2015 TOYOTA CAMRY HYBRID air filter

5
1
9 8 6 5
4
3
2
CAMRY_HV_U (OM33A87U)
10
7
6-1. Using the air conditioning system
and defogger
Automatic air conditioning system............................. 332
Seat heaters ...................... 339
6-2. Using the interior lights Interior lights list ................ 340
• Interior lights ................. 341
• Personal lights .............. 341
6-3. Using the storage features
List of storage features...... 343
• Glove box...................... 344
• Console box .................. 344
• Coin holder ................... 345
• Bottle holders ................ 345
• Cup holders .................. 346
• Auxiliary boxes.............. 347
• Open tray ...................... 352
Trunk features ................... 353
6-4. Other interior features Other interior features ....... 354
• Sun visors ..................... 354
• Vanity mirrors................ 354
• Clock ............................. 355
• Ashtray.......................... 356
• Power outlets ................ 357
• Armrest ......................... 358
• Assist grips ................... 358
• Coat hooks.................... 359
Garage door opener .......... 360
Safety Connect.................. 365
Compass ........................... 370 7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 376
Cleaning and protecting the vehicle interior ........... 379
7-2. Maintenance Maintenance requirements ................... 382
General maintenance ........ 385
Emission inspection and maintenance (I/M)
programs ......................... 389
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ...................... 390
Hood .................................. 392
Positioning a floor jack....... 393
Engine compartment ......... 394
12-volt battery .................... 402
Tires................................... 406
Tire inflation pressure ........ 416
Wheels............................... 419
Air conditioning filter .......... 421
Electronic key battery ........ 423
Checking and replacing fuses ................................ 425
Light bulbs ......................... 428
6Interior features7Maintenance and care

3376-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33A87U)■
When the outside temperature is low
The dehumidification function may not operate even when is pressed.
■ Ventilation and air conditioning odors
●To let fresh air in, set the air condi tioning system to the outside air mode.
● During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time immediately after the air conditioni ng system is started in automatic
mode.
■ Air conditioning filter
P. 421
■ Customization
The air conditioning control of Eco drive mode can be changed to the same
setting as that used in normal drive mode.
(Customizable features P. 530)
WARNING
■To prevent the windshield from fogging up
●Do not use during cool air operat ion in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■ To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
●Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

375
7Maintenance and care
CAMRY_HV_U (OM33A87U)7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 376
Cleaning and protecting the vehicle interior ........... 379
7-2. Maintenance Maintenance requirements ................... 382
General maintenance........ 385
Emission inspection and maintenance (I/M)
programs ......................... 389
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 390
Hood ................................. 392
Positioning a floor jack ...... 393
Engine compartment ......... 394
12-volt battery ................... 402
Tires .................................. 406
Tire inflation pressure ....... 416
Wheels .............................. 419
Air conditioning filter.......... 421
Electronic key battery........ 423
Checking and replacing fuses ............................... 425
Light bulbs......................... 428

3917-3. Do-it-yourself maintenance
7
Maintenance and care
CAMRY_HV_U (OM33A87U)
WARNING
The engine compartment contains many mechanisms and fluids that may
move suddenly, become hot, or become electrically energized. To avoid death
or serious injury, observe the following precautions.
■When working on the engine compartment
●Make sure that the “READY” indicator is off.
● Keep hands, clothing and tools away from the moving fans and engine
drive belt.
● Be careful not to touch the engine, power control unit, radiator, exhaust
manifold, etc. right after driving as they may be hot. Oil and other fluids
may also be hot.
● Do not leave anything that may burn easily, such as paper and rags, in the
engine compartment.
● Do not smoke, cause sparks or expose an open flame to fuel. Fuel fumes
are flammable.
■ When working near the electric co oling fans or radiator grille
Be sure the power switch is off.
With the power switch in ON mode, the electric cooling fans may automati-
cally start to run if the air conditioni ng is on and/or the coolant temperature
is high. ( P. 399)
■ Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc.
from getting in your eyes.
NOTICE
■ If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear
due to dirt in the air.

4217-3. Do-it-yourself maintenance
7
Maintenance and care
CAMRY_HV_U (OM33A87U)
Turn the power switch off.
Open the glove box and
remove the glove box cover
inside the glove box.
Remove the filter cover.
Remove the air conditioning fil-
ter and replace it with a new
one.
The “UP” marks shown on the fil-
ter should be pointing up.
Air conditioning filter
The air conditioning filter must be changed regularly to maintain
air conditioning efficiency.
Removal method
1
2
3
4

4227-3. Do-it-yourself maintenance
CAMRY_HV_U (OM33A87U)
■Checking interval
Inspect and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement
may be required. (For scheduled maintenanc e information, please refer to the
“Schedule maintenance guide” or “Owner’s Manual Supplement”.)
■ If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
NOTICE
■When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the
system.

4638-2. Steps to take in an emergency
8
When trouble arises
CAMRY_HV_U (OM33A87U)
Other displayed messages
Warning messageDetails/Actions
Indicates that maintenance of the hybrid system
(traction battery) cooling component is required The filter may be clogged, the air vent may be
blocked or the duct may be disconnected.
 Have maintenance performed on the hybrid
system (traction battery) cooling compo-
nent at Toyota dealer.
Indicates that the EV drive mode is not avail-
able
*2
The reason the EV drive mode is not available
(the vehicle is idling, hybrid battery [traction
battery] charge is low, speed is higher than the
EV drive mode operating speed range, acceler-
ator pedal is depressed too much) may be dis-
played.
A buzzer also sounds.
 Use the EV drive mode when it becomes
available.

551
CAMRY_HV_U (OM33A87U)
Alphabetical index
Alphabetical index
A/C ............................................ 332Air conditioning filter ............. 421
ABS (Anti-lock Brake System)...... 218Function ................................ 218
Warning light ......................... 445
Air conditioning filter .............. 421
Air conditioning system.................................... 332Air conditioning filter ............. 421
Airbags ....................................... 36
Airbag operating conditions .... 45
Airbag precautions for your child .............................. 39
Airbag warning light .............. 445
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............................. 45
Curtain shield airbag precautions........................... 42
Front passenger occupant classification system............. 49
General airbag precautions .... 39
Locations of airbags................ 36
Modification and
disposal of airbags ............... 44
Side airbag operating conditions ............................. 45
Side airbag precautions .......... 39
Side and curtain shield airbags operating conditions ............. 45
Side and curtain shield airbags precautions........................... 39
SRS airbags............................ 36
Alarm .......................................... 80
Anchor brackets ........................ 60 Antennas
(smart key system) ............... 121
Anti-lock Brake System (ABS) ...................................... 218Function ................................ 218
Warning light......................... 445
Armrest..................................... 358
Assist grips .............................. 358
Audio input
*............................ 253
Audio system
*......................... 250
Antenna ................................ 323
Audio input............................ 253
AUX port/USB port ............... 253
Bluetooth
® audio .................. 296
CD player.............................. 269
iPod ...................................... 274
MP3/WMA disc ..................... 269
Optimal use .......................... 266
Portable music player ........... 282
Radio .................................... 267
Steering wheel audio switch ................................. 252
USB memory ........................ 278
Automatic High Beam ............. 175
Automatic light control system.................................... 172
AUX port
*................................. 253
Auxiliary boxes ........................ 347
A
*: For vehicles with a navigation system or Entune Audio Plus, refer to
the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”.
