2015 VOLKSWAGEN BEETLE Owner´s Manual

Turn the thumbwheel to the desired position (2):
Position Vehicle loading condition5
– Front seats occupied and an empty luggage compartment.
1 All seats occupied and an empty luggage compartment.
1.5 All seats occupied and a fully loaded luggage compartment
2 Only the driver seat occupied and a fully loaded luggage compartment.
3 –

WARNING
Headlights that are aimed too high because of the way the vehicle is loaded can blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Always make sure the headlights are adjusted to loading conditions so that they do not blind others.
Interior and reading lights

Fig. 75 Thumbwheel next to the steering wheel.

Button Function
s
Door contact switch - center position. Interior lights go on automatically when the vehicle is unlocked, a door is opened, or the vehicle key is removed from the ignition. The lights go out about 20 seconds after you close the doors. They also go out when you lock the vehicle or switch on the ignition.
* Reading light on or off.

Glove and luggage compartment lights
The glove and luggage compartments may have lights that come on automatically when they are opened and go off when they are closed.
Ambient (background) lighting
When the ignition and the headlights are switched on, ambient lights in the roof console light up.
There may also be footwell lighting.
Ambient (background) lighting in the doors
Some vehicles are equipped with ambient lighting in the doors that comes on when the ignition or headlights are switched on.

Turn the thumbwheel to the desired position ⇒ fig. 75:
Position Ambient lighting color
R Red
B Blue
W White
– Ambient lighting in the doors switched off

The interior and reading lights go out when you lock the vehicle or a few minutes after you re-move the vehicle key from the ignition. This helps to prevent unnecessary drain on the vehicle battery.

Sun protection

Windshield made of heat-insulating glass

Fig. 77 Heat-reflective windshield with communications window (blue shaded area).

Windshield wipers and washer

Lights up Possible cause Proper response
Y Not enough windshield washer fluid. Refill windshield washer reservoir at the next opportunity

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 78 Operating the front windshield wipers.

Move the lever to the desired position ⇒ :
(F) W Pull the lever toward the steering wheel to activate the windshield washers, then release.

NOTICE
To help prevent damage to the wiper blades and the wiper motor when it is cold outside, al-ways make sure that blades are not frozen to the windshield before operating the wipers. Using the service position can be helpful in cold weather so the wipers do not freeze to the wind-
shield ⇒  Windshield wiper service position.
x If the ignition is switched off while the wipers are running, the wipers will continue at the same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recom-mends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can be scratched.
The windshield wipers work only if the ignition is switched on.
The intermittent wiping for the front windshield depends on the driving speed. The higher the speed, the faster the wipers move.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
Windshield wiper functions

Wiper performance in different situations:
During intermittent wiping: Speed-dependent interval control: The higher the vehicle speed, the faster the wipers move.

Heated washer nozzles
Some vehicles are equipped with heated washer nozzles. The heating thaws frozen washer nozzles, but not the fluid supply hoses. When the ignition is switched on, the heat applied to the washer noz-zles is automatically regulated depending on the outside air temperature.
If there is something on the windshield, the wiper will try to wipe it away. If it continues to block the wiper, the wiper will stop moving. Remove the obstacle and switch the wiper on again.
Windshield wiper service position

Fig. 79 Windshield wiper in service position.
