2015 TOYOTA PRIUS PLUG-IN display

400
3-5. Other interior features
PRIUS PHV_OM_OM47A11U_(U)
Outside temperature display
■Operating conditions
The “POWER” switch is in ON mode.
■Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
●When stopped, or driving at low speeds (less than 16 mph [25 km/h])
●When the outside temperature has changed suddenly (at the entrance/
exit of a garage, tunnel, etc.)
■When -- is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
The displayed temperature ranges from -40°F (-40°C) up to 122°F
(50°C).

437
4-2. Maintenance
PRIUS PHV_OM_OM47A11U_(U)
4
Maintenance and care
■Resetting the message indicating maintenance is required (U.S.A.
only)
After the required maintenance is performed according to the maintenance
schedule, please reset the message.
To r e s e t t h e d a t a , f o l l o w t h e p r o c e d u r e s d e s c r i b e d b e l o w :
Turn the “POWER” switch off with the trip meter A shown.
Turn the “POWER” switch to ON mode with the MPH or km/h button
(oP. 2 6 4 ) h e l d d o w n .
Keep pressing the button until the trip meter indicates “000000” and
the multi-information display indicates that the reset is complete.
■Allow inspection and repairs to be performed by a Toyota dealer
●To y o t a t e c h n i c i a n s a r e w e l l - t r a i n e d s p e c i a l i s t s a n d a r e k e p t u p t o d a t e
with the latest service information. They are well informed about the
operation of all systems on your vehicle.
●Keep a copy of the repair order. It proves that the maintenance that has
been performed is under warranty coverage. If any problem should arise
while your vehicle is under warranty, your Toyota dealer will promptly
take care of it.
STEP 1
STEP 2
STEP 3

490
4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47A11U_(U)
Tire inflation pressure
■Tire inflation pressure
The recommended cold tire inflation pressure and tire size are
displayed on the tire and loading information label. (oP. 6 2 7 )

5
When trouble arises
529
5-1. Essential information
PRIUS PHV_OM_OM47A11U_(U)
If your vehicle needs to be towed
Situations when it is not possible to be towed by another vehicle
In the following situations, it is not possible to be towed by another
vehicle using cables or chains, as the front wheels may be locked
due to the parking lock. Contact your Toyota dealer or a commercial
towing service.
●There is a malfunction in the shift control system. (oP. 5 5 2 )
●There is a malfunction in the immobilizer system. (oP. 1 8 3 )
●There is a malfunction in the smart key system. (oP. 5 9 9 )
●The 12-volt battery is discharged. (oP. 6 0 1 )
Situations needs to contact dealers before towing
The following may indicate a problem with your hybrid transmission.
Contact your Toyota dealer or commercial towing service before tow-
ing.
●The “CHECK HYBRID SYSTEM” warning message appears on
the multi-information display and the vehicle does not move.
●The vehicle makes an abnormal sound.
If towing is necessary, we recommend having your vehicle towed by
your Toyota dealer or commercial towing service, using a lift-type
truck or flat bed truck.
Use a safety chain system for all towing, and abide by all state/pro-
vincial and local laws.

550
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47A11U_(U)
If a warning message is displayed
If a warning is shown on the multi-information display, stay calm and
perform the following actions:
Master warning light
Multi-information display
The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.
If any of the warning light turns on again after performing the fol-
lowing actions, contact your Toyota dealer.

5
When trouble arises
551
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47A11U_(U)
Stop the vehicle immediately.
A buzzer sounds and a warning message is shown on the multi-infor-
mation display. The following warnings indicate the possibility of dam-
age to the vehicle that may lead to an accident. Immediately stop the
vehicle in a safe place and contact your Toyota dealer.
Warning messageDetails
(U.S.A.)
(Canada)
Indicates an abnormal engine oil pressure.
The warning light may turn on if the engine oil pres-
sure is too low.
Indicates a malfunction in the hybrid system.
In this situation, there is a possibility that the parking
lock mechanism will not work.
When parking, park the vehicle on a flat surface and
apply the parking brake securely.

5
When trouble arises
557
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47A11U_(U)
Warning messageDetailsCorrection
procedure
(Flashes
rapidly)
(If equipped)
Indicates that there is a high
possibility of a frontal collision,
or that the pre-collision braking
function is operating.
A buzzer also sounds.
At the same time,
will appear on the head-up
display (the image flashes).
Slow the vehicle by
applying the
brakes.
(If equipped,
flashes)
Indicates that your vehicle is
nearing the vehicle ahead (in
radar cruise mode).
A buzzer also sounds.
At the same time,
will appear on the head-up
display (the image flashes).
Slow the vehicle by
applying the
brakes.
The hybrid system has over-
heated.
This message may be dis-
played when driving under
severe operating conditions,
and the output of the hybrid
system may temporarily
decrease in order to protect
the system. (For example,
when driving up a long steep
hill or driving up a steep hill in
reverse.)
Stop and check.
(oP. 6 0 7 )

560
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47A11U_(U)
Warning messageDetailsCorrection
procedure
The fuel filler door has been
left open.
Tighten the fuel
tank cap and close
the fuel filler door.
The charging port lid is open.Close the charging
port lid.
■Warning message in radar cruise mode (if equipped)
In the following cases, the warning message may not be displayed even if
vehicle-to-vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same
speed or the vehicle ahead is traveling more quickly than your vehicle.
●When the vehicle ahead is traveling at very low speed.
●Immediately after cruise control speed is set.
●At the instant the accelerator pedal is depressed.
