2015 TOYOTA 4RUNNER maintenance

3986-3. Do-it-yourself maintenance
4RUNNER (U)_(OM35B18U)

4197-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)_(OM35B18U)
CAUTION
■If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause a loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●If the tire pressure warning light comes on even after tire inflation pres-
sure adjustment, it is probable that you have a flat tire. Check the tires.
If a tire is flat, change it with th e spare tire and have the flat tire
repaired by the nearest Toyota dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly
when cold and inflated to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or tire inflation pressure
label (tire and load information label). (If your vehicle has tires of a dif-
ferent size than the size indicated on the vehicle placard or tire inflation
pressure label [tire and load information label], you should determine
the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire
pressure monitoring system (TPMS-ti re pressure warning system) that
illuminates a low tire pre ssure telltale (tire pressure warning light) when
one or more of your tires is significantly under-inflated. Accordingly,
when the low tire pressure telltale (tire pressure warning light) illumi-
nates, you should stop and check your tires as soon as possible, and
inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel effi ciency and tire tread life, and may
affect the vehicle’s hand ling and stopping ability.
Please note that the TPMS (tire pres sure warning system) is not a sub-
stitute for proper ti re maintenance, and it is the driver’s responsibility to
maintain correct tire pressure, even if under-inflation has not reached
the level to trigger illumina tion of the TPMS low tire pressure telltale (tire
pressure warning light).

4237-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)_(OM35B18U)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s ManualSupplement” for the maintenance interval applicable to your vehicle.
Indicates that an intuitive parking assist-sensor is
dirty or covered with ice The site of the malfunction flashes and stays
on.
A buzzer will sound for several seconds and
this warning message will disappear after sev-
eral seconds.
If the engine switch is turned to a mode other
than IGNITION ON mode and then back to
IGNITION ON mode, the buzzer will sound and
this message will be displayed again.
 Clean the sensor.
(U.S.A. only)
Indicates that all maintenance according to the
driven distance on the maintenance schedule
*
should be performed soon.
Comes on approximately 4500 miles (7200 km)
after the maintenance data has been reset.
If necessary, perform maintenance.
(U.S.A. only)
Indicates that all maintenance is required to cor-
respond to the driven distance on the mainte-
nance schedule
*.
Comes on approximately 5000 miles (8000 km)
after the maintenance data has been reset.
(The indicator will not work properly unless the
maintenance data has been reset.)
 Perform the necessary maintenance.
Please reset the maintenance data after the
maintenance is performed ( P. 340)
Warning messageDetails/Actions

455
Vehicle specifications8
4RUNNER (U)_(OM35B18U)8-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 456
Fuel information ................ 466
Tire information ................. 469
8-2. Customization Customizable features ...... 481
8-3. Items to initialize Items to initialize ............... 488

456
4RUNNER (U)_(OM35B18U)
8-1. Specifications
*1: Unladen vehicle
*2: Without rear differential lock system
*3: With rear differential lock system (TRAIL)
*4: With 5 occupants
*5: With 7 occupants
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
Overall length189.8 in. (4820 mm)
Overall width75.8 in. (1925 mm)
Overall height *170.1 in. (1780 mm)
Wheelbase109.8 in. (2790 mm)
TreadFront63.2 in. (1605 mm)
Rear63.2 in. (1605 mm)
Vehicle capacity weight
(Occupants + luggage)1165 lb. (525 kg) *2
835 lb. (375 kg) *3
Trailer weight rating
(trailer weight + cargo weight)5000 lb. (2270 kg)
Luggage compartment load
capacity970 lb. (445 kg) *4
670 lb. (309 kg) *5

488
4RUNNER (U)_(OM35B18U)
8-3. Items to initialize
Items to initialize
The following item must be initialized for normal system opera-
tion after such cases as the battery being reconnected, or main-
tenance being performed on the vehicle:
ItemWhen to initializeReference
Maintenance dataAfter the maintenance is per-
formedP. 340

512Alphabetical index
4RUNNER (U)_(OM35B18U)
Child safety ................................ 52Airbag precautions .................. 37
Back door precautions .......... 116
Battery precautions ....... 360, 449
Child restraint system ............. 53
How your child should
wear the seat belt ................. 31
Installing child restraints ......... 57
Moon roof precautions .......... 155
Power window lock switch .... 145
Power window precautions ... 147
Rear door child-protectors ...... 99
Removed electronic key battery precautions ...... 379
Seat belt extender precautions ........................... 34
Seat belt precautions .............. 56
Seat heater precautions........ 291
Child-protectors......................... 99
Cleaning ........................... 334, 336 Aluminum wheels.................. 334
Exterior ................................. 334
Interior................................... 336
Seat belts .............................. 337
Clock ......................................... 309
Compass .................................... 85
Condenser ................................ 355
Console box ............................. 297
Cooling system Engine overheating ............... 450
Crawl Control ........................... 249
Cruise control .......................... 221
Cup holders.............................. 298
Curtain shield airbags ............... 35
Customizable features ............ 481 Daytime running light
system.................................... 208
Defogger Front windshield ................... 286
Outside rear view
mirrors ........................ 280, 286
Rear window ................. 280, 286
Dimension ................................ 456
Dinghy towing.......................... 190
Display Multi-information display ......... 81
Trip information....................... 83
Warning message................. 421
Do-it-yourself maintenance .... 345
Door courtesy lights Wattage ................................ 465
Doors Automatic door locking and unlocking system......... 100
Back door ............................. 114
Door windows ....................... 145
Door lock ........................ 98, 115
Open door warning buzzer ... 105
Open door warning light ....... 414
Outside rear view mirrors ..... 143
Rear door child-protector ........ 99
Side doors .............................. 96
Downhill assist control system.................................... 246
Driver’s seat position memory .................................. 132
Driving ...................................... 158
Break-in tips.......................... 159
Correct driving posture ........... 28
Driving assist systems .......... 259
Off-road precautions ............. 272
Procedures ........................... 158
Winter drive tips .................... 268D

515Alphabetical index
4RUNNER (U)_(OM35B18U)
Head restraints ........................ 136
Headlights ................................ 204Light switch ........................... 204
Replacing light bulbs ................... 385, 387, 397
Wattage ................................ 465
Heaters
Air conditioning system ....... ................. 278, 284
Outside rear view
mirrors ....................... 280, 286
Seat heaters ......................... 291
Hill-start assist control............ 260
Horn .......................................... 139
Hood ......................................... 348
Hooks
Cargo hooks ......................... 303
Cargo net hooks ................... 304
Grocery bag hooks ............... 306
Retaining hooks (floor mat)..... 26 I/M test ...................................... 344
Identification
Engine .................................. 457
Vehicle .................................. 457
Ignition switch (engine switch) .............. 191, 194
Illuminated entry system ........ 295
Immobilizer system ................... 70
Indicators ................................... 79
Initialization
Maintenance ......................... 340
Moon roof ............................. 154
Power back window .............. 150
Power windows..................... 146
Inside rear view mirror ............ 141
Instrument panel light control ...................................... 82
Interior lights ........................... 293
Intuitive parking assist ........... 225
Jack Vehicle-equipped jack .......... 428
Jack handle .............................. 432
Jam protection function
Moon roof ............................. 153
Power back window .............. 150
Power windows..................... 146
