3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 176
Inside rear view mirror....... 178
Outside rear view mirrors ............................. 180
3-5. Opening, closing the windows and moon roof
Power windows ................. 183
Quarter windows ............... 186
Moon roof .......................... 188
4-1. Before driving Driving the vehicle ............. 192
Cargo and luggage............ 201
Vehicle load limits ............. 207
Trailer towing (with towing package) ..... 208
Dinghy towing.................... 222
4-2. Driving procedures Engine (ignition) switch (vehicles without a
smart key system) ........... 223
Engine (ignition) switch (vehicles with a smart
key system) ..................... 226
Automatic transaxle........... 231
Turn signal lever................ 235
Parking brake .................... 236 4-3. Operating the lights
and wipers
Headlight switch ................ 237
Automatic High Beam ........ 242
Fog light switch .................. 247
Windshield wipers and washer ............................. 248
Rear window wiper and washer ............................. 252
4-4. Refueling Opening the fuel tank cap................................... 254
4-5. Using the driving support systems
Cruise control .................... 257
Dynamic radar cruise control.............................. 261
Intuitive parking assist ....... 273
Rear view monitor system ............................. 281
Driving assist systems ....... 291
PCS (Pre-Collision System) ........................... 296
BSM (Blind Spot Monitor) ........................... 303
4-6. Driving tips Winter driving tips .............. 311
4Driving

TABLE OF CONTENTS6
SIENNA_OM_01999-08001_(U)6-4. Using the other interior
features
Other interior features ....... 435 • Sun visors ..................... 435
• Vanity mirrors................ 435
• Clock ............................. 436
• Conversation mirror ...... 436
• Power outlets ................ 437
• Armrests ....................... 440
• Assist grips ................... 441
• Rear side sunshades .... 442
• Grocery bag hooks ....... 443
Garage door opener .......... 444
Compass ........................... 449
Safety Connect.................. 453
7-1. Maintenance and care Cleaning and protecting the vehicle exterior .......... 460
Cleaning and protecting the vehicle interior ........... 463
7-2. Maintenance Maintenance requirements ................... 466
General maintenance ........ 469
Emission inspection and maintenance (I/M)
programs ......................... 472 7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ...................... 473
Hood .................................. 475
Positioning a floor jack....... 477
Engine compartment ......... 478
Tires................................... 488
Tire inflation pressure ........ 496
Wheels............................... 499
Air conditioning filter .......... 501
Wireless remote control/ electronic key battery ...... 503
Checking and replacing fuses ................................ 506
Light bulbs ......................... 509
8-1. Essential information Emergency flashers ........... 528
If your vehicle has to be stopped in an
emergency....................... 529
8-2. Steps to take in an emergency
If your vehicle needs to be towed .......................... 531
If you think something is wrong............................... 535
Fuel pump shut off system ............................. 536
If a warning light turns on or a warning buzzer
sounds ............................. 537
If a warning message is displayed ......................... 546
If you have a flat tire (vehicles with
run-flat tires) .................... 562
7Maintenance and care
8When trouble arises

16Pictorial index
SIENNA_OM_01999-08001_(U)
■Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223, 226
Starting the engine/changing the modes . . . . . . . . . . . . . P. 223, 226
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . P. 529
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . P. 578
Warning messages
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 558
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 231
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 231
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 531
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . P. 580
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 87
Reading the meters/adjusting the instrument panel light . . . . . . P. 87
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 82
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 537
1
2
3

301-1. For safe use
SIENNA_OM_01999-08001_(U)
To release plate “B”, press the
release button on buckle “B”.
To release plate “A”, insert the
key (P. 104) or plate “B” into
the hole on buckle “A”.
Retract the belt slowly when
releasing and stowing the seat
belt.
Insert the seat belt plates into
the holder on the roof as
shown.
Releasing and stowing the seat belt (for the third center seat)
Buckle “B”
Release
button
Plate “B”
1
Buckle “A”
Plate “A”
Plate “A”
Plate “B”
Buckle “A”
O
Plate “A”
Plate “B”
P

391-1. For safe use
SIENNA_OM_01999-08001_(U)
1
For safety and security
Your vehicle is equipped with ADVANCED AIRBAGS designed based
on the US motor vehicle safety standards (FMVSS208). The airbag
sensor assembly (ECU) controls airbag deployment based on infor-
mation obtained from the sensors et c. shown in the system compo-
nents diagram above. This informat ion includes crash severity and
occupant information. As the airbags deploy, a chemical reaction in
the inflators quickly fills the airbag s with non-toxic gas to help restrain
the motion of the occupants.
WARNING
■ SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
● The driver and all passengers in the vehicle must wear their seat belts
properly.
The SRS airbags are supplemental devices to be used with the seat belts.
● The SRS driver airbag deploys with considerable force, and can cause
death or serious injury especially if the driver is very close to the airbag.
The National Highway Traffic Safety Administration (NHTSA) advises:
Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm)
of inflation, placing yourself 10 in. (250 mm) from your driver airbag pro-
vides you with a clear margin of safety. This distance is measured from
the center of the steering wheel to your breastbone. If you sit less than 10
in. (250 mm) away now, you can change your driving position in several
ways:
• Move your seat to the rear as far as you can while still reaching the ped- als comfortably.
• Slightly recline the back of the seat.
Although vehicle designs vary, many drivers can achieve the 10 in. (250
mm) distance, even with the driver seat all the way forward, simply by
reclining the back of the seat somewhat. If reclining the back of your
seat makes it hard to see the road, raise yourself by using a firm, non-
slippery cushion, or raise the seat if your vehicle has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the air-
bag toward your chest instead of your head and neck.
The seat should be adjusted as recommended by NHTSA above, while
still maintaining control of the foot pedals, steering wheel, and your view
of the instrument panel controls.

411-1. For safe use
SIENNA_OM_01999-08001_(U)
1
For safety and security
WARNING
■SRS airbag precautions
● Do not sit on the edge of the seat or
lean against the dashboard.
● Do not allow a child to stand in front of
the SRS front passenger airbag unit or
sit on the knees of a front passenger.
● Do not allow the front seat occupants to
hold items on their knees.
● Do not lean against the door, the roof
side rail or the front, side and rear pil-
lars.
● Do not allow anyone to kneel on the
passenger seat toward the door or put
their head or hands outside the vehicle.

118
SIENNA_OM_01999-08001_(U)
3-2. Opening, closing and locking the doors
■When all the doors are locked with the wireless remote control or key
The doors cannot be unlocked with the door lock switch.
The door lock switch can be reset by unlocking all the doors with the wireless
remote control or key.
■ Using the mechanical key (vehicles with a smart key system)
The doors can also be locked and unlocked with the mechanical key.
(P. 581)
■ Conditions affecting the operation of the smart key system or wireless
remote control
Vehicles without a smart key system
The wireless remote control function may not operate normally in the follow-
ing situations:
● Near a TV tower, radio station, electric power plant, airport or other facility
that generates strong radio waves
● When carrying a portable radio, cellular phone or other wireless communi-
cation devices
● When multiple wireless keys are in the vicinity
● When the wireless key is in contact with, or is covered by, a metallic object
● When a wireless key (that emits radio waves) is being used nearby
● When the wireless key has been left near an electrical appliance such as a
personal computer
● If window tint with a metallic content or metallic objects is attached to the
rear window
● Vehicles with AUTO ACCESS SEAT: If the wireless remote control of the
AUTO ACCESS SEAT is operated simultaneously, the AUTO ACCESS
SEAT may not operate properly.
For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.

SIENNA_OM_01999-08001_(U)
1193-2. Opening, closing and locking the doors
3
Operation of each component
Vehicles with a smart key system
The smart key system uses weak radio waves. In the following situations, the
communication between the electronic key and the vehicle may be affected,
preventing the smart key system and wireless remote control from operating
properly. (Way of coping P. 581)
● When the electronic key battery is depleted
● Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise
● When carrying a portable radio, cellular phone, cordless phone or other
wireless communication devices
● When the electronic key is in contact with, or is covered by the following
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
● When multiple electronic keys are in the vicinity
● When another wireless key (that emits radio waves) is being used nearby
● When carrying or using the electronic key together with the following
devices that emit radio waves
• Another vehicle’s electronic key
• A wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
● If window tint with a metallic content or metallic objects are attached to the
rear window
● Vehicles with AUTO ACCESS SEAT: If the wireless remote control of the
AUTO ACCESS SEAT is operated simultaneously, the AUTO ACCESS
SEAT may not operate properly.
For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.
■ Customization
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features: P. 622)
