2015 VOLKSWAGEN BEETLE Owners Manual

Front passenger side overview

Fig. 9 Overview of the front passenger side.
Key to fig. 9:
(1) Passenger front airbag location in the instrument panel (approximate)
(2) Opening handle for the upper glove compartment (if equipped)
(3) Air vents  –

Symbols on the roof console

Symbol Meaning
* / s   Interior and reading lights
g c • Power sunroof

/ a 3-button module for vehicles without Car-NetTM ⇒ Booklet Mobile
Phone Package.
• > • 3-button module for vehicles with Car-NetTM

Instrument cluster

Additional instruments

Fig. 12 Above the center console: Engine oil temperature indicator 1, stopwatch 2, and boost pressure indica-tor 3.

– Speed-dependent stopwatch mode (TIME-SINCE-START). The stopwatch starts automati-cally with an audible chime when you begin driving. An LED in the stopwatch lights up to in-
dicate that this mode is active ⇒ .
– Digital clock display (CLOCK).
If the ignition is switched off while the timing function is active, the display will remain active for about 2 hours. If the timing function was not active when the ignition was switched off, the digital clock dis-play will turn off after about 30 seconds.
The display will remain on for about 2 hours if you press the E

Type of notification Warning light Explanation
Priority 2 warning light Yellow Light flashing or continuously lit – sometimes with acoustic warnings. Malfunctions or low operating fluid levels may cause vehicle damage
and vehicle breakdown ⇒ . Check malfunction as soon as possible. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance if necessary.

Odometer displays
The odometer indicates the total distance driven by the vehicle.
The trip odometer shows the distance driven since the last time the trip odometer was reset. The last digit indicates 1/10 mile (100 meters).
Outside temperature display
At outside temperatures below about +39 °F (+4 °C), a “snowflake symbol” appears in the display. The symbol flashes at first, then stays on until the outside temperature rises above +43 °F (+6 °C)
⇒ .
When the vehicle is not moving or when you are driving at very low speeds, the temperature displayed may be slightly higher than the actual outside temperature.
The measurement range is from -40 °F (-40 °C) to +122 °F (+50 °C).
Selector lever positions (automatic transmission)
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive (D) and
Sport Drive (S), as well as in Tiptronic® mode ⇒  Shifting.
Gear recommendation
When the vehicle is moving, a fuel economy gear recommendation may appear in the instrument
cluster display ⇒  Shifting.
Engine identification code
Press and hold the /./
