2015 TOYOTA CAMRY HYBRID Quick Reference Guide

2015
Camry Hybrid
Quick Reference Guide

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
1
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental operations
so you can locate and use the vehicle’s main equipment quickly
and easily.
The Quick Reference Guide is not intended as a substitute for the
Owner’s Manual located in your vehicle’s glove box. We strongly
encourage you to review the Owner’s Manual and supplementary
manuals so you will have a better understanding of your vehicle’s
capabilities and limitations.
Your dealership and the entire staff of Toyota Motor Sales, U.S.A.,
Inc. wish you many years of satisfied driving in your new Camry
Hybrid.
A word about safe vehicle operations
This Quick Reference Guide is not a full description of
Camry Hybrid operations. Every Camry Hybrid owner should
review the Owner’s Manual that accompanies this vehicle.
Pay special attention to the boxed

information highlighted in

color throughout the Owner’s Manual. Each box contains safe
operating instructions to help you avoid injury or equipment
malfunction.
All information in this Quick Reference Guide is current at the
time of printing. Toyota reserves the right to make changes at
any time without notice.
2015
Camry Hybrid
INDEX
1 Visit your Toyota dealer for information on customizing this feature.2 Programmable by customer. Refer to the Owner’s Manual for instructions and more information.3 HomeLink ®
is a registered trademark of Gentex Corporation.
OVERVIEW
FEATURES/OPERATIONS
Moonroof 13
Multi-Information Display1 25
Parking
brake
12
Power outlets-12V
DC

15
Pre-collision system

(PCS)

26
Rear

view monitor system

18
Seat

adjustments-Front

14
Seat

adjustments-Rear

14
Seat

heaters

20
Seats-Head

restraints

13
Steering

lock release

12
Steering

wheel switches and
Telephone

controls (Bluetooth
®) 21
Tilt and
telescopic steering wheel 12
Traffic

23
Transmission

11
Weather

23
Windows-Power

13
Wipers & washers

15
Wireless

Charging

25



Door locks 27
Doors-Child safety locks 27
Floor
mat installation
31
Safety

Connect
28
Seat

belts
27
Seat

belts-Shoulder belt anchor
28
Spare

tire & tools
29
Star

Safety System
TM 30-31
Trunk
internal release 29
Engine maintenance 9
Fuel tank door release and cap 8
Hood release

9
Indicator symbols


4-5
Instrument cluster


4
Instrument panel
2-3Light control-Instrument panel 8Smart Key System1,2 6-7


Air Conditioning/Heating


19
Audio

22
Auto lock/unlock
1,2 11
Bluetooth® Pairing Section 33-42
Bottle holders 24
BSM
(Blind Spot Monitor)
18
Clock

19
Cruise control

17
Cup

holders
24
Garage

door opener (HomeLin
k®)3 17
Hybrid
Synergy Drive System

10
iPod®/USB/AUX port 20
Lights1 & turn signals 16
Lane
Departure Alert (LDA) 26
SAFETY AND EMERGENCY FEATURES
FEATURES/OPERATIONS

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
23
OVERVIEW
Instrument panel
Steering wheel audio controls1,2,3
Meter control switches1
Telephone controls1,2,3
Voice command button1,2,3
Vehicle-to-vehicle distance button1
Cruise control
Air Conditioning controls
Outside rearview mirror
1/Rear window defogger button
Headlight and turn signal controls/Headlight, turn signal and front fog
light
1 controls
Wiper and washer controls
“ENGINE START STOP” button (Smart Key)
1
Audio system1/Navigation system1,2/Display audio system1,3
Emergency flasher button
Tire pressure warning reset switch1
Eco drive mode switch EV drive mode switch
Seat heater controls
1
Tilt and telescopic steering lock release
BSM (Blind Spot Monitor) main switch1
VSC OFF switch
LDA (Lane Departure Alert) switch1
PCS (Pre-Collison System) switch1
1
If equipped2 For details, refer to the “Navigation System Owner’s Manual.”3 For details, refer to the “Display Audio System Owner’s Manual .”
NOTE: For vehicles equipped with Entune
TM, please consult the “Navigation
System With Entune Quick Reference Guide” or www.toyota.com/entune.
Steering wheel controlsAutomatic Air Conditioning
Type A
Type B

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
45
OVERVIEW
Instrument cluster
Hybrid system indicator
Service indicators and reminders
Outside temperature display
Speedometer
Display change button
Fuel gauge
Odometer/trip meter display
Multi-information display
Shift position display
Engine coolant temperature display
Instrument panel light control button
2 If this light flashes, refer to “Cruise control,” Section 2-4, 2015 Owner’s Manual.3 Light flashes in yellow to indicate a malfunction. Light flashes quickly in green to indicate that
the steering lock has not been released.
Driver/Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
Indicator symbols
Brake system warning1
For details, refer to “Indicators and warning lights,” Section 2-2, 2015 Owner’s
Manual .
1 If indicator does not turn off within a few seconds of starting engine, there may be a
malfunction. Have vehicle inspected by your Toyota dealer.

Pre-collison system warning1
Headlight low/high beam indicator
Turn signal indicator
Slip indicator
1
Cruise control indicator2/Cruise control SET indicator2
Low Tire Pressure Warning1
Theft deterrent/Engine immobilizer system indicator
SRS airbag warning1
Electric power steering system warning1
Malfunction/Check Engine indicator1
Low fuel level warning
Anti-lock Brake System warning1
Vehicle Stability Control OFF indicator1
Master system warning1
Automatic high beam indicator

Land Departure Alert (LDA) warning1
Passenger Air Bag ON/OFF indicator1
“ECO MODE” indicator
“READY” indicator
EV indicator1
EV drive mode indicator1
Radar cruise control indicator1

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
67
OVERVIEW
Smart Key system
Push
Push ONCE: Driver door
TWICE: All doors
Locking operation
Unlocking operation
Start function
Accessories such as the radio will operate.
Power ON; the engine not running.
All systems OFF.
ACC
ON
OFF
NOTE: Gear shift lever must be in Park and brake pedal depressed.
Without depressing the brake pedal, pressing the “ENGINE START STOP” switch
will change the operation mode in succession from:
* Driver door unlocking function can be programmed to unlock driver door only, or all doors. Grasping front passenger door handle will unlock all doors.
NOTE: Doors may also be locked/unlocked using remote.
Power (without starting engine)
Panic button
Push and hold
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for
safety.
Trunk lid
Push and holdTrunk lock/unlock
Push
Locking operationUnlocking operation
Carry remote to lock Carry remote to unlock
Front door lock
Carry remote to lock/unlock
Front door unlock*
TouchGrasp

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
89
Hood releaseFuel tank door release and cap
Engine oil filler cap
Engine oil level dipstick
Engine coolant reservoir
Windshield washer fluid tank
NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer
to the “Warranty Maintenance Guide.”
Light control-Instrument panel
Engine maintenance
OVERVIEW
NOTE: Tighten until one click is heard. If the cap is not tightened enough,
Check Engine “
” indicator may illuminate.
Pull up
Turn to open
Store
Turn to close
Brightness control
Pull up latch and raise hood
Pull

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
11
10
FEATURES/OPERATIONS
Auto lock/unlock
Automatic door locks can be programmed to operate in four different modes, or
turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed goes above approximately 12 mph.
-Doors unlock when shifting into Park.
-Doors unlock when the “ENGINE START STOP” switch is set to OFF and driver’s
door is opened.
Refer to the Owner’s Manual for more details.
(1) Put the selector lever in “P.”
(2) Depress the brake pedal, and “
” will be displayed on the Multi-Information
Display.
(3) Press the “POWER” switch briefly and firmly.
(4) The “READY” light will blink. After a few seconds, when the light remains
steady and a beep sounds, you may begin driving.
Starting the Hybrid System
The Hybrid Synergy Drive System utilizes a computer-controlled gasoline engine
and electric motor to provide the most efficient combination of power for the
vehicle. To conserve energy, when the brakes are applied the braking force
generates electricity which is then sent to the traction battery. In addition,
the engine shuts off when the vehicle is stopped. The benefits are better fuel
economy, reduced vehicle emissions and improved performance.
NOTE: Fuel consumption and energy information of the Hybrid System are shown on the Multi-Information Display and/or navigation system
screen (if equipped).
Tips for improved fuel economy
1. Ensure tire pressures are maintained at levels specified in the Owner’s Manual.
2. Link trips to reduce engine cold starts whenever possible.
3. Avoid driving at speeds that are higher than necessary, especially on the highway.
4. When possible, avoid sudden stops to maximize regenerative braking energy.
5. Minimize use of the Air Conditioning.
Hybrid Synergy Drive System
Transmission
1 The “POWER” switch must be set at “ON” and the brake pedal depressed to shift
from Park.
2 The engine brake is the equivalent of downshifting. Shift to “B” when engine
braking is desired (i.e. downhill driving, coasting to a stop, etc.).
B
Park1
Reverse
Neutral
Drive
Engine braking2

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
1213
FEATURES/OPERATIONS
Moonroof (if equipped)
Sliding operationTilting operation
OpenTiltCloseClose
Recommended driving position
to minimize wind noise.
Windows-Power
Push once to open; moonroof will automatically stop at the recommended
position. Push again to open completely.
Push once to open partway;
again to open completely.
Steering lock release
Parking brake
Set: Depress
Release: Depress again
Hold wheel, push lever down, set angle and length, and return lever.
NOTE: Do not attempt to adjust while the vehicle is in motion.
Tilt and telescopic steering wheel
* Gently turn steering wheel while pressing the “ENGINE START STOP” switch. If the lock
does not release, the Smart Key system indicator will flash quickly (green).
Push
Turn
Lock release lever
Angle
Length
U.S.A. Canada
Up
Down
Driver sideWindow lock switch
Automatic operation (driver’s and passenger’s side) Push the switch completely
down or pull it completely up and release to fully open or close. To stop the
window partway, operate the switch in the opposite direction.
Window lock switch
Deactivates all passenger windows. Driver’s window remains
operable.
Seats-Head restraints
Lock release button
