2015 TOYOTA CAMRY HYBRID seat adjustment

CAMRY_HV_U (OM33A87U)
Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3
Operation of
each
componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advices which are necessary for
driving
5Audio systemOperating the audio system
6Interior featuresUsage of the interior features, etc.
7Maintenance
and careCaring for your vehicle and maintenance
procedures
8When trouble
arisesWhat to do in case of malfunction or emergency
9Vehicle
specificationsVehicle specifications, customizable features, etc.
10For ownersReporting safety defects for U.S. owners, and seat
belt and SRS airbag instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically

291-1. For safe use
1
For safety and security
CAMRY_HV_U (OM33A87U)
Make sure that you can see backward clearly by adjusting the inside
and outside rear view mirrors properly. (P. 136, 138)
Adjusting the mirrors
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat
tracks and stop the seat from locking in place. This may lead to an acci-
dent and the adjustment mechanism may also be damaged.
● When driving over long distances, take regular breaks before you start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force yourself to con-
tinue driving and take a break immediately.

128
CAMRY_HV_U (OM33A87U)
3-3. Adjusting the seats
Manual seat
Power seat
Fr ont seats
Adjustment procedure
Seat position adjustment lever
Seatback angle adjustment
leverVertical height adjustment
lever (driver’s side only)1
2
3
Seat position adjustment
switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch (driver’s
side only)Vertical height adjustment
switch (driver’s side only)
Lumbar support adjustment
switch (driver’s side only)1
2
3
4
5

1293-3. Adjusting the seats
3
Operation of each component
CAMRY_HV_U (OM33A87U)
WARNING
■When adjusting the seat position
●Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Make sure to leave enough space around the feet so they do not get stuck.
■ Seat adjustment
●Be careful that the seat does not hit passengers or luggage.
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● Manual seat only: After adjusting the seat, make sure that the seat is
locked in position.

1313-3. Adjusting the seats
3
Operation of each component
CAMRY_HV_U (OM33A87U)
WARNING
■When folding the rear seatback down
Observe the following precautions. Failure to do so may result in death or
serious injury.
●Do not fold the seatback down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the trunk while driv-
ing.
● Do not allow children to enter the trunk.
■ When returning the seat to its original position
● Ensure that the seat belt does not get caught between or behind the seats.
● If the seat belt has been released from its guide, pass the seat belt through
its guide. ( P. 32)
■ Seat adjustment
Be careful not to get hands or feet pinched between the rear console box
and the rear seat when folding down the rear seatback.
■ After returning the seatback to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
●Make sure the seatback is securely locked by pressing it forward and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seatback.
● Make sure that the seat belt is passing through its guide.

1323-3. Adjusting the seats
CAMRY_HV_U (OM33A87U)
Vertical adjustmentUp
Pull the head restraint up.
Down
Push the head restraint down while
pressing the lock release button.
■Removing the head restraints (front seats)
■ Installing the head restraints (front seats)
Head restraints
Head restraints are provided for all seats.
Front seats
Lock release button
1
2
Pull the head restraint up while pressing
the lock release button.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Lock
release
button
Lock release
button

555Alphabetical index
CAMRY_HV_U (OM33A87U)
Entune Audio system*............ 248
Audio input ............................ 253
AUX port/USB port................ 253
Bluetooth
® audio................... 295
CD player .............................. 269
iPod....................................... 274
MP3/WMA disc ..................... 269
Optimal use........................... 266
Portable music player ........... 282
Radio .................................... 267
Steering wheel audio switch ................................. 252
USB memory ........................ 278
EPS
(Electric Power Steering)...... 219Function ................................ 219
Warning light ......................... 445
EV drive mode.......................... 166
Event data recorder (EDR) ........ 11 Flat tire ..................................... 471
Floor mats .................................. 26
Fluid
Brake .................................... 504
Hybrid transmission .............. 504
Washer ................................. 401
Front interior lights ................. 341 Wattage ................................ 506
Front passenger occupant classification system .............. 49
Front personal lights............... 341
Wattage ................................ 506
Front seats ............................... 128 Adjustment............................ 128
Cleaning ............................... 379
Correct driving posture ........... 28
Head restraints ..................... 132
Seat heaters ......................... 339
Front side marker lights ......... 172 Light switch ........................... 172
Replacing light bulbs ............ 430
Wattage ................................ 506
Front turn signal lights ........... 170
Replacing light bulbs ............ 431
Turn signal lever ................... 170
Wattage ................................ 506
Fuel ........................................... 182 Capacity................................ 500
Fuel gauge.............................. 88
Information............................ 507
Refueling .............................. 182
Type.............................. 182, 500
Warning light......................... 446
Warning message................. 461
Fuel consumption ................... 101
Fuel filler door ......................... 182 Refueling .............................. 182
Fuses ........................................ 425
F
*: For vehicles with a navigation system or Entune Audio Plus, refer to
the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”.

560Alphabetical index
CAMRY_HV_U (OM33A87U)
Safety Connect ........................ 365
Seat belt reminder light........... 446
Seat belts.................................... 30Adjusting the seat belt ............ 31
Automatic Locking Retractor (ALR) .................... 32
Child restraint system installation ............................ 62
Cleaning and maintaining the seat belt ........................ 380
Emergency Locking Retractor
(ELR) .................................... 32
How to wear your seat belt ..... 30
How your child should wear the seat belt .......................... 32
Pregnant women, proper seat belt use ......................... 33
Reminder light and buzzer .... 446
Seat belt extender................... 32
Seat belt pretensioners ........... 31
SRS warning light ................. 445
Seat heaters ............................. 339
Seating capacity ...................... 158
Seats ......................................... 128 Adjustment ............................ 128
Adjustment precautions ........ 129
Child seats/child restraint system installation ................ 60
Cleaning................................ 379
Head restraints ..................... 132
Properly sitting in the seat ...... 28
Seat heaters ......................... 339 Sensor
Automatic headlight
system ................................ 173
Automatic High Beam system ................................ 179
Humidity sensor .................... 338
Inside rear view mirror .......... 137
LDA (Lane Departure Alert)................................... 202
Radar sensor ........ 197, 225, 229
Service plug ............................... 73
Shift lever ................................. 168 Hybrid transmission .............. 168
If the shift lever cannot be shifted from P ................ 484
Shift lock system ..................... 484
Side airbags ............................... 37
Side marker lights ................... 172 Light switch ........................... 172
Replacing light bulbs .... 430, 432
Wattage ................................ 506
Side mirrors ............................. 138 Adjusting and folding ............ 138
BSM (Blind Spot Monitor) ..... 231
Smart key system .................... 121 Antenna location ................... 121
Entry functions .............. 110, 117
Starting the hybrid system .... 161
Warning message................. 465
Snow tires ................................ 244
Spare tire .................................. 471 Inflation pressure .................. 505
Storage location.................... 471
S
