2015 TOYOTA PRIUS heater

376 3-5. Other interior features
PRIUS_OM_OM47A17U_DVD_(U)
CAUTION
■Burns
●Use caution when seating the following persons in a seat with the seat
heater on to avoid the possibility of burns:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
● Do not cover the seat with anything when using the seat heater.
Using the seat heater with a blanket or cushion increases the temperature
of the seat and may lead to overheating.
● Do not use the seat heater more than necessary. Doing so may cause
minor burns or overheating.
NOTICE
■To prevent seat heater damage
Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
■ To prevent 12-volt battery discharge
Turn the seat heaters off when the hybrid system is off.

410 4-1. Maintenance and care
PRIUS_OM_OM47A17U_DVD_(U)
NOTICE
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the rear window, as this may cause
damage to the rear window defogger heater wires. Use a cloth dampened
with lukewarm water to gently wipe the window clean. Wipe the window in
strokes running parallel to the heater wires.
● Be careful not to scratch or damage the heater wires.

473
4-3. Do-it-yourself maintenance
PRIUS_OM_OM47A17U_DVD_(U)
4
Maintenance and care
■
Left side instrument panel
FUSEAmpereCircuit
1 CIG 15A Power outlets
2 ECU-ACC 10AMultiplex communication system,
outside rear view mirrors, driver
support system, audio system,
navigation system, advanced
parking guidance system, head-up
display
3 PWR OUTLET 15A Power outlets
4 SEAT HTR FR 10A Seat heater
5 SEAT HTR FL 10A Seat heater
6 DOOR NO.1 25A Power door lock system
7 PSB 30A Pre-Collision System
8 PWR SEAT FR 30A Front passenger’s seat
9 DBL LOCK 25A No circuit
10 FR FOG 7.5A Front fog lights
11 PWR SEAT FL 30A Driver’s seat
12 OBD 7.5A On-board diagnosis system
13 RR FOG 7.5A No circuit
ITO43P133
12
3 4
56 7
8
910
11 12
13
14 15
16 17
18 19
23 24 25
26
2728
29
30
20 21 22

594 6-1. Specifications
PRIUS_OM_OM47A17U_DVD_(U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

632 Alphabetical index
PRIUS_OM_OM47A17U_DVD_(U)
Child safetyAirbag precautions ................150
Back door precautions ............96
Child restraint system............ 162
Child-protectors .......................89
How your child should wear the seat belt ........................ 112
Installing child restraints ........ 167
Power window lock switch..... 125
Power window precautions ... 127
Removed electronic key battery precautions ......................... 465
Seat belt extender precautions ......................... 117
Seat belt precautions ............ 113
Seat heater precautions ........ 376
12-volt battery precautions .... 443
Child-protectors .........................89
Cleaning
Exterior .................................. 404
Interior ................................... 407
Seat belts .............................. 408
Clock ......................................... 233
Condenser ................................ 435
Console box ............................. 365
Cooling system Engine overheating ............... 561
Hybrid system overheating.... 561
Cruise control Cruise control ........................ 269
Dynamic radar cruise control ................................. 273
Cup holders .............................. 366
Curtain shield airbags ............. 141
Customizable features............. 602 Daytime running light
system .................................... 256
Deck board ............................... 381
Defogger
Rear window ......................... 352
Side mirrors........................... 352
Dimensions .............................. 572
Dinghy towing .......................... 329
Display Dynamic radar cruise control ................................. 273
Multi-information ................... 226
Warning messages ............... 517
Do-it-yourself maintenance .... 419
Door lock Back door ................................ 94
Side doors ............................... 88
Smart key system .. ................. 63
Wireless remote control .......... 86
Doors Back door ................................ 94
Door glasses ......................... 125
Door lock ..................... 63, 86, 88
Rear door child-protector ........ 89
Side doors ............................... 88
Driver’s seat belt reminder light ......................................... 508
Driving
Break-in tips .......................... 183
Correct posture ..................... 139
Procedures............................ 182
Winter driving tips ................. 323D

634 Alphabetical index
PRIUS_OM_OM47A17U_DVD_(U)
Floor mats................................. 379
FluidBrake ..................................... 580
Washer .................................. 438
Fog lights Replacing light bulbs ............. 478
Switch.................................... 259
Wattage ................................. 582
Foot lights................................. 359
Front fog lights
Replacing light bulbs ............. 478
Switch.................................... 259
Wattage ................................. 582
Front passenger occupant classification system ............ 156
Front passenger’s seat belt reminder light......................... 508
Front seats
Adjustment ............................ 100
Front side marker light Replacing light bulbs ............. 478
Wattage ................................. 582
Front turn signal lights Replacing light bulbs ............. 478
Switch.................................... 214
Wattage ................................. 582
Fuel Capacity ................................ 574
Fuel gauge ............................ 217
Information ............................ 583
Refueling ............................... 133
Type ...................................... 583
Fuel door................................... 133
Fuel filler door .......................... 133
Fuses......................................... 466 Garage door opener ................ 387
Gauges...................................... 217
Glove boxes ............................. 364
Hands-free system
(for cellular phone)
*
Hazard lights Switch ................................... 494
Head restraints Adjustment ........................... 106
Headlight cleaner ..................... 268
Headlights
Cleaner ................................. 268
Replacing light bulbs ............. 478
Switch ................................... 253
Wattage................................. 582
Heaters
Automatic air conditioning system ................................ 332
Seat heaters.......................... 375
Side mirrors........................... 352
Hill-start assist control ............ 306
Hood.......................................... 422
Hooks Cargo .................................... 381
Horn .......................................... 216
Hybrid system Eco savings record ................. 55
Emergency shut off system..... 39
Energy monitor/consumption screen ............. 44
High voltage components ....... 38
Hybrid System Indicator ........ 227
Ignition switch ....................... 195
Monthly fuel consumption record .............. 55
“POWER” switch ................... 195
FG
H

636 Alphabetical index
PRIUS_OM_OM47A17U_DVD_(U)
MaintenanceDo-it-yourself maintenance ....................... 419
General maintenance ............ 414
Maintenance data.................. 572
Maintenance requirements.... 411
Maintenance data ..................... 412
Meter Instrument panel light
control ................................. 220
Meters ................................... 217
Speed unit select button........ 219
Trip information display ......... 232
Micro dust and pollen filter ..... 336
Microphone
*............................ 395
Mirrors Inside rear view mirror........... 119
Side mirror heater ................. 352
Side mirrors ........................... 123
Vanity mirrors ........................ 371
MP3 disc
*
Multi-information display ........ 226
Navigation system (refer to “NAVIGATION
SYSTEM OWNER’S MANUAL”)
Noise from under vehicle ..........22
Odometer .................................. 231
Oil
Engine oil .............................. 429
Opener
Back door ................................94
Fuel filler door ....................... 133
Hood...................................... 422
Outside rear view mirrors Adjusting and folding ............. 123
Outside rear view mirror
defogger switch ..................... 352 Outside temperature
display .................................... 372
Overheating .............................. 561
Parking brake ........................... 215
Parking lights
Switch ................................... 253
PCS ........................................... 308
Personal lights
Switch ................................... 361
Wattage................................. 582
Power outlets ........................... 373
“POWER” switch ..................... 195
Power windows ........................ 125
Pre-collision system ................ 308
Radar cruise control system .................................... 273
Radiator .................................... 435
Radio
*
Radio data system*
RDS*
Rear seats Adjustment ............................ 103
Folding down......................... 104
Rear turn signal lights
Replacing light bulbs ............. 478
Wattage................................. 582
Rear view mirror .............. 119, 123
Rear view monitor system
*
Rear window and outside rear view mirror
defoggers ............................... 352
Rear window wiper and washer .................................... 265
Remote Air C onditioning
System.................................... 348
M
N
O
P
R

637
Alphabetical index
PRIUS_OM_OM47A17U_DVD_(U)
Replacing
Electronic key battery ........... 464
Fuses.................................... 466
Light bulbs ............................ 478
Tires ..................................... 537
Reporting safety defects for
U.S. owners ........................... 612
Resetting the message indicating maintenance is
required ................................. 412
Safety Connect ........................ 395
Seat belt reminder light .......... 508
Seat belts Adjusting the seat belt .......... 111
Automatic Locking Retractor (ALR).................................. 112
Child restraint system installation .......................... 167
Cleaning and maintaining the seat belt ....................... 408
Emergency Locking Retractor (ELR) ................................. 112
How to wear your
seat belt ............................. 110
How your child should wear the seat belt ....................... 112
Pre-collision seat belts ......... 308
Pregnant women, proper seat belt use ........... 114
Reminder light ...................... 508
Seat belt extenders .............. 113
Seat belt instructions for Canadian owners .......... 613
Seat belt pretensioners ........ 111
Seat heaters ............................. 375
Seating capacity ...................... 322 Seats
Adjustment ................... 100, 103
Adjustment precautions .................102, 105
Child seats/child restraint system installation ..............167
Cleaning ................................407
Folding down the seatbacks............................104
Head restraint........................106
Properly sitting in the seat .....139
Seat heaters ..........................375
Service reminder indicators ..............................222
Shift lever
Transmission .........................205
Side airbags..............................141
Side marker lights Replacing light bulbs .............478
Switch....................................253
Wattage .................................582
Side mirrors
Adjusting and folding ............. 123
Smart key system Antenna location .....................66
Entry functions ........................63
Starting the hybr id system.....195
Solar Ventilation System .........345
SOS button ...............................395
Spare tire Inflation pressure...................581
Storage location ....................537
Spark plug ................................578
Specifications...........................572
Speedometer ............................217
S
*: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL” or “NAVIGATION SYSTEM OWNER’S MANUAL”.
