3-2. Opening, closing and locking the doors
■Power sliding doors
●If the power sliding door outside handle is pulled while the power sliding
door is opening or closing, the door will reverse the operation direction.
● During opening operation:
Stroking the power sliding door handle forward will reverse the direction and
start closing.
Stroking the handle backward will continue opening.
During closing operation:
Stroking the power sliding door handle backward will reverse the direction
and start opening.
Stroking the handle forward will continue closing.
● The power sliding doors can be opened/closed manually when the power
sliding door function is canceled with the main switch.
● A buzzer sounds if you put the shift lever out of P with the engine switch in
the “ON” position (vehicles without a smart key system) or IGNITION ON
mode (vehicles with a smart key system) and the sliding door not completely
closed.
● Vehicles with AUTO ACCESS SEAT: If the AUTO ACCESS SEAT has not
been locked in place after being stowed, the right-hand sliding door will not
close and a beep will sound twice.
For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.
● In an emergency, power slide door operation can be stopped by any of the
following:
• Pulling the outside handle three consecutive times
• During opening operation, sliding the inside handle forward three consec-
utive times
• During closing operation, sliding the inside handle backward three con- secutive times
• Pressing the power sliding door switch three consecutive times
• Pressing the power sliding door button on wireless remote control three consecutive times ( P. 124)
After stopping, power sliding door brake function will be activated ( P. 127)
■ The situations in which the sliding door does not open completely
The left side sliding door does not open
completely when the fuel filler door is
opened.

156
SIENNA_OM_01999-08001_(U)
3-3. Adjusting the seats
■Removing the second center seat (if equipped)Pull the lock release strap
and fold down the second
center seatback.
Make sure that the head
restraint is in the lowest position.
Pull the lock release strap
under the seat to remove the
seat.
Retract the cushion leg.
Stow the seat in the storage
box of the luggage room
(cushion side first).
Engage the stow latch buckle
to hold the seat and tighten
the latch strap.
1
2
3

158
SIENNA_OM_01999-08001_(U)
3-3. Adjusting the seats
■Installing the second center seats (if equipped)Engage the rear pins with the
hooks.
Unfold the cushion leg and
push down on the seat to
engage the front lock.
Unfold the seatback and lock
it.
Make sure the seat is locked in
place by trying to shake the
seatback and lift up the seat
cushion.
■
Before folding the third seats Fold the outside head
restraints and lower the cen-
ter head restraint to the low-
est position ( P. 172), and
stow the seat belt buckles.
Stow the center seat belt. ( P. 3 0 )
1
2
3
Folding down the third seats (manual seats)
1
2

SIENNA_OM_01999-08001_(U)
1593-3. Adjusting the seats
3
Operation of each component
■Folding down the third seatbacks
Pull the “TO FOLD/LIFT SEAT-
BACK” strap and fold down the
seatback.
■Returning the third seatbacks
Pull the “TO FOLD/LIFT SEAT-
BACK” strap, and raise the
seatback and the outside head
restraints.
You can operate the power third seats when the shift lever is in P.
■Before folding the third seats Lower the center head
restraint to the lowest posi-
tion ( P. 172) and stow the
seat belt buckles.
Stow the center seat belt. ( P. 3 0 )
ITN13N047
Folding down the third seats (power seats)
1
2

160
SIENNA_OM_01999-08001_(U)
3-3. Adjusting the seats
■Folding down the third seatbacks
Press the folding/returning
switch.
■Returning the third seatbacks
Press the folding/returning switch, returning switch (P. 163) or
seatback angle adjustment switch ( P. 153).
Before stowing or returning third seat, remove any items from the floor
area to prevent interference with moving parts.
■Before stowing the third seats Lower the center head
restraint to the lowest posi-
tion ( P. 172), and stow the
seat belt buckles.
Stow the center seat belt. ( P. 3 0 )
Stowing the third seats (manual seats)
1
2

SIENNA_OM_01999-08001_(U)
1613-3. Adjusting the seats
3
Operation of each component
■Stowing the third seatsPull the handle to move the
seat rearward. Then push the
seat down.
The outside head restraints are
folded automatically.
Push the seat against the
floor.
Open the flaps.
■Before returning the third seats
Be sure to move the second seats forward from the rearmost posi-
tion, as they may interfere with the third seats returning operation.
1
2

162
SIENNA_OM_01999-08001_(U)
3-3. Adjusting the seats
■Returning the third seatsReturn the flaps.
Pull the handle and lift up the
seat rearward.
Push the seat forward and
then engage the front leg
locks.
Make sure the front and rear
legs are locked securely.
Raise the seatback and the outside head restraints. ( P. 158)
You can operate the power third seats when the shift lever is in P.
Before stowing or returning third seat, remove any items from the floor
area to prevent interference with moving parts.
■Before stowing the third seats Lower the center head
restraint to the lowest posi-
tion ( P. 172) and stow the
seat belt buckles.
Stow the center seat belt. ( P. 3 0 )
1
2
Stowing the third seats (power seats)
3
1
2

SIENNA_OM_01999-08001_(U)
1633-3. Adjusting the seats
3
Operation of each component
■Stowing the third seatsPress and hold the stowing
switch.
A beep sounds twice to indicate
the start of the operation. The
beep sounds again twice when
the operation is completed.
Open the flaps.
■Before returning the third seats
Be sure to move the second seats forward from the rearmost posi-
tion, as they may interfere with the third seats returning operation.
■Returning the third seatsReturn the flaps.
Press and hold the returning
switch until the seat cushion
is locked.
A beep sounds twice to indicate
the start of the operation. The
beep sounds again twice when
the seats are locked in folded-
down position. Make sure the
front and rear legs are locked
securely.
Raise the outside head restraints.
1
ITN13N056
2
1
2
