2015 TOYOTA SIENNA clock

520
SIENNA_OM_01999-08001_(U)
7-3. Do-it-yourself maintenance
■Rear turn signal lights (vehicles with LED type stop/tail lights)Remove the securing bolts
and remove the unit.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
1
2
3

SIENNA_OM_01999-08001_(U)
5217-3. Do-it-yourself maintenance
7
Maintenance and care
■Rear turn signal lights and stop/tail lights (vehicles with bulb
type stop/tail lights)
Remove the securing bolts
and remove the unit.
Unplug the connector while
pushing the lock release.
Turn the bulb base counter-
clockwise.Rear turn signal lights
Stop/tail lights
Remove the light bulb. Rear turn signal lights
Stop/tail lights
1
2
3
1
2
4
1
2

522
SIENNA_OM_01999-08001_(U)
7-3. Do-it-yourself maintenance
■Tail and back-up lightsRemove the back door trim
board.
Turn the bulb base counterclockwise.
Remove the light bulb.
1
2
Vehicles with bulb type
stop/tail lightsVehicles with LED type stop/tail
lights
Back-up light
Tail light Tail light
Back-up light
1
2
1
2
3
Vehicles with bulb type
stop/tail lightsVehicles with LED type stop/tail
lights
Back-up light
Tail light Tail light
Back-up light
1
2
1
2

SIENNA_OM_01999-08001_(U)
5237-3. Do-it-yourself maintenance
7
Maintenance and care
■License plate lightsRemove the back door trim
board.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
● Headlight low beams (discharge bulbs)
● Parking lights (LED type)
● Daytime running lights (LED type)
● Side turn signal light (if equipped)
● Stop/tail lights (LED type) and rear side marker lights
● High mounted stoplight
● Outer foot lights (if equipped)
1
2
3

5748-2. Steps to take in an emergency
SIENNA_OM_01999-08001_(U)
Pull strap to tighten and secure
tire.
Lay down the tire with the outer
side (valve stem) facing up, and
install the holding bracket.
Turn the jack handle clockwise
to raise the tire until the tire is in
the correct position as the jack
handle skips.
Stow the tools.5
Stowing the spare tire
Valve stem1
2
3

651Alphabetical index
SIENNA_OM_01999-08001_(U)
CareAluminum wheels.................. 461
Exterior ................................. 460
Interior................................... 463
Seat belts .............................. 463
Cargo capacity ......................... 207
Cargo hooks............................. 433
CD player
*................................ 337
Chains....................................... 312
Child restraint system ............... 56 Booster seats, definition ......... 57
Booster seats, installation ....... 68
Convertible seats, definition ............................... 57
Convertible seats, installation ............................ 66
Front passenger occupant
classification syst em............. 50
Infant seats, definition ............. 56
Infant seats, installation .......... 60
Installing CRS with LATCH anchors .............. 62, 64
Installing CRS with
seat belts .............................. 66
Installing CRS with top tether strap ............... 69, 70 Child safety ................................ 55
Airbag precautions.................. 39
Back door precautions .......... 138
Battery precautions........ 486,586
Child restraint system ............. 56
How your child should wear
the seat belt.......................... 32
Installing child restraints ......... 60
Moon roof precautions .......... 190
Power window lock switch .... 183
Power window precautions ... 185
Removed key battery
precautions......................... 505
Seat belt extender
precautions........................... 35
Seat belt precautions .............. 34
Seat heater precautions ....... 416
Sliding door child-protectors................... 125
Child-protectors ...................... 125
Cleaning
Aluminum wheels ................. 461
Exterior ................................. 460
Interior .................................. 463
Seat belts.............................. 463
Clock......................................... 436
Compass .................................. 449
Condenser................................ 483
Console box ............................. 424
Conversation mirror ................ 436
Cooling system........................ 481 Engine overheating............... 587
Cruise control
Cruise control ...................... 257
Dynamic radar cruise control ................................ 261
Cup holders ............................. 426
Curtain shield airbags............... 36
Customizable features ............ 617
C
*: Refer to “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”
