2015 TOYOTA SIENNA warning

SIENNA_OM_01999-08001_(U)
6119-1. Specifications
9
Vehicle specifications
■Temperature A, B, C
The temperature grades are A (the highest), B, and C, representing
the tire’s resistance to the generation of heat and its ability to dissi-
pate heat when tested under cont rolled conditions on a specified
indoor laboratory test wheel.
Sustained high temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive temperature can lead
to sudden tire failure.
Grade C corresponds to a level of performance which all passenger
car tires must meet under the Federal Motor Vehicle Safety
Standard No. 109.
Grades B and A represent higher le vels of performance on the labo-
ratory test wheel than the minimum required by law.
Warning: The temperature grades of a tire assume that it is properly
inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire
failure.

622
SIENNA_OM_01999-08001_(U)
9-2. Customization
■Door lock (P. 110, 581)
■Smart key system* and wireless remote control ( P. 105, 142)
*: If equipped
FunctionDefault settingCustomized
setting
Unlocking using a key Driver’s door
unlocked in
one step, all
doors unlocked in two steps All doors
unlocked in
one step ––O
Automatic door lock
Shifting the
shift lever to
position other than P
Off
O—O
Vehicle speed
is approxi-
mately 12 mph (20 km/h) or
higher
Automatic door unlockShifting the
shift lever to POff
O—ODriver’s door is opened
123
FunctionDefault settingCustomized setting
Operation signal (buzzer
volume) Level 7Off
O–O
Level 1 to 6
Operation signal
(Emergency flashers) On Off O – O
Time elapsed before the
automatic door lock func-
tion is activated if door is
not opened after being
unlocked 60 seconds
Off
O–O
30 seconds
120 seconds
Open door warning buzzer On Off – – O
123

SIENNA_OM_01999-08001_(U)
6279-2. Customization
9
Vehicle specifications
■Vehicle customization
●When the speed-detecting automatic door lock and shift-linked automatic
door lock are both on, the door lock operates as follows:
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door locking function will operate.
● When the smart key system is off, the entry unlock function cannot be cus-
tomized.
● When the doors remain closed after unlocking the doors and the timer acti-
vated automatic door lock function activates, signals will be generated in
accordance with the operation buzzer volume and operational signal
(Emergency flashers) function settings.
■ When customizing on the audio system screen
Stop the vehicle in a safe place, apply the parking brake, and shift the shift
lever to P. Also, to prevent battery discharge, leave the engine running while
customizing the features.
WARNING
■ During customization
As the engine needs to be running during customization, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect and enter the vehicle. This may lead to death or a serious health
hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while cus-
tomizing features.

628
SIENNA_OM_01999-08001_(U)
9-3. Initialization
Items to initialize
The following items must be initialized for normal system opera-
tion after such cases as the battery being reconnected, or main-
tenance being performed on the vehicle.
ItemWhen to initializeReference
Power sliding door
(if equipped) After reconnecting or changing the
battery
P. 128
Power back door
(if equipped) After reconnecting or changing the
battery
P. 137
Message indicating
maintenance is
required (U.S.A. only) After the maintenance is performed P. 467
Tire pressure
warning system
When changing the tire size
P. 489

647What to do if... (Troubleshooting)
SIENNA_OM_01999-08001_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 539)
●The brake system warning light is on
Is the parking brake released? (P. 236)
Depending on the situation, other types of warning buzzer may also sound.
( P. 537, 546)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 77)
To stop the alarm, turn the engine switch to the “ON” position (vehicles with-
out a smart key system) or IGNITION ON mode (vehicles with a smart key
system) or start the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( P. 546)
A warning buzzer sounds during driving
An alarm is activated and the horn sounds (if equipped)
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)

648What to do if... (Troubleshooting)
SIENNA_OM_01999-08001_(U)
●When a warning light turns on or a warning message is displayed, refer to
P. 537, 546.
●Vehicles with run-flat tires:
Slow down the vehicle, drive with extra caution, and take your vehicle
to the nearest Toyota dealer or authorized tire dealer as soon as possi-
ble to have the tire replaced. ( P. 562)
●Vehicles with a compact spare tire:
Stop the vehicle in a safe place and replace the flat tire with the spare
tire. ( P. 564)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 590)
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

649Alphabetical index
SIENNA_OM_01999-08001_(U)
Alphabetical index
A/C .................................... 404, 413Air conditioning filter ............. 501
Front automatic air
conditioning system ............ 404
Rear automatic air
conditioning system ............ 413
ABS (Anti-lock Brake System) .................................. 291
Function ................................ 291
Warning light ......................... 538
Warning message ................. 549
Active head restraint ............... 149
Active Torque Control 4WD system ........................... 291
Function ................................ 291
Warning message ......... 553, 554
Air conditioning filter .............. 501
Air conditioning system
Air conditioning filter ............. 501
Front automatic air conditioning system ............ 404
Rear automatic air conditioning system ............ 413 Airbags ....................................... 36
Airbag operating
conditions ............................. 45
Airbag precautions for your child......................... 39
Airbag warning light .............. 538
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............. 46
Curtain shield airbag precautions........................... 39
Front passenger occupant classification syst em ............ 50
General airbag
precautions........................... 39
Locations of airbags ............... 36
Modification and disposal of airbags ............... 44
Side and curtain shield airbags operating
conditions ............................. 46
Side and curtain shield airbags precautions .............. 39
SRS airbag instructions for Canadian owners .......... 633
SRS airbags ........................... 36
A

650Alphabetical index
SIENNA_OM_01999-08001_(U)
AlarmAlarm ...................................... 77
Warning buzzer..................... 537
Anchor brackets ........................ 60
Antenna Smart key system ................. 142
Radio .................................... 336
Anti-lock brake system
(ABS) ...................................... 291 Function ................................ 291
Warning light ......................... 538
Warning message ................. 549
Approach warning ................... 266
Armrest ..................................... 440
Assist grips .............................. 441
Audio input
*............................ 322
Audio system
*......................... 316
Antenna ................................ 336
A/V input port
*
Audio input*.......................... 322
Audio visual input
*
AUX port/USB port*............. 322
Blu-ray Disc™
*
CD player*............................ 337
DVD disc
*
DVD player*
HDMI port*
iPod*.................................... 343
MP3/WMA disc
*................... 337
Optimal use
*........................ 334
Portable music player
*......... 352
Radio
*.................................. 335
Rear seat entertainment
system
*
Steering wheel audio switch
*............................... 320
USB memory
*...................... 347
Audio visual input
*
Automatic High Beam ............. 242 Warning message ................. 554
Automatic light control system .................................... 240 Automatic transaxle
Automatic transaxle .............. 231
If the shift lever cannot be
shifted from P ..................... 580
S mode ................................. 232
AUX port
*................................. 322
Auxiliary box ........................... 430
A/V input port
*
Back door ................................. 132
Back-up lights Replacing light bulbs ............ 522
Wattage ................................ 602
Battery Battery checking ................... 484
If the vehicle has discharged battery.............. 583
Preparing and checking before winter ...................... 311
Warning light......................... 537
Warning message................. 551
Blind Spot Monitor (BSM) ....... 303
Bluetooth
®
Audio system*...................... 364
Hands-free system
*
(for cellular phone) ............. 366
Bottle holder ............................ 428
Brake Fluid ...................................... 483
Parking brake ....................... 236
Warning light......................... 537
Warning message......... 550, 554
Brake assist ............................. 291
Break-in tips............................. 193
Brightness control Instrument light control ........... 89
BSM (Blind Spot Monitor) ....... 303 Blind Spot Monitor
function............................... 306
Rear Cross Traffic Alert function............................... 308
B
