Shift the transmission into reverse.
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key that used to unlock the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment position is used again. For vehicles with memory seat
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into reverse gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forwards faster than about 10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base when moving the mirrors.
WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and seri-ous injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision. But vehicles or other objects seen in a convex mirror will look smaller and farther away than they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
x Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
x Never fold power mirrors in manually because doing so could damage the electrical drive.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by press-ing on the edges of the mirror surface.
