2015 TOYOTA SIENNA Navigation Manual

249
3. WHAT TO DO IF...
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
PHONE
7
When making/receiving a call
“Unable to dial.
Please check your
phone.”
Bluetooth® function
is not enabled on
the cellular phone.Enable the Bluetooth®
function on the cellular
phone.
Old registration in-
formation remains
on either this sys-
tem or the cellular
phone.Delete the existing reg-
istration information
from both this system
and the cellular phone,
then register the cellu-
lar phone you wish to
connect to this system.
53
SymptomLikely causeSolution
Page
Cellular phoneThis
system
A call cannot be
made/received.Your vehicle is in a
“No Service” area.Move to where “No
Service” no longer ap-
pears on the display.
SymptomLikely causeSolution
Page
Cellular phoneThis
system

250
3. WHAT TO DO IF...
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
When using the phonebook
SymptomLikely causeSolution
Page
Cellular
phoneThis
system
Phonebook data can-
not be transferred
manually/automati-
cally.
The profile version
of the connected
cellular phone may
not be compatible
with transferring
phonebook data.
For a list of specific
devices which
operation has been
confirmed on this
system, check with
your Toyota dealer or
the following website:
http://www.toyota.com/
entune/

Automatic contact
transfer function on
this system is set to
off.Set automatic contact
transfer function on this
system to on.
236
Passcode has not
been entered on the
cellular phone.Enter the passcode on
the cellular phone if re-
quested (default pass-
code: 1234).

Transfer operation
on the cellular
phone has not com-
pleted.Complete transfer op-
eration on the cellular
phone (approve trans-
fer operation on the
phone).

Phonebook data can-
not be edited.
Automatic contact
transfer function on
this system is set to
on.Set automatic contact
transfer function on this
system to off.236

251
3. WHAT TO DO IF...
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
PHONE
7
When using the Bluetooth® message function
SymptomLikely causeSolution
Page
Cellular
phoneThis
system
Messages cannot be
viewed.
Message transfer is
not enabled on the
cellular phone.
Enable message trans-
fer on the cellular
phone (approve mes-
sage transfer on the
phone).

Automatic transfer
function on this sys-
tem is set to off.Set automatic transfer
function on this system
to on.
244
New message notifi-
cations are not dis-
played.
Notification of SMS/
MMS/E-mail recep-
tion on this system
is set to off.Set notification of SMS/
MMS/E-mail reception
on this system to on.
244
Automatic message
transfer function is
not enabled on the
cellular phone.Enable automatic
transfer function on the
cellular phone.


252
3. WHAT TO DO IF...
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
In other situations
SymptomLikely causeSolution
Page
Cellular
phoneThis
system
The Bluetooth® con-
nection status is dis-
played at the top of
the screen each time
the engine switch is in
following.
 Vehicles without
a smart key sys-
tem
The engine switch is
turned to the “ACC” or
“ON” position.
Vehicles with a
smart key system
The engine switch is
turned to ACCESSO-
RY or IGNITION ON
mode.
Connection confir-
mation display on
this system is set to
on.To turn off the display,
set connection confir-
mation display on this
system to off.
57

253
3. WHAT TO DO IF...
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
PHONE
7
: For details, refer to the owner’s manual that came with the cellular phone.
Even though all con-
ceivable measures
have been taken, the
symptom status does
not change.
The cellular phone
is not close enough
to this system.Bring the cellular
phone closer to this
system.
The cellular phone
is the most likely
cause of the symp-
tom.
Turn the cellular phone
off, remove and rein-
stall the battery pack,
and then restart the
cellular phone.

Enable the cellular
phone’s Bluetooth®
connection.

Stop the cellular
phone’s security soft-
ware and close all ap-
plications.

Before using an appli-
cation installed on the
cellular phone, careful-
ly check its source and
how its operation might
affect this system.

SymptomLikely causeSolution
Page
Cellular phoneThis
system

254
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
1. QUICK REFERENCE ................... 256
MAP SCREEN ..................................... 256
NAVIGATION OPTIONS SCREEN...... 258
2. MAP SCREEN OPERATION ....... 259
CURRENT POSITION DISPLAY ......... 259
MAP SCALE ........................................ 259
ORIENTATION OF THE MAP ............. 260
SWITCHING THE MAP MODE............ 261
SCREEN SCROLL OPERATION ........ 263
ADJUSTING LOCATION IN SMALL INCREMENTS................................... 264
3. MAP SCREEN INFORMATION .......................... 265
DISPLAYING MAP INFORMATION .... 265
DISPLAYING INFORMATION
ABOUT THE ICON WHERE THE
CURSOR IS SET .............................. 267
STANDARD MAP ICONS .................... 268
4. TRAFFIC INFORMATION ............ 269
DISPLAYING TRAFFIC INFORMATION ON THE MAP .......... 271
1. DESTINATION SEARCH SCREEN .................................... 272
2. SEARCH OPERATION.. .............. 274
SELECTING SEARCH AREA .............. 275
SETTING HOME AS
DESTINATION................................... 275
SETTING PRESET DESTINATIONS AS DESTINATION ............................. 275
SEARCHING BY ADDRESS ................ 276
SEARCHING BY POINT OF INTEREST ......................................... 277
SEARCHING FROM PREVIOUS DESTINATIONS ................................ 280
SEARCHING BY ADDRESS BOOK .............................. 280
SEARCHING BY EMERGENCY .......... 281
SEARCHING BY INTERSECTION AND FREEWAY..... 281
SEARCHING BY MAP ......................... 283
SEARCHING BY COORDINATES ....... 283
3. STARTING ROUTE GUIDANCE ....... ......................... 284
STARTING ROUTE GUIDANCE.......... 284
PAUSING GUIDANCE ......................... 287
1BASIC OPERATION2DESTINATION SEARCH
8
NAVIGATION SYSTEM *

8
255
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
1
2
3
4
5
6
7
8
9
1. ROUTE GUIDANCE SCREEN ..... 288
SCREEN FOR ROUTE GUIDANCE ... 288
ROUTE OVERVIEW............................ 289
DURING FREEWAY DRIVING............ 290
WHEN APPROACHING INTERSECTION ............................... 291
TURN LIST SCREEN .......................... 292
TURN-BY-TURN ARROW SCREEN ........................................... 292
2. TYPICAL VOICE GUIDANCE PROMPTS.................................. 293
3. EDITING ROUTE ......................... 294
ADDING DESTINATIONS ................... 295
REORDERING DESTINATIONS ......... 295
DELETING DESTINATIONS ............... 295
SETTING ROUTE PREFERENCES ... 296
SELECTING ROUTE TYPE ................ 296
DETOUR SETTING ............................. 297
STARTING FROM ADJACENT ROAD ................................................ 298
1. MEMORY POINTS SETTINGS ................................. 299
SETTING UP HOME ........................... 300
SETTING UP PRESET
DESTINATIONS................................ 301 SETTING UP ADDRESS BOOK.......... 303
SETTING UP AREAS TO AVOID ........ 305
DELETING PREVIOUS
DESTINATIONS ................................ 307
1. DETAILED NAVIGATION SETTINGS ................................. 308
SCREENS FOR NAVIGATION
SETTINGS ........................................ 308
2. TRAFFIC SETTINGS................... 312
SCREEN FOR TRAFFIC SETTINGS ........................................ 312
AUTO AVOID TRAFFIC....................... 313
MY TRAFFIC ROUTES ....................... 314
1. GPS (GLOBAL POSITIONING SYSTEM) .................... ............... 318
LIMITATIONS OF THE
NAVIGATION SYSTEM..................... 318
2. MAP DATABASE VERSION AND COVERED AREA ............. 320
MAP INFORMATION ........................... 320
ABOUT THE MAP DATA ..................... 321
3ROUTE GUIDANCE
4MEMORY POINTS
5SETUP
6TIPS FOR THE NAVIGATION
SYSTEM
NAVIGATION SYSTEM*
*: With navigation function

256
SIENNA_Navi+MM_01999-08003_(U)
14.06.02 18:35
1. BASIC OPERATION
1. QUICK REFERENCE
MAP SCREEN
To display this screen, press the “APPS” button, then select “Navigation” on the
“Apps” screen.
No.NameFunctionPage
2D North-up, 2D
heading-up or 3D
heading-up sym-
bolIndicates whether the map orientation is set to
north-up or heading-up. The letter(s) beside this
symbol indicate the vehicle’s heading direction
(e.g. N for north). In 3D map, only a heading-up
view is available.
260
Options buttonSelect to display the “Navigation Options” screen.258
“GPS” mark
(Global
Positioning
System)Shows that the vehicle is receiving signals from
the GPS.318
Traffic indicator
Shows that traffic information is received. Select
to start voice guidance for traffic information.
When traffic information is received via HD Radio
broadcast, HD mark is displayed on the right.
269
Scale indicatorThis figure indicates the map scale.259
