2015 TOYOTA SIENNA wipers

3
1
9 8
7
6 4 3
2
SIENNA_OM_01999-08001_(U)
10
5
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 176
Inside rear view mirror....... 178
Outside rear view mirrors ............................. 180
3-5. Opening, closing the windows and moon roof
Power windows ................. 183
Quarter windows ............... 186
Moon roof .......................... 188
4-1. Before driving Driving the vehicle ............. 192
Cargo and luggage............ 201
Vehicle load limits ............. 207
Trailer towing (with towing package) ..... 208
Dinghy towing.................... 222
4-2. Driving procedures Engine (ignition) switch (vehicles without a
smart key system) ........... 223
Engine (ignition) switch (vehicles with a smart
key system) ..................... 226
Automatic transaxle........... 231
Turn signal lever................ 235
Parking brake .................... 236 4-3. Operating the lights
and wipers
Headlight switch ................ 237
Automatic High Beam ........ 242
Fog light switch .................. 247
Windshield wipers and washer ............................. 248
Rear window wiper and washer ............................. 252
4-4. Refueling Opening the fuel tank cap................................... 254
4-5. Using the driving support systems
Cruise control .................... 257
Dynamic radar cruise control.............................. 261
Intuitive parking assist ....... 273
Rear view monitor system ............................. 281
Driving assist systems ....... 291
PCS (Pre-Collision System) ........................... 296
BSM (Blind Spot Monitor) ........................... 303
4-6. Driving tips Winter driving tips .............. 311
4Driving

15Pictorial index
SIENNA_OM_01999-08001_(U)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 311
To prevent freezing (windshield wiper de-icer)
*. . . . . . . . . . . . P. 408
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . P. 462
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 254
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 254
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 596
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 600
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 311
Checking/rotation/tire pressure warning system . . . . . . . . . P. 488
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . P. 562, 564
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 475
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 475
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 596
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 587
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 548
Headlights/parking lights/ daytime running lights
*. . . . . . . P. 237
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Fog lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 247
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 235
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 231
5
6
7
8
Light bulbs of the exterior lights for driving
(Replacing method: P. 509, Watts: P. 602)
*: If equipped
9
10
11
12
13
14
15

191
SIENNA_OM_01999-08001_(U)
4Driving
4-1. Before drivingDriving the vehicle ............. 192
Cargo and luggage ........... 201
Vehicle load limits ............. 207
Trailer towing (with towing package) ..... 208
Dinghy towing ................... 222
4-2. Driving procedures Engine (ignition) switch (vehicles without a
smart key system) ........... 223
Engine (ignition) switch (vehicles with a smart
key system) ..................... 226
Automatic transaxle........... 231
Turn signal lever................ 235
Parking brake .................... 236 4-3. Operating the lights
and wipers
Headlight switch ................ 237
Automatic High Beam ....... 242
Fog light switch ................. 247
Windshield wipers and washer ............................ 248
Rear window wiper and washer ............................ 252
4-4. Refueling Opening the fuel tank cap .................................. 254
4-5. Using the driving support systems
Cruise control .................... 257
Dynamic radar cruise control ............................. 261
Intuitive parking assist....... 273
Rear view monitor system ............................ 281
Driving assist systems ...... 291
PCS (Pre-Collision System)........................... 296
BSM (Blind Spot Monitor)........................... 303
4-6. Driving tips Winter driving tips ............. 311

237
SIENNA_OM_01999-08001_(U)
4-3. Operating the lights and wipers
4
Driving
Headlight switch
Turning the end of the lever turns on the lights as follows:
The illustration is intended as an example.
The headlights can be operate d manually or automatically.
Operating instructions
U.S.A.Canada
The headlights, side marker, parking lights, daytime running
lights (if equipped) and so on turn on and off automatically
(when the engine switch is in the “ON” position [vehicles
without a smart key system] or IGNITION ON mode [vehi-
cles with a smart key system]).
The side marker, parking, tail, license plate, daytime run-
ning lights (if equipped) and instrument panel lights turn on.
The headlights and all lights listed above (except daytime
running lights) turn on.
1
2
3

238
SIENNA_OM_01999-08001_(U)
4-3. Operating the lights and wipers
*1: Vehicles without a daytime running light system
*2: Vehicles with a daytime running light system
With the headlights on, push
the lever away from you to turn
on the high beams.
When the light switch is in
position, the Automatic High Beam
system will be activated. (P. 242)
Pull the lever toward you to the
center position to turn the high
beams off.
Pull the lever toward you and release it to flash the high beams
once.
You can flash the high beams with the headlights on or off.
*1
(U.S.A.)
Off.
*2
(U.S.A.)
The daytime running light system is off.
(Canada)The daytime running light system is on.
Turning on the high beam headlights
4
1
2

SIENNA_OM_01999-08001_(U)
2394-3. Operating the lights and wipers
4
Driving
The level of the headlight aim can be adjusted according to the num-
ber of passengers and the loading condition of the vehicle.
Raises the level of the head-
lights
Lowers the level of the head-
lights
■Guide to dial settings
Manual headlight leveling dial (v ehicles with discharge head-
lights)
1
2
Occupancy and luggage load conditionsDial position
OccupantsLuggage load2WD
modelsAWD
models
DriverNone00
Driver and front
passengerNone00
Driver, front passenger and all passengers in the second seat
None00
All seats occupiedNone10.5
All seats occupiedFull luggage loading11
DriverFull luggage loading00

240
SIENNA_OM_01999-08001_(U)
4-3. Operating the lights and wipers
■Daytime running light system (if equipped)
●Bulb type: To make your vehicle more visible to other drivers, the headlights
turn on automatically (at a reduced intensity) whenever the engine is started
and the parking brake is released. Daytime running lights are not designed
for use at night.
For the U.S.A.: Daytime running lights can be turned off by operating the
headlight switch.
LED type: To make your vehicle more visible to other drivers, the daytime
running lights turn on automatically whenever the engine is started and the
parking brake is released. Daytime running lights are not designed for use
at night.
For the U.S.A.: Daytime running lights can be turned off by operating the
headlight switch.
● Compared to turning on the headlights, the daytime running light system
offers greater durability and consumes less electricity, so it can help improve
fuel economy.
■ Headlight control sensor
The sensor may not function properly if an
object is placed on the sensor, or anything
that blocks the sensor is affixed to the
windshield.
Doing so interferes with the sensor
detecting the level of ambient light and
may cause the automatic headlight sys-
tem to malfunction.

SIENNA_OM_01999-08001_(U)
2414-3. Operating the lights and wipers
4
Driving
■Automatic light off system
Vehicles without a smart key system
● When the headlights are on: The headlights and tail lights turn off 30 sec-
onds after a door is opened and closed if the engine switch is turned to the
“ACC” or “LOCK” position. (The lights turn off immediately if on the
key is pressed after all the doors are locked.)
● When only the tail lights are on: The tail lights turn off automatically if the
engine switch is turned to the “ACC” or “LOCK” position and the driver’s
door is opened.
To turn the lights on again, turn the engine switch to the “ON” position, or turn
the light switch off once and then back to the
or .
Vehicles with a smart key system
● When the headlights are on: The headlights and tail lights turn off 30 sec-
onds after a door is opened and closed if the engine switch is turned to
ACCESSORY mode or turned off. (The lights turn off immediately if
on the key is pressed after all the doors are locked.)
● When only the tail lights are on: The tail lights turn off automatically if the
engine switch is turned to ACCESSORY mode or turned off and the driver’s
door is opened.
To turn the lights on again, turn the engine switch to IGNITION ON mode, or
turn the light switch off and then back to or .
■ Light reminder buzzer
Vehicles without a smart key system
A buzzer sounds when the engine switch is turned to the “LOCK” position, the
key is removed and the driver’s door is opened while the lights are turned on.
Vehicles with a smart key system
A buzzer sounds when the engine switch is turned off and the driver’s door is
opened while the lights are turned on.
■ Customization
Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features: P. 625)
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than necessary when the engine is not
running.
