2015 VOLKSWAGEN TIGUAN Owner´s Manual

Color Current strength in amps
Yellow 20
White or clear 25
Green 30
Orange 40

Opening the fuse box in the instrument panel
x Open storage compartment and pull back firmly in the direction of the arrow ⇒ fig. 200.
Opening the fuse box in the engine compartment
x Open the engine hood

Fig. 203 Removing or inserting a fuse using the plastic tweezers.

Replacing light bulbs

WARNING
Improper replacement of burned out headlights and other light bulbs can cause serious personal injury.
x Stop! Always read and heed the WARNINGS before doing any work in the engine
compartment ⇒  Working in the engine compartment. The engine compartment of any motor vehicle is a potentially dangerous area, and work in this area can lead to serious personal injury.
x HID – High Intensity Discharge (Xenon) get power from a high voltage source that can cause severe personal injury and even death if handled improperly.
x H7/H15 bulbs and HID – High Intensity Discharge (Xenon) are under high pressure and can explode if handled improperly.
x Always let a burned out light bulb cool down before replacing it.
x Never replace a light bulb unless you are familiar with all of the necessary procedures. In particular, never remove a headlight unless you know exactly how to carry out the job and have the correct tools and light bulbs.
x If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID – High Intensity Discharge (Xenon) lamps and H7/H15 bulbs replaced by a qualified technician.
x Do not touch the glass of light bulbs with your bare hands. Fingerprints left on the bulb evaporate due to the heat when the bulb is switched on and cause the reflector to “cloud”.
x There are sharp edges on and around the headlight housing in the engine compartment and the rear light housing. Wear hand protection if you replace bulbs.
NOTICE
After replacing a headlight bulb or other light bulb, always make sure that the rubber covers or plastic caps have been properly and securely reinstalled to help prevent water from getting into the electrical connections and headlight housing and damaging the electrical system.
Indicator light

WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Failure of a single LED within a taillight is not indicated. However, the  indicator light will come on if all LEDs fail.
Information on light bulb replacement

WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
NOTICE
Always insert and remove lamps carefully to avoid damage to the vehicle paint or to other parts of the vehicle.
Replacing light bulbs in the Halogen headlight

Fig. 204 In the engine compartment: Cover 1 on the left headlight for the low beam bulb holder 3 and cover 2 for the parking light bulb holder 4, turn signal bulb holder 5 and high beam or daytime running light bulb 6.

Only perform these steps in the specified order:
fig. 204 Low beam headlight Parking light Turn signal High beam headlight or daytime running light
4. Turn the bulb holder (3) B counterclockwise until it stops and remove it toward the rear with the bulb.
Unclip the bulb holder (4) B upward out of the guide and remove it toward the rear with the bulb.
Unclip the parking light bulb holder (4) B upward out of the guide and remove it toward the rear with the bulb. Turn the turn signal bulb holder (5) B counterclockwise until it stops and remove it toward the rear with the bulb.
Turn the bulb (6) B counterclockwise until it stops and remove it toward the rear.
5. If necessary, press the locking mechanism on the bulb holder and pull the bulb straight out of the bulb holder.
6. Replace the burned out light bulb with a new bulb of the same type.
7. Reinsert the bulb holder (3) B into the headlight and turn it clockwise until it stops.
Reinsert the bulb holder (4) B into the headlight and clip it into the guide.
Reinsert the turn signal bulb holder (5) B into the headlight and turn it clockwise until it stop. Insert the parking light bulb holder (4) B into the headlight and clip it into the guide.
Reinsert the bulb (6) B into the headlight and turn it clockwise until it stops.
8.
Install the cover (1) A on the back of the headlight (retainer vertical) and turn it clockwise until it stops.
Install the rubber cover (2) A.

The illustrations show the left headlight assembly from the rear. The right headlight assembly is the mirror image of the left headlight assembly.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Replacing light bulbs in the HID-High Intensity Discharge (Xenon)
headlight

Fig. 205 In the engine compartment: Cover 1 on the left headlight for the turn signal bulb holder 2 and the cornering light bulb holder 3.
