2015 VOLKSWAGEN PASSAT CC multi function display

– Intermittent operation for windshield wipers z
– “One-tap wiping” x
– Windshield wiper U
– Automatic wipe/wash for windshield W
(5) Multi-function steering wheel controls:
– Volume setting for radio, navigation system notifications, or
telephone calls & – '
– Mute switching for radio or activation of voice control 
– Display Phone main menu or accept telephone calls -
– Audio, Navigation

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside
air temperature is above freezing.
If you use the outside temperature display to tell you about
frost conditions, remember that roads can even ice over at
temperatures above +39 °F (+4 °C). Always remember: even if
the “snowflake symbol” (icy road warning) is not displayed,
there could still be black ice on the road.
Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
The instrument cluster displays and their arrangement may vary
depending on the vehicle model and engine. For displays without
warning and information messages, malfunctions are only signaled
with indicator lights.
If there are multiple warning messages, the symbols are dis-
played for several seconds in order of importance. The symbols are
displayed until the cause has been corrected.

Calibrating the compass
In order to calibrate the compass, you need a valid compass zone for
the location and enough room to drive in a circle.
Switch on the ignition.
Select the Settings menu followed by the Compass and Calibrate
menu items.
Confirm the Please drive a full circle to calibrate message by
pressing the /+ button on the multi-function steering wheel, and then
drive in a complete circle at about 6 mph (10 km/h).
During calibration, CAL is shown in the instrument cluster display.
The calibration is complete when the compass direction is displayed.
Service reminder display

Push the /+ button (⇒ fig. 13) on the right side of the multi-function
steering wheel until a main menu appears in the instrument cluster
display. For a list of main menus, see ⇒  Main menu.
Push buttons # or ∃ to move to another main menu, and push the
arrow up and down buttons * and + to navigate inside the current
main menu. For example, in the Settings main menu, press the ar-
row down button + to navigate to the MFI data submenu.
Displaying a submenu
Press the /+ button ⇒ fig. 13 to display submenu items. For in-
stance, after scrolling to MFI data in the Settings main menu, press
the /+ button to display items available under the MFI data submenu.
Selecting a setting
Some menus are used to select settings for certain features. Push
the /+ button (⇒ fig. 13) to select a setting.
Use the arrow up and down buttons * and + on the multi-function
steering wheel to navigate through the available options.
The selected menu item is located between the 2 horizontal lines.
There may also be a triangle () on the right.
Push the /+ button to select the setting.
Returning to the main menu
Via menu: Use the arrow down button + to select Back and then
press the /+ button ⇒ fig. 13.
For operation with multi-function steering wheel: Press E.
Driver assistance systems button

Fig. 14 In the turn signal and high beam lever: Driver assistance sys-
tems button.

Menu Function See
Vehicle
status
Current warning and information
messages.
This menu item is only displayed
when warning or information
messages are available. The
number of available messages is
shown in the display. Example:
1/1 or 2/2.

Settings Includes the Convenience and
Lights & Vision submenus, as
well as many settings such as
time, speed warning for winter
tires, language, and units.

MFI menu (Multi-Function Indicator)

Display Function
Av. consumption
--.- l/100 km
(toggle) is displayed once the vehicle has been
driven about 330 feet (100 m). Until then, dash-
es appear instead of a number. The value dis-
played is updated every 5 seconds.
Range  -- mi Estimated distance in miles (km) that the vehicle
can go with the fuel left in the tank the way you
are currently driving. Takes account of the cur-
rent fuel consumption, among other things. Range  -- km
Route -- mi Distance driven in miles (km) per trip memories
1 and 2 (toggle).
Route -- km
Average speed
-- mph
Average speed on trips per trip memories 1 and
2 (toggle). Displayed once the vehicle has been
driven about 300 feet (100 m). Until then, dash-
es may appear instead of a number. The value
displayed is updated every 5 seconds.
Average speed
-- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
Oil temperature Current engine oil temperature (digital display;
3.6 liter engine only).
Speed warning
--- mph
When the set speed (from 20–155 mph or 30–
250 km/h) is exceeded, an acoustic warning
sounds and a visual message may also appear
in the instrument cluster display. Speed warning
--- km/h

Switching between the displays
Use the arrow up and down buttons (* and +) on the multi-
function steering wheel.

Storing speed for the speed warning
Navigate to MFI > Speed warning (Speed warning -- mph or
Speed warning -- km/h) display.
Press the /+ button to save the current speed and to activate the
warning.
If the speed is not right, press buttons * or + on the multi-function
steering wheel to set a different speed within about 5 seconds. Then
press the /+ button a second time or just wait a few seconds. The
speed is saved and the warning is activated.
To deactivate, toggle to --- mph or --- km/h and press the /+ but-
ton. The set speed is deleted.
Manually erasing trip memory 1 or 2
Navigate to MFI > Route.
Select the memory to be erased.
Press the /+ button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data to enable displays you
want to be available under the MFI menu in the instrument cluster
display. The units in which data is displayed can also be changed ⇒ 
Settings menu
Settings menu

For vehicles with the 3.6 liter engine, the engine oil temperature can
be displayed in the Volkswagen Information System MFI menu ⇒  MFI
menu (Multi-Function Indicator).
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Engine oil specifications
