2015 TOYOTA SIENNA torque

5728-2. Steps to take in an emergency
SIENNA_OM_01999-08001_(U)
Remove any dirt or foreign mat-
ter from the wheel contact sur-
face.
If foreign matter is on the wheel
contact surface, the wheel nuts
may loosen while the vehicle is in
motion, causing the tire to come
off.
Install the tire and loosely
tighten each wheel nut by hand
by approximately the same
amount.
Tighten the wheel nuts until the
tapered portion comes into loose
contact with the disc wheel seat.
Lower the vehicle.
Firmly tighten each wheel nut
two or three times in the order
shown in the illustration.
Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
Stow the flat tire, tire jack and all tools.
Installing the spare tire
1
Tapered portion
Disc wheel
seatO
P
Q
R

600
SIENNA_OM_01999-08001_(U)
9-1. Specifications
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N,50 kgf) while the engine is running
*2: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N,30.6 kgf)
17-inch tires
18-inch tires
Brakes
Pedal clearance*12.99 in. (76 mm)
Pedal free play 0.04  0.24 in. (1  6 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake pedal travel*23  6 clicks
Fluid type SAE J1703 or FMVSS No.116 DOT 3
Steering
Free play Less than 1.2 in. (30 mm)
Tires and wheels
Tire sizeP235/60R17 100T
Tire inflation pressure
(Recommended cold tire
inflation pressure)Front:
35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Rear:
35 psi (240 kPa, 2.4 kgf/cm
2 or bar)
Wheel size 17 x 7J
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)
Tire size P235/55R18 99V, P235/55RF18 99T
Tire inflation pressure
(Recommended cold tire
inflation pressure)Front:
35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Rear:
35 psi (240 kPa, 2.4 kgf/cm
2 or bar)
Wheel size 18 x 7J
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)

SIENNA_OM_01999-08001_(U)
6019-1. Specifications
9
Vehicle specifications
19-inch tires
Compact spare tire (2WD models)
Tire sizeP235/50R19 99V
Tire inflation pressure
(Recommended cold tire
inflation pressure)Front:
36 psi (250 kPa, 2.5 kgf/cm2 or bar)
Rear:
36 psi (250 kPa, 2.5 kgf/cm
2 or bar)
Wheel size 19 x 7J
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)
Tire size T155/80R17 101M
Tire inflation pressure
(Recommended cold tire
inflation pressure)60 psi (420 kPa, 4.2 kgf/cm2 or bar)
Wheel size
17 x 4T
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)

649Alphabetical index
SIENNA_OM_01999-08001_(U)
Alphabetical index
A/C .................................... 404, 413Air conditioning filter ............. 501
Front automatic air
conditioning system ............ 404
Rear automatic air
conditioning system ............ 413
ABS (Anti-lock Brake System) .................................. 291
Function ................................ 291
Warning light ......................... 538
Warning message ................. 549
Active head restraint ............... 149
Active Torque Control 4WD system ........................... 291
Function ................................ 291
Warning message ......... 553, 554
Air conditioning filter .............. 501
Air conditioning system
Air conditioning filter ............. 501
Front automatic air conditioning system ............ 404
Rear automatic air conditioning system ............ 413 Airbags ....................................... 36
Airbag operating
conditions ............................. 45
Airbag precautions for your child......................... 39
Airbag warning light .............. 538
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............. 46
Curtain shield airbag precautions........................... 39
Front passenger occupant classification syst em ............ 50
General airbag
precautions........................... 39
Locations of airbags ............... 36
Modification and disposal of airbags ............... 44
Side and curtain shield airbags operating
conditions ............................. 46
Side and curtain shield airbags precautions .............. 39
SRS airbag instructions for Canadian owners .......... 633
SRS airbags ........................... 36
