2015 VOLKSWAGEN GOLF SPORTWAGEN lock

x To close, fold the luggage compartment floor sections to the rear and place them on the supports.
Opening and closing front storage compartment or removing the luggage compartment floor
x Open the rear hatch, if necessary.
x To open the storage compartment or remove the luggage compartment floor, turn the two latch-
es⇒ fig. 99 B (magnified view) a quarter turn (90°) in the direction of the arrow (position (2)).
x Pull the recessed handle in the luggage compartment floor ⇒ fig. 99 A and lift the floor upward (arrow).
x Fold all luggage compartment floor sections to the front or lift the folded luggage compartment floor up and out of the luggage compartment.
x To insert the luggage compartment floor, make sure that the two latches ⇒ fig. 99 B (magnified view) are in position (2).
x Place the folded luggage compartment floor in the side supports at the very front of the luggage compartment.
x To close the storage compartment, fold the luggage compartment floor sections to the rear and place them on the supports.
x Turn the two latches⇒ fig. 99 B (magnified view) a quarter turn (90°) against the direction of the arrow (position (1)).
Raising the luggage compartment floor
x Pull the recessed handle in the luggage compartment floor ⇒ fig. 99 A and lift the floor upward (arrow).
x Fit the outer edges of the rear luggage compartment floor section into the recesses on the supports
⇒ fig. 100 A (magnified view, arrow).
Extending the luggage compartment downward
x Turn the two latches ⇒ fig. 99 B (magnified view) a quarter turn (90°) in the direction of the arrow (position (2)).
x Pull the recessed handle in the luggage compartment floor ⇒ fig. 99 A and lift the floor upward (arrow).
x Fold all luggage compartment floor sections to the front or lift the folded luggage compartment floor up and out of the luggage compartment.
x If necessary, lift out the side walls of the side storage compartments and set them aside.
x Pull the front luggage compartment floor support ⇒ fig. 100 B (1) upward in the direction of the arrow and remove it from the luggage compartment.
x Unlock both retaining pins ⇒ fig. 100 B (2) (magnified view) by turning them a quarter turn (90°) in the direction of the arrow and lifting them out.
x Place the retaining pins outside the luggage compartment.
x Lift the two side luggage compartment floor supports ⇒ fig. 100 B (3) at the rear in the direction of the arrow and pull them out of the front mountings to the rear.
x Remove the luggage compartment floor supports from the luggage compartment.
x Place the folded luggage compartment floor at the very front of the luggage compartment.
x Fold and place the luggage compartment floor sections to the rear.
x If necessary, install the side walls from the side storage compartments in the holders on the lug-gage compartment trim.
x Safely stow away the removed luggage compartment floor supports ⇒ fig. 100 B (1), (3) and the
retaining pins ⇒ fig. 100 B (2).

NOTICE
Never attach a trailer to the vehicle or leave it attached to the vehicle when the trailer is sup-ported by a trailer jack or blocks. Various things (such as a change in trailer or vehicle load or a flat tire) can lower or raise the vehicle. This subjects the trailer hitch and the trailer to strong forces that can damage the vehicle or the trailer.
If the engine is switched off and accessories in the trailer are on and use electricity from the vehicle, the vehicle battery will be drained as long as the electrical systems of the vehicle and the trailer are connected.
Loading the trailer

x Unlock the parking brake and gently release it while holding the unlock button. At the same time, release the brake pedal and gradually depress the accelerator and, for a manual transmission, let out the clutch until you can feel the car moving forward. If applicable, follow the instructions for the Hill
Hold feature ⇒  Starting assistance systems.
x Do not release the parking brake lever until the engine starts to move the vehicle forward. If your vehicle has an automatic transmission, you can also depress and hold the brake pedal for added braking and then let up on the brake pedal when you feel that the vehicle “wants” to move forward.
x Drive ahead slowly.
WARNING
Improper trailer towing can cause loss of vehicle control and serious personal injury.
x Driving with a trailer and carrying heavy or bulky items changes the way the vehicle han-dles and increases the distance it needs to stop safely.
x Always watch what is happening up ahead and around you. Brake earlier than you would if you were not towing a trailer.
x Always adapt your speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Reduce your speed even more than you otherwise would when going downhill and under unfavorable load, weather, or wind conditions.
x Drive especially carefully and accelerate gently. Always avoid sudden maneuvers and hard braking.
x Be especially careful when passing other vehicles.
x Reduce speed immediately if the trailer shows even the slightest sign of swaying.
x Never try to stop the swaying by accelerating.
x Always obey speed limits. In some areas speed limits for vehicles towing trailers are lower than for vehicles without trailers.
Ball mount

Fig. 103 Dimensions of the ball mount support.

The receiver used requires both a ball mount and a ball that meet special requirements regarding geometry and size. This applies to both the height of the ball above the surface where it attaches
⇒ fig. 103 (A), and the pin-to-ball distance (B).
These dimensions are important because they help determine the way that the forces that arise during towing are applied to the receiver and its attachments to the vehicle. If you buy a ball mount and ball, make sure that they meet the following specifications.
Ball mount dimensions
x The drop height (A) from the center of the ball to the center of the hole for the securing pin on the ball mount must be at least 1 inch (25.4 mm) and at most 27/8 inches (73 mm).
x The pin-to-ball distance (B) from the center of the ball to the center of the hole for the securing pin on the ball mount must be no more than 7 inches (178 mm).
x The ball diameter must be no more than 11/4 inches (32 mm).
A ball mount and ball combination that does not meet these specifications can damage your vehicle
and may even fail in use ⇒ .
Never install a “weight distributing” or “load equalizing” trailer hitch on your vehicle. The vehicle is not
designed for this kind of trailer hitch ⇒ .
WARNING
An improperly installed or unsuitable trailer hitch can cause the trailer to separate from the towing vehicle and result in a major accident with serious personal injuries.
x Have any trailer hitch retrofit or other work on a trailer hitch done by a qualified workshop.
CAUTION
The ball mount sticks out behind the rear bumper and can cause injury to pedestrians and cyclists.
x To reduce the risk of injury in rear-end collisions, and the risk to pedestrians and cyclists when the vehicle is parked, always remove the ball carrier when you are not towing a trailer.
NOTICE
x Never use a ball larger than 11/4 inches (32 mm) on your vehicle. The vehicle was not de-signed to tow heavier trailers with a receiver larger than the specified ball. The increased loads can damage the attachment points for the trailer hitch.
x Never use an adapter to increase the size of the trailer hitch receiver from 11/4 inches (32 mm) to 2 inches (50.8 mm) or more to tow a trailer that is heavier than the maximum per-missible trailer weight that your vehicle can tow.
x You can use an adapter if required for the proper installation of a bicycle rack or other similar carrier as long as the maximum weight limits are observed. When using bicycle racks or similar carriers, make sure that the rear lights are not blocked.
x Only use trailer hitches that are approved by the hitch manufacturer for your vehicle and model.

The design of the wheel bolts is matched to the factory-installed wheels. If different wheels are in-stalled, wheel bolts with the right length and bolt head shape must be used. This helps to ensure that
wheels can be mounted securely and that the brakes will work correctly ⇒  Changing a wheel.
In most cases, you cannot use wheel bolts from a different vehicle. Even wheel rims from the same model may not fit properly.
Tires and wheel rims approved by Volkswagen have been matched precisely to your vehicle model and contribute considerably to good handling and safe vehicle performance.
Tightening torque
Wheel bolts must always be installed with the correct tightening torque ⇒ page 424, Changing a wheel. The required tightening torque for your vehicle's wheel bolts is 88 ft-lbs (120 Nm). After chang-ing a wheel, the bolt torque must be checked as soon as possible with an accurate torque wrench. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Wheel rims with bolted rim rings
Wheel rims with bolted rim rings have several parts. The parts are bolted together with special screws in a special process. This helps to ensure that they will work properly, prevent leaks, run true and safely. Damaged wheel rims must be replaced, and you must never take them apart or try to repair them yourself. Have an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
repair them for you ⇒ .
Wheel rims with bolted decorative covers
Light-alloy wheels may have interchangeable decorative covers attached to the rim with self-locking screws. If you want to replace damaged wheel covers, contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
WARNING
Using improper or damaged wheel rims can affect driving safety, cause accidents and severe personal injury.
x Use only wheel rims approved for the vehicle.
x Regularly check wheel rims for damage and replace them if necessary.
WARNING
Improper loosening and tightening of the bolts on wheel rims with bolted rim rings can cause accidents and severe personal injury.
x Never loosen bolted connections on wheel rims with bolted rim rings.
x Have all work on wheel rims with bolted rim rings performed by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
New and replacement tires

WARNING
Some kinds of cigarette lighters can be lit unintentionally, or crushed causing a fire that can result in serious burns and vehicle damage.
x Always make sure that there are no lighters in the seat tracks or near other moving parts before adjusting the seats.
x Before closing a storage compartment, always make sure that no cigarette lighter can be activated, crushed, or otherwise damaged.
x Never leave a cigarette lighter in a storage compartment, on the instrument panel, or in other places in the vehicle. Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. High temperatures could cause the cigarette lighter to catch fire.
NOTICE
x The defroster heating wires or antenna in the rear window can be damaged by hard or sharp things on the shelf below the rear window.
x Do not keep any food, medicine, or other items sensitive to heat or cold in the vehicle. They can be damaged or made unusable by heat or cold.
x Things that are made of transparent materials (such as eyeglasses, magnifying glasses, or transparent suction cups on the windows) can magnify sunlight and damage the vehicle.
The ventilation slots beneath the side windows in the luggage area must not be blocked so that stale air can escape from the vehicle.
Storage compartments in the doors

Fig. 111 In the driver door: Storage compartment.

LED display on the outlet ⇒ fig. 126
Red flashing light: Malfunction such as over-
current or overheating cutoff

Opening and closing the 115 Volt and 12 Volt outlet covers in the luggage compartment
To open: Lift the outlet cover ⇒ fig. 125 (1) or (2) in the direction of the arrow (magnified view).
To close: The outlet covers (1) and (2) close automatically.
Overheating cutoff
The inverter in the 115 Volt outlet shuts off automatically above a certain temperature. The shutoff prevents overheating in case of excessive power consumption of connected devices or at high ambi-ent air temperatures. The 115 Volt outlet can only be used again after a cool-down period.
The plug on the connected device must first be removed and then reinserted before using the 115 volt outlet again after the cool-down period. This prevents the connected electrical device from being switched on accidentally.
DANGER
Improper use of the 115 Volt outlet can cause electrical shock, burns, and severe personal injury.
x Never spill liquids on the socket.
x Never plug an adapter or an extension cord into the 115 Volt outlet. Otherwise, the inte-grated childproof lock is switched off and the outlet is live.
x Never stick anything that conducts electricity, such as a knitting needle, into the contacts of the 115 Volt outlet.
NOTICE
x Follow the manufacturer's instructions for connected devices!
x Never exceed the maximum power consumption, or the entire vehicle electrical system may become damaged.
x 115 Volt outlet:
– Do not connect devices or plugs which are too heavy, such as a grid power supply adapter or cord, directly onto the outlet.
– Do not connect lamps containing fluorescent tubes.
– Only connect devices to the outlet with voltage consistent with the voltage of the outlet.
– For devices with a high starting current, the integrated over-current shutoff will prevent them from being switched on. In this case, disconnect the power supply from the device and reconnect after about 10 seconds.
Some devices may not work very well when connected to the 115 Volt outlet due to low wattage.
Unshielded devices may interfere with radio reception or the vehicle's electrical system.

WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. The engine can be started and vehicle systems such as the power windows can be operated, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked with the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
x Never remove the key from the ignition switch while the vehicle is moving or rolling to a stop. The steering wheel will lock and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position other than Park (P) when the ignition is switched off can drain the vehicle battery.
On automatic transmission vehicles, the vehicle key can be removed from the ignition switch only when the transmission is in Park (P). You may have to press the release button on the transmis-sion selector lever to put the lever into Park (P).
Starter button

Fig. 128 In the lower center console: Starter button for the Keyless Access system.
