2015 VOLKSWAGEN GOLF SPORTWAGEN key

WARNING
Unintended vehicle movement can cause serious personal injury.
x Do not depress the brake or clutch pedals when switching on the ignition, as the engine could otherwise start immediately.
WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. Children or unauthorized per-sons may use it to lock the vehicle, start the engine, and operate vehicle systems such as the power windows, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked using the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
In vehicles with a diesel engine and Keyless Access, the engine start may be delayed if the engine has to be preheated.
If the ignition is switched on or the engine is running and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the engine and turn off the ignition before leaving and locking the vehicle from the outside.
Starting the engine

Please perform these steps only in the order listed.
Step Vehicles without Keyless Ac-
cess
Vehicles with Keyless Access
3.
Only for vehicles with a diesel
engine: To preheat the glow
plug, turn the vehicle key to po-
sition ⇒ fig. 127 (1). The indica-
tor light D will come on in the
instrument cluster.
–
4. Turn the vehicle key to posi-
tion ⇒ fig. 127 (2) – do not de-
press the accelerator pedal.
Briefly press the starter button
⇒ fig. 128 – do not depress the
accelerator pedal. An authorized
vehicle key must be inside the
vehicle in order to start the en-
gine.
5. When the engine starts, release
the vehicle key.
When the engine starts, release
the starter button.
6. If the engine does not start,
switch off the ignition and start
again after about 1 minute.
If the engine does not start,
switch off the ignition and start
again after about 1 minute. Use
the emergency start feature if
necessary
7. Release the parking brake when you are ready to start driving

WARNING
Never leave the vehicle unattended with the engine running, especially when it is in gear. The vehicle could move suddenly or some other unexpected event could occur, resulting in prop-erty damage, fire, or personal injury.
WARNING
“Starting fluids” can explode and can cause a “run-away” vehicle condition.
x Never use starting assist fluids.

Please perform these steps only in the order listed.
Step Vehicles without Keyless Ac-
cess Vehicles with Keyless Access
6. Manual transmission: Shift into 1st gear (vehicle on flat surface or
pointing uphill) or Reverse (R) (vehicle pointing downhill).
7.
Removing the vehicle key from
the ignition switches off electrical
equipment and activates the
steering column lock.
Opening the doors switches off
electrical equipment and acti-
vates the steering column lock.

WARNING
Never stop the engine before the vehicle has come to a complete stop. You can lose control of the vehicle, crash, and be seriously injured.
x The airbags and safety belt pretensioners will not work when the ignition is switched off.
x The brake booster does not work when the engine is not running. More brake pedal pres-sure will be needed to stop the vehicle.
x The power steering system does not work when the engine is not running, and you will need more force to steer the vehicle.
x Never remove the key from the ignition switch or turn off the ignition with the starter but-ton while the vehicle is moving or rolling to a stop. The electronic steering column could suddenly lock, and you would not be able to steer the vehicle.
NOTICE
If the vehicle has been driven hard for a long time, the engine could overheat when it is stopped. To reduce the risk of engine damage, let the engine idle in Neutral for about 2 minutes before you switch off the ignition.
If the ignition is switched on or the engine is running and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the engine and turn off the ignition before leaving and locking the vehicle from the outside.
On vehicles with automatic transmissions, the vehicle key can only be removed from the ignition when the transmission is in Park (P).
After the engine has been switched off, the radiator fan in the engine compartment may keep running for several minutes, or may start running after the vehicle has been parked for a while, even if the ignition is switched off and the vehicle key has been removed. The radiator fan shuts off automati-cally when the engine has cooled down enough.

WARNING
Parking improperly can cause serious personal injury.
x Never remove the key from the ignition switch or turn off the ignition with the starter but-ton while the vehicle is moving or rolling to a stop. The electronic steering column could suddenly lock, you would not be able to steer, and you could lose control of the vehicle, crash, and seriously injure yourself and others.
x Never park the vehicle where the hot exhaust system or catalytic converter could ignite flammable materials, such as brush, leaves, dry grass, spilled fuel, etc.
x Always apply the parking brake when parking your vehicle.
x Improper use of the parking brake can seriously injure you and your passengers.
x Never use the parking brake to slow down the vehicle when it is moving, except in an emergency. The stopping distance is much longer because only the rear wheels are braked. Always use the foot brake to stop the vehicle.
x Never activate the throttle manually from the engine compartment when the engine is running and the automatic transmission is in gear. The vehicle will start to move as soon as the engine speed increases even if the parking brake is on.
x Never leave children or anyone who cannot help themselves behind in the vehicle. They could release the parking brake and move the gear selector lever or gear shift, which could cause the vehicle to start moving. This can lead to a crash and serious personal injuries.
x Always take the key with you when you leave the vehicle. The engine can be started and vehicle systems such as the power windows can be operated, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked with the remote control vehicle key, trapping passengers in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
NOTICE
x Always be careful when you park in areas with parking barriers or high curbs. These vary in height and could damage your bumper and related parts if the front of your vehicle hits a barri-er or curb that is too high while you are getting into or out of a parking spot. To help prevent damage, stop before the tires of your vehicle touch a parking barrier or curb.
x Always be careful when you enter a driveway or drive up or down steep ramps or over curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).
Warning and indicator lights

x Apply the parking brake to help prevent the vehicle from moving ⇒  Parking brake.
x Switch on the ignition.
x Switch on the Infotainment system (if not already on) ⇒  Infotainment system.
x Shift into Reverse (R).
x Tap the function key.
x Adjust the desired settings in the menu.
Camera

Fig. 145 In the rear hatch: Location of the camera.

Key for displays ⇒ fig. 146
Symbol Meaning
O Close the current display.
Depending on vehicle equipment: Switch the PDC
sound on or off.
Setting display: brightness, contrast, color.
Depending on vehicle equipment: Display PDC.

Switching the camera on and off.
The Rear View Camera system switches on and off automatically.

Function Action with the ignition on
Vehicles without Park
Distance Control
Vehicles with Park Dis-
tance Control
Switch on the
display automati-
cally:
Shift into Reverse (R).
Switch off the
display automati-
cally:
Switch off the ignition.
OR: Drive forward faster than 6 mph (10 km/h) or for
longer than 10 seconds.
OR: Shift out of Reverse
(R) and wait about
10 seconds.
OR: Shift out of Reverse
(R) (display switches off
immediately).
Switch off the
display manually:
Press one of the Infotainment system buttons or tap
the O function key on the screen.

OR: Tap the function key
.

Function Action with the ignition on
Vehicles without Park
Distance Control
Vehicles with Park Dis-
tance Control
The PDC full screen mode
is displayed
Show the display
again:
Shift out of Reverse (R), then shift back into Reverse
(R).

OR: Tap the function key
Z.

Applicable only in Canada
Operation

Fig. 147 In the Infotainment system: Rear View Camera system display (display may vary depending on vehicle equipment).

Switching the camera on and off.
The Rear View Camera system switches on and off automatically.

Function Action with the ignition on
Switch on the
display automati-
cally:
Shift into Reverse (R).
Switch off the
display automati-
cally:
Switch off the ignition.
OR: Drive forward faster than 6 mph (10 km/h) or for
longer than 10 seconds.
OR: Shift out of Reverse (R) and wait about
10 seconds.
Switch off the
display manually:
Press one of the Infotainment system buttons or tap
the O function key on the screen.
Show the display
again:
Shift out of Reverse (R), then shift back into Reverse
(R).

Parking

Fig. 148 On the screen: Orientation lines for the parking space behind the vehicle. A: Searching for a parking space, B: Backing into the parking space, C: Maneuvering.
