2015 TOYOTA RAV4 coolant capacity

RAV4_OM_OM42A78U_(U)
6658-1. Specifications
8
Vehicle specifications
Cooling system
Capacity7.2 qt. (6.8 L, 6.0 Imp. qt.)
Coolant type
Use either of the following:• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-basednon-silicate, non-amine, non-nitrite, and
non-borate coolant with long-life hybrid
organic acid technology
Do not use plain water alone.
Ignition system
Spark plug
MakeDENSO SK16HR11
Gap0.043 in. (1.1 mm)
NOTICE
■ Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

RAV4_OM_OM42A78U_(U)
6818-1. Specifications
8
Vehicle specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below

720Alphabetical index
RAV4_OM_OM42A78U_(U)
Eco drive mode ........................ 209
Eco Driving Indicator .............. 167
EDR (Event data recorder) ........ 11
Electric Power Steering (EPS)....................................... 272
Function ................................ 272
Warning light ......................... 613
Electronic key ............................ 96
Battery-saving function ......... 106
If the electronic key does not operate properly ........... 646
Replacing the battery ............ 570
Emergency, in case of If the electronic key does
not operate properly ........... 646
If the engine will not start ...... 643
If the shift lever cannot be shifted from P ..................... 645
If the vehicle has discharged battery .............. 649
If the warning buzzer sounds ................................ 611
If the warning light
turns on .............................. 611
If you have a flat tire ............. 627
If you lose your keys ............... 97
If you think something is wrong.................................. 609
If your vehicle becomes stuck ................................... 656
If your vehicle needs to be towed .................................. 603
If your vehicle overheats ....... 653
Emergency flashers ................ 600 Engine
“ACC” position ...................... 197
Accessory mode ................... 201
Compartment ........................ 537
Engine switch ............... 197, 200
Hood ..................................... 533
How to start the engine ........................ 197, 200
Identification number ............ 662
If the engine will not start ...... 643
Ignition switch (engine switch) ........... 197, 200
Overheating .......................... 653
Engine coolant......................... 542
Capacity................................ 665
Checking............................... 542
Preparing and checking before winter ...................... 287
Engine immobilizer system ...... 76
Engine oil ................................. 538 Capacity................................ 663
Checking............................... 538
Preparing and checking before winter ...................... 287
Engine oil maintenance data......................................... 521
Engine switch
(ignition switch) ............ 197, 200
Engine switch light (ignition switch light) ............ 486
Entune Audio ........................... 387 Basic Audio Operations ........ 392
CD player.............................. 409
iPod ...................................... 415
Listening to Bluetooth
®
Audio .................................. 440
Radio .................................... 407
Steering wheel audio switches ............................. 389
USB memory ........................ 420
USB port/AUX Port ............... 391
Using a Bluetooth
®
Phone ................................. 442
Using the AUX port ............... 425
E
