x Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a
dry cloth ⇒ .
x Remove snow with a brush.
x Remove ice with deicer spray ⇒ .
NOTICE
x Never use abrasive cleaning agents to clean the camera lens.
x Never remove snow or ice on the camera lens with warm or hot water. This can damage the camera lens.
Operation

Fig. 140 Rear View Camera system display (may vary depending on vehicle equipment).

Function Action with the ignition on
Switch off the display manually:
Press a function selection button on the radio or the navi-
gation system ⇒ Booklet Radio or ⇒ Booklet Navigation
system.
OR: Tap the O function button on the screen.
Show the display again: Shift out of Reverse (R), then shift back into Reverse (R).

Parking

Fig. 141 On the screen: Static orientation lines for the parking space behind the vehicle.

Parking using the Rear View Camera system

Step Action:
1. The requirements for parking and maneuvering with the Rear View Camera system
must be fulfilled ⇒ page 255.
2. Position the vehicle in front of the parking space (2) ⇒ fig. 141 A.
3. Shift into Reverse (R).
4. Reverse slowly and steer the vehicle B so that the lateral yellow orientation lines lead into the parking space (2).
Pay attention to the message in the display: Always make sure it is safe to
back up! ⇒  on page 254
5. Align the vehicle in the parking space B so that the yellow orientation lines are parallel with the parking space (3).
6. Stop the vehicle C before (or at the very latest, when) the horizontal yellow line reaches the rear boundary, for example, a curb (4).

NOTICE
Smaller objects up to about 20 inches (50 cm) from the rear of the vehicle will not be detected by the camera and could result in vehicle damage.

Blind Spot Monitor with Rear Traffic Alert

NOTICE
x The radar sensors in the rear bumper can be damaged or become misaligned in low-speed impacts and parking maneuvers. The system can switch itself off or may be impaired as a result.
x Always keep the rear bumper clean and free of snow and ice so that the radar sensors can function properly. Do not cover the radar sensor area.
x The rear bumper may only be painted with vehicle paint that is approved by Volkswagen. Other paints may impair the function of the Blind Spot Monitor or cause it to malfunction.
x Sunlight may reduce the visibility of the indicator light in the outside mirror.
If the system does not function as described in this chapter or if your vehicle was involved in a collision, do not use the Blind Spot Monitor with Rear Traffic Alert. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to have the system checked.
Indicator lights

WARNING
Failure to heed warning and indicator lights and instrument cluster text messages can result in a collision and serious personal injury.
x Never ignore warning and indicator lights or text WARNINGS.
x Always heed warning and indicator lights and take action where necessary.
NOTICE
Failure to heed warning and indicator lights or text WARNINGS can result in vehicle damage.
Blind Spot Monitor

Fig. 142 In the outside mirrors: Indicator lights for the Blind Spot Monitor.

Fig. 143 Rear of the vehicle: Radar sensor areas.

mirror A informs you about traffic to the left, and the indicator light in the passenger side outside mirror B informs you about traffic to the right of your vehicle.
Tinting on the side windows or aftermarket tinting films can interfere with the indicator lights in the outside mirrors or cause false readings.
Keep the glass in the outside mirrors clean and free of snow and ice, and do not cover the mirrors with stickers or other objects.
Radar sensors
The radar sensors are behind the rear bumper on the left and right ⇒ fig. 143. They are not visible from outside the vehicle. They monitor an area about 21 yards (20 meters) behind the vehicle as well as the blind spots on the left and right sides of the vehicle. The monitored area next to the vehicle is about one lane wide.
The width of the lane is not detected individually on each road, but is preprogrammed into the system. Because of this, the indicators may be incorrect when driving on narrow roads or driving in the center of two lanes. Likewise, vehicles that are two lanes away from you or stationary objects such as guard rails may also be detected and cause a false warning.
Driving situations

Fig. 144 A: Driving situation when passing with traffic behind your vehicle. B: Blind Spot Monitor indicator light in the driver side mirror.

Fig. 145 A: Driving situation when passing and merging into the lane. B: Blind Spot Monitor indicator light in the passenger side mirror.

The Blind Spot Monitor only works at speeds above about 9 mph (15 km/h). The green indicator light 9 in the instrument cluster display switches on automatically when the system is active. The system and indicator light switch off automatically when the vehicle speed drops below about 6 mph (10 km/h).
Physical and system limitations
In certain situations, the Blind Spot Monitor may not interpret the traffic situation correctly. These situations may include:
x When driving in tight curves.
x When the width of the lanes differs.
x When there is a rise in the road surface.
x When there are poor weather conditions.
x When certain types of equipment are on the side of the road, such as high or offset guard rails.
Rear Traffic Alert

Fig. 146 Rear Traffic Alert: Monitored area around the vehicle that is backing out of a parking space.
