Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal con-venience settings, and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Manual controls

Fig. 157 In the center console: Manual air conditioning controls.

Button/Knob More information: Manual air conditioning ⇒ fig. 157
K Air distribution to the upper instrument panel outlets.
O Air distribution to the upper instrument panel outlets and
footwells.
L Air distribution to the footwells.
u Air distribution to the windshield and footwells.
=
Rear window defroster: Works only when the engine is
running and switches off automatically after 10 minutes or
less.
3 Air recirculation mode
A, [ Buttons for seat heating
!

Climatronic controls

Fig. 158 In the center console: Climatronic controls.

Button/Knob More information: Climatronic ⇒ fig. 158.
L Air distribution to the footwells.
Air is directed upward.
=
Rear window defroster: Works only when the engine is
running and switches off automatically after 10 minutes or
less.
3 Manual and automatic air recirculation
A, [ Buttons for seat heating
!

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions, and serious personal injury.
x Never switch off the fan for a long time because no fresh air will enter the passenger com-partment.
When adjusting fan speed manually, LEDs in the knob (2) light up to indicate the current fan speed. During automatic regulation, the fan speed is not indicated.
Operation via the Infotainment system

Operation

Special considerations
When it is very hot and humid outside, water condensation can drip from the air conditioner evapora-tor and form a puddle under the vehicle. This is normal and does not indicate a leak.
The climate control system adjusts the passenger compartment temperature as fast as possible considering the outside temperature.
Due to residual moisture in the air conditioner, the windshield may fog up after the engine is started. Switch on the windshield defroster to help evaporate the condensation as quickly as possible.
The air coming out of the vents flows through the passenger compartment and through the air vents in the luggage compartment. Do not cover these slots with clothing or other things.
Air vents

Fig. 159 In the instrument panel: Air vents.

Air recirculation
