Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Roof antenna for:
– Mobile phone
– Navigation
(2) High-mounted brake light
(3) Rear window with:
– Rear window defroster
– Rear window wiper
(4) Taillights (on both left and right)
(5) Area of:
– Button to open the rear hatch
– Rear Assist camera and the Area View camera
– License plate lighting
(6) Radar sensors for Side Assist
(7) Sensors for rear Park Distance Control
(8) Threaded hole for the rear towing eye (on both left and right) behind covers
(9) Trailer hitch/ball mount receiver

Lower center console

Fig. 8 Overview of lower center console (4MOTION).
Key to fig. 8:
(1) Automatic transmission selector lever
(2) Button for:
– Electronic parking brake G
(3) Cup holders
(4) Storage compartment
– with 12 Volt socket
(5) Starter button for Keyless Access locking and starting system 34!24 – 34/0
(6) Storage compartment in the center armrest
(7) Button for:
– Driving with electric motor %--/$%
– Anti-slip regulation (ASR) m
(8) Rotary knob for setting drive mode (On-road / Off-road)

d Make sure that children are properly secured by a restraint system appropriate for their size and
weight ⇒  Child safety and child restraints.
d Properly adjust front seats, all head restraints and mirrors to the correct height ⇒  Adjusting the seating position.
d Wear shoes that give your feet a good grip and that give you a feel for the pedals.
d Make sure that the floormat on the driver side is properly fastened and cannot interfere with the pedals.
d Assume a proper seating position before the vehicle starts to move and keep this position while
driving. Make sure that all passengers do the same ⇒  Adjusting the seating position.
d Properly fasten your safety belt before driving the vehicle and wear your safety belt properly at all
times while driving. Make sure that all passengers do the same ⇒  Safety belts.
d Only transport as many passengers as there are seats and safety belts available.
d Never drive if your driving ability has been impaired, for example, by medication, alcohol, or illegal drugs.
d Never let passengers or phone calls distract you while driving and never take your attention off the road while using vehicle software or adjusting vehicle equipment or accessories.
d Always adapt your speed and driving style to visibility, weather, road, and traffic conditions.
d Always obey traffic laws and speed limits.
d On long trips make frequent rest stops – at least once every 2 hours.
d Secure animals in the vehicle with a system that corresponds to their weight and size.
WARNING
Always observe traffic rules and posted speed limits and use common sense. Your good judgment can mean the difference between arriving safely at your destination and being seri-ously injured in a crash or other kind of accident.
Regular service and maintenance of your vehicle is important both for operational and driving safety and to help prolong your vehicle's service life. Always follow the scheduled maintenance inter-
vals in the ⇒ Booklet Warranty and Maintenance, especially for changing the brake fluid. Hard use, frequent stop-and-go driving, driving in very dusty areas, trailer towing, and other factors may make it necessary to have the vehicle serviced more frequently. Ask an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for more information.
Driving in other countries

8 One or more brake lights
burned out.
See an authorized Volkswagen
dealer or an authorized
Volkswagen Service Facility.

Adaptive Front Lighting Sys-
tem (AFS) malfunction.
See an authorized Volkswagen
dealer or an authorized
Volkswagen Service Facility
 Headlight range adjustment
malfunction.
See an authorized Volkswagen
dealer or an authorized
Volkswagen Service Facility
 Parking lights switched on.
; One or more license plate
lights burned out.
See an authorized Volkswagen
dealer or an authorized
Volkswagen Service Facility.
Fog lights switched on.
Z

Function Action
Switching the DRL back on: – Release the parking brake.
– OR: Turn the light switch to the
position.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static cor-nering lights. On some models the static cornering lights may be integrated in the headlights. At speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the !54/ position) ⇒ fig. 85, they work only when the headlights have been automatically switched on. The static cornering lights do not come on when the headlight switch is in
the / position or when the fog lights themselves have been switched on ⇒  Switching lights on and off.
Automatic headlight control !54/
Automatic headlight control is a convenience feature only and cannot always recognize all driving situations.
If the light switch is in the !54/ position, the outside vehicle lighting and the instrument lighting are
automatically switched on at dusk/nightfall and off in normal daylight in the following situations ⇒ :

Automatic activation: Automatic deactivation/change to
daytime running lights:
If the low-light sensor registers
darkness, for example when driving
through a tunnel.
If sufficient brightness is registered.
If you drive faster than about
87 mph (140 km/h) for several se-
conds.
If you drive slower than about
40 mph (65 km/h) for several se-
conds.
If the rain sensor recognizes heavy
rain and switches the windshield
wipers on.
If the windshield wipers have not
moved for several minutes.

WARNING
Heavy loads will influence the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can cause loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that a change in the center of gravity also changes the way your vehicle handles:
– Always distribute the load as evenly as possible.
– Secure heavy objects properly as far forward in the luggage compartment as possible.
– Always tie down heavy items securely with suitable straps using the tie-downs in the luggage compartment.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt your speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Drive especially carefully and accelerate gently.
x Always accelerate and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Stowing luggage

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal injury during hard braking or sharp steering or in an accident. Loose items can also be struck and thrown through the passenger compartment by the front airbags if they inflate. To help reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in the luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so that they cannot move into the deployment zone of a side or front airbag during a sudden braking, in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on the shelf behind the rear seat bench, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle interi-or and stow them securely in the luggage compartment.
WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and increases braking distances. Heavy loads which are not properly stowed or secured in the vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the rear axle as possible and secure them with appropriate straps to the tie-downs provided.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings, which are printed on the Safety Compliance Certification Label located on the door jamb of the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave differently.
x Always adapt your speed and driving style to accommodate your payload and its weight distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid sud-den braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
x The defroster heating wires or antenna in the rear window can be damaged by objects that rub against them.
x The antenna wiring in the side windows can be damaged by items rubbing against it.
The ventilation slots between the rear window and the luggage compartment cover must not be blocked so that stale air can escape from the vehicle.

Headlight settings
Towing a trailer can raise the front end of the vehicle enough for the low beams to blind other road users. Use the headlight range adjustment feature to lower the light cones as required. If your vehicle does not have headlight range adjustment, have the headlights adjusted by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Vehicles with Xenon headlights self-adjust to vehicle load and do not need manual adjustment.
Special towing considerations
x If the trailer has an overrun brake, apply the brakes gently at first and then firmly. This helps to prevent sudden brake shock and helps prevent trailer wheels from locking up.
x Due to the combined towing weight including the higher gross vehicle weight, the stopping distance is longer.
x Before driving downhill, especially on hills that are long or steep, shift into a lower gear so that the engine helps to brake the vehicle. Otherwise, the brake system could overheat and might fail.
x The vehicle's center of gravity and, in turn, the vehicle's handling, will change because of the trailer load and the increased combined towing weight of the vehicle and trailer.
x Weight distribution is especially bad if the towing vehicle is empty and the trailer is loaded. If you absolutely must drive with this combination, drive with extra care and at a reduced speed.
Starting off with a trailer on hills
Depending on how steep the hill is and the combined towing weight, a parked vehicle with trailer can roll backwards when you first start moving.
When starting off with a trailer on a hill:
x Depress and hold the brake pedal.
x Put the transmission in Drive (D).
x Press the G button once to deactivate the electronic parking brake ⇒ page 411, Braking and parking.
x Pull and hold the G button to hold the vehicle and trailer with the electronic parking brake ⇒  Braking and parking.
x At the same time, release the brake pedal and gradually depress the accelerator. Do not release the G button until the engine starts to move the vehicle forward. If your vehicle has an automatic transmission, you can also depress and hold the brake pedal for added braking and then let up on the brake pedal when you feel that the vehicle “wants” to move forward.
x Drive ahead slowly.
