2015 TOYOTA PRIUS PLUG-IN HYBRID tow

5
When trouble arises
535
5-1. Essential information
PRIUS PHV_OM_OM47A11U_(U)
NOTICE
■
To prevent damage to the vehicle when towing using a wheel-lift type
truck
When raising the vehicle, ensure adequate ground clearance for towing at
the opposite end of the raised vehicle. Without adequate clearance, the
vehicle could be damaged while being towed.
■ To prevent body damage when towing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.

604 5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47A11U_(U)
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■ To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is
off.
● Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic.
■ When the 12-volt battery is removed or discharged
●The hybrid system may not start. ( P. 478)
● If the 12-volt battery is depleted with the shift position in P, it will not be
possible to shift the shift position other than P. In this case, the vehicle
cannot be towed without lifting both front wheels because the front
wheels are locked by the parking lock. ( P. 529)
● When the 12-volt battery is reconnected, start the hybrid system, depress
the brake pedal, and confirm that it is possible to shift into each shift posi-
tion.
■ Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even
when the vehicle is not in use, due to natural discharge and the draining
effects of certain electrical appliances. If the vehicle is left for a long time, the
12-volt battery may discharge, and the hybrid system may be unable to start.
(The 12-volt battery charges automatically while the hybrid system is operat-
ing.)

614 5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47A11U_(U)
NOTICE
■To avoid damage to the hybrid transmission and other components
●Avoid spinning the wheels and depressing the accelerator pedal more
than necessary.
● If the vehicle remains stuck even after these procedures are performed,
the vehicle may require towing to be freed.

679
Alphabetical index
PRIUS PHV_OM_OM47A11U_(U)
Daytime running light
system ................................... 300
Deck board............................... 409
Defogger
Rear window......................... 381
Side mirrors .......................... 381
Dimensions .............................. 618
Dinghy towing ......................... 361
Display Dynamic radar cruise control ................................ 317
Multi-information ................... 271
Warning messages............... 550
Do-it-yourself maintenance .... 445
Door lock Back door ............................. 144
Side doors ............................ 138
Smart key system ... .............. 113
Wireless remote control........ 136
Doors Back door ............................. 144
Door glasses ........................ 175
Door lock .............. 113, 136, 138
Rear door child-protector...... 139
Side doors ............................ 138
Driver’s seat belt reminder light ........................................ 541
Driving
Break-in tips ......................... 230
Correct posture..................... 185
Procedures ........................... 228
Winter driving tips ................. 355 Eco drive mode switch ............251
Electric power steering ...........333
Electronic key
If the electronic key does not operate properly..................599
Replacing battery ..................497
Emergency, in case of If a warning buzzer sounds ................................537
If a warning light turns on ......537
If the electronic key does not operate properly..................599
If the hybrid system will not start .....................................596
If the 12-volt battery is
discharged ..........................601
If you have a flat tire .............574
If you lose your keys .............598
If you think something is wrong ..................................536
If your vehicle becomes stuck ...................................613
If your vehicle has to be stopped in an
emergency ..........................615
If your vehicle needs to be towed ..................................529
If your vehicle overheats .......607
Emergency flashers Switch....................................528DE

686 Alphabetical index
PRIUS PHV_OM_OM47A11U_(U)
Tonneau cover ......................... 410
Tools ......................................... 454
Total load capacity................... 354
Touch tracer display ................263
TowingDinghy towing........................ 361
Emergency towing................. 532
Trailer towing......................... 360
TRAC ......................................... 333
Traction control........................ 333
Trailer towing ........................... 360
Transmission
Hybrid transmission............... 249
P position switch ................... 252
Trip information ....................... 279
Trip meter ................................. 278
Turn signal lights Replacing light bulbs ............. 511
Switch.................................... 259
Wattage ................................. 628
USB port
*................................. 387
Vanity lights Vanity lights ........................... 399
Wattage ................................. 628
Vanity mirrors........................... 399
Vehicle data recordings ............24
Vehicle identification number ................................... 619
Vehicle proximity notification system ......................................38
Vehicle stability control........... 333
VSC............................................ 333 Warning buzzers
Brake system ........................ 537
Open door ............................ 541
Seat belt reminder................. 541
Warning lights Anti-lock brake system
(ABS) .................................. 539
Automatic headlight leveling system ................................ 540
Brake system ................ 537, 540
Charging system .... ............... 538
Cruise control ........................ 540
Electric power steering
system ................................ 539
High coolant temperature...... 538
Hybrid system ....................... 539
Low fuel level ........................ 541
Low tire pressure .................. 542
Malfunction indicator lamp .... 539
Open door ............................. 541
Pre-collision system .............. 540
Radar cruise control. ............. 540
Seat belt warning light........... 541
Slip indicator ......................... 540
SRS airbags .......................... 539
Tire pressure warning light.... 542U
V
W
