2015 TOYOTA SIENNA load capacity

499
SIENNA_OM_01999-08001_(U)
7-3. Do-it-yourself maintenance
7
Maintenance and care
Wheels
When replacing wheels, care should be taken to ensure that they are
equivalent to those removed in load capacity, diameter, rim width and
inset
*.
Replacement wheels are available at your Toyota dealer.
*: Conventionally referred to as “offset”.
Toyota does not recommend using the following:
● Wheels of different sizes or types
● Used wheels
● Bent wheels that have been straightened
● Use only Toyota wheel nuts and wrenches designed for use with
your aluminum wheels.
● When rotating, repairing or changi ng your tires, check that the
wheel nuts are still tight after driving 1000 miles (1600 km).
● Be careful not to damage the aluminum wheels when using tire
chains.
● Use only Toyota genuine balance weights or equivalent and a plas-
tic or rubber hammer when balancing your wheels.
■When replacing wheels
The wheels of your vehicle are equipped with tire pressure warning
valves and transmitters that allow the tire pressure warning system to
provide advanced warning in the event of a loss in tire inflation pressure.
Whenever wheels are replaced, tire pressure warning valves and trans-
mitters must be installed. ( P. 489)
If a wheel is bent, cracked or heavily corroded, it should be
replaced.
Otherwise, the tire may separate from the wheel or cause a loss
of handling control.
Wheel selection
Aluminum wheel precautions

612
SIENNA_OM_01999-08001_(U)
9-1. Specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation
pressure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflat
ed pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended
inflation pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent
that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded
vehicle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weight The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy
duty battery, and special trim

SIENNA_OM_01999-08001_(U)
6139-1. Specifications
9
Vehicle specifications
RimA metal support for a tire or a tire and tube
assembly upon which the tire beads are
seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer’s designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity) The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity
Vehicle maximum load
on the tire The load on an individual tire that is deter-
mined by distributing to each axle its share of
the maximum loaded vehicle weight, and
dividing by two
Vehicle normal load
on the tire The load on an individual tire that is deter-
mined by distributing to each axle its share of
curb weight, accessory weight, and normal
occupant weight (distributed in accordance
with Table 1
* below), and dividing by two
Weather side The surface area of the rim not covered by the
inflated tire
Bead The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Bead separation A breakdown of the bond between compo-
nents in the bead
Bias ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at alternate
angles substantially less than 90 degrees to
the centerline of the tread
Carcass The tire structure, except tread and sidewall
rubber which, when inflated, bears the load
Chunking The breaking away of pieces of the tread or
sidewall
Cord The strands forming the plies in the tire
Tire related termMeaning

616
SIENNA_OM_01999-08001_(U)
9-1. Specifications
*: Table 1  Occupant loading and distribution for vehicle normal load for
various designated seating capacities
Snow tire
A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight
Line on Snow-and Ice-Covered Surfaces, and
which is marked with an Alpine Symbol ( )
on at least one sidewall
Test rim The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of th e tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Tire related termMeaning
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution
in a normally loaded vehicle
2 through 4 2 2 in front
5 through 10 32 in front, 1 in second
seat
11 through 15 52 in front, 1 in second
seat, 1 in third seat, 1 in fourth seat
16 through 20 72 in front, 2 in second
seat, 2 in third seat, 1 in fourth seat

656Alphabetical index
SIENNA_OM_01999-08001_(U)
Keyless entrySmart key system ................. 142
Wireless remote control ........ 105
Keys Battery-saving function ......... 144
Electronic key ....................... 104
Engine switch................ 223, 226
If you lose your keys ............. 107
If the electronic key does
not operate properly ........... 581
Key number plate.................. 104
Keyless entry
................... 105, 110, 121, 132
Keys ...................................... 104
Mechanical key ..................... 104
Replacing the battery ............ 503
Warning buzzer..................... 143
Wireless remote control ........ 105
Knee airbags .............................. 36
Language (multi-information display)................................... 619
LATCH anchors ......................... 60
Lever Auxiliary catch lever .............. 475
Hood lock release lever ........ 475
Shift lever .............................. 231
Tilt and telescopic steering lock release lever ............... 176
Turn signal lever ................... 235
Wiper lever.................... 248, 252 License plate lights
Light switch ........................... 237
Replacing light bulbs ............ 523
Wattage ................................ 602
Light bulbs
Replacing.............................. 509
Wattage ................................ 602
Lights
Automatic High Beam system .......... ...................... 242
Door courtesy lights .............. 419
Engine switch light ................ 419
Fog light switch ..................... 247
Headlight switch ................... 237
Illuminated entry system ....... 421
Interior light switch ................ 420
Luggage compartment
light..................................... 136
Outer foot lights .................... 419
Personal light switch ............. 420
Rear ceiling lights ................. 421
Replacing light bulbs ............ 509
Turn signal lever ................... 235
Vanity lights .......................... 435
Wattage ................................ 602
Load capacity .......................... 207
Lock steering column ..... 224, 229
Luggage compartment light Switch ................................... 136
Wattage ................................ 602
K
L

661Alphabetical index
SIENNA_OM_01999-08001_(U)
Tachometer ................................ 88
Tail lightsLight switch ........................... 237
Replacing light bulbs ................... 520, 522, 523
Wattage ................................ 602
Talk switch
*............................. 400
Telephone switch
*.................. 379
Theft deterrent system Alarm ...................................... 77
Engine immobilizer system ..... 75
Theft prevention labels ............. 80
Tire inflation pressure ............. 496 Maintenance data ................. 600
Warning light ......................... 539
Tire pressure warning system
Function ................................ 489
Initializing .............................. 489
Installing tire pressure warning valves and
transmitters......................... 489
Registering ID codes ............ 490
Tire pressure warning reset switch ........................ 489
Warning light ......................... 539
Warning message ................. 550 Tires
Chains .................................. 312
Checking............................... 488
Glossary ............................... 612
If you have a flat tire ..... 562, 564
Inflation pressure .................. 496
Information............................ 606
Replacing.............................. 564
Rotating tires ........................ 488
Size....................................... 600
Snow tires ............................. 311
Tire identification number ..... 608
Tire pressure warning system .......... ...................... 489
Uniform Tire Quality Grading .............................. 610
Warning light......................... 539
Tools ......................................... 567
Total load capacity .................. 594
Towing Dinghy towing ....................... 222
Emergency towing ................ 531
Trailer towing ........................ 208
Traction control ....................... 291
TRAC (Traction Control) Function ................................ 291
TRAC OFF switch................. 292
Trailer towing ........................... 208
Trip meter ................................... 88
Turn signal lights Replacing light bulbs........... 517, 521, 518, 523
Turn signal lever ................... 235
Wattage ................................ 602
T

5HIHUWR³1$9,*$7,21$1'08/7,0(',$
6<67(02:1(5¶60$18$/´

662Alphabetical index
SIENNA_OM_01999-08001_(U)
USB memory ............................ 347
USB port ................................... 322
Valet key ................................... 104
Vanity lightsVanity lights .......................... 435
Wattage ................................ 602
Vanity mirrors .......................... 435 Vanity lights .......................... 435
VDIM (Vehicle Dynamics
Integrated Management)....... 292
Vehicle data recordings .............. 9
Vehicle identification number ................................... 595
Vehicle stability control (VSC) ...................................... 291
Voice command system
*....... 400
VSC (Vehicle Stability Control) .................................. 291
Warning buzzers Brake system ....... ................. 537
Electric power steering system ......... ....................... 538
Key reminder ........................ 560
Low engine oil pressure ........ 537
Open door ............................. 539
Seat belt reminder ................ 539 Warning lights
ABS ...................................... 538
Brake system ....... ................. 537
Charging system................... 537
Electric power steering system .......... ...................... 538
Low engine oil pressure........ 537
Low fuel level ........................ 539
Malfunction indicator lamp .... 537
Master warning light ............. 539
Open door............................. 539
Pre-collision system.............. 538
Seat belt reminder light......... 539
Slip indicator light ................. 538
SRS airbags ......................... 538
Third seat warning light ........ 539
Tire pressure warning light ... 539
Warning messages.................. 546
Washer Checking............................... 487
Low washer fluid warning
message............................. 555
Preparing and checking
before winter ...................... 311
Switch ........................... 248, 252
Washing and waxing ............... 460
Weight Cargo capacity...................... 207
Load limits ............................ 594
Weight .................................. 594
Wheels ...................................... 499 Replacing wheels ................. 564
Size....................................... 600
Window glasses ..................... 183
Window lock switch ................ 183
U
V
W
