2015 VOLKSWAGEN PASSAT roof

Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Rear window:
– Rear window defroster
(2) High-mounted brake light
(3) Taillights (on both left and right)
(4) Luggage compartment release
(5) License plate lights
(6) Roof antenna

Symbols on the roof console and sun visor

Symbol Meaning
*   s  Interior and reading lights
 c h Power sunroof
• > • 3-button module.for vehicles with Car-NetTM
1 2 3 HomeLink® Universal Transmitter

NOTICE
Volkswagen is not responsible for vehicle damage caused by inferior-quality or malicious application software, poorly programmed application software, insufficient wireless service reception, data loss during transmission or misuse of mobile devices.
3-button module

Fig. 19 In the roof console: 3-button module to access Volkswagen Car-Net service operators

x OR: The luggage compartment lid is opened.
x OR: The vehicle is mechanically unlocked with the vehicle key.
Convenience functions
x For convenience closing of all power windows and the power sunroof, keep your finger on the
door handle locking surface ⇒ fig. 41 (B) on the outside of the door handle until all windows and/or the power sunroof have closed. All turn signals blink once to confirm that the windows and power sunroof are completely closed.
x Take your finger off the door handle locking surface (B) to cancel the function. If you release the door handle locking surface (B) on the outside of the door handle and then touch the unlocking sur-
face (A) on the inside of the door handle right away, all windows start to open (safety function)

x Remove the cover cap from the concealed lock cylinder on the driver door ⇒  Manually unlocking and locking the driver door.
x Turn the vehicle key bit in the lock of the driver door to the closing position and hold it there ⇒  Power locking system. The power sunroof now closes. Release the vehicle key in order to stop the process.
x On vehicles with Keyless Access, using the door handle sensors ⇒  Power locking system.
Convenience closing first closes the windows and then the power sunroof. All turn signals blink once to confirm that the windows and power sunroof are closed.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children, remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power win-dows for several minutes after the ignition is switched off as long as the driver or front pas-senger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power windows and keep them from being opened and closed.
If the power windows malfunction, the one-touch feature, as well as pinch protection will not work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away.
Power window pinch protection

WARNING
Without pinch protection, power windows will close with enough force to cause serious per-sonal injury.
x Always be careful when closing power windows.
x Always make sure that no one is in the way when overriding pinch protection to close power windows!
x Pinch protection cannot prevent fingers or other parts of the body from being pressed against the window frame; injuries may result.
Pinch protection is also active during convenience closing of the windows and the power sunroof
⇒  Power windows – features.

Power sunroof

Opening and closing the power sunroof

Fig. 50 In the headliner: Rotary switch for the power sunroof. (A) Turn the rotary switch to slide the sunroof open or closed. (B) Press or pull the switch to tilt open or to close.
