2015 RENAULT DUSTER engine

JauneNoir Noir texte
2.3
ENG_UD39254_4
Mise en route / Arrêt du moteur (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
LPG versions
The engine is always started using
petrol:
– activate the starter without accelera-
ting;
– release the key as soon as the
engine starts.
The system will automatically deter-
mine the switchover from petrol to LPG.
When operating on LPG, the fuel gauge
may indicate a drop in the petrol level
and the on-board computer will not op-
erate.
Under certain winter conditions the
system may delay or disable operation
with LPG.
After stopping the engine, if the envi-
ronmental conditions are once again
suitable, the system may once again
permit LPG mode.
Starting the engineIn very cold conditions (temperatures
below –20°C): so that it is easier to
start the engine, switch on the ignition
for several seconds before starting the
engine.
When starting the engine, if the outdoor
temperature is very low (below -10°C):
hold down the clutch pedal until the
engine starts.
Make sure the engine immobiliser is not
activated. Refer to the information on
the “Engine immobiliser” in Section 1.
Petrol injection
– Turn the key to the start position
without depressing the accelera-
tor.
– Release the key as soon as the
engine starts.
ÉDiesel injection
Turn the ignition key to ignition “On” po-
sition M, and hold this position until the
preheating warning light goes out.
Turn the key to starter position D with-
out depressing the accelerator
pedal.
Release the key as soon as the engine
starts.
STARTING, STOPPING THE ENGINE (1/4)
At temperatures close to 0°C or less, it
is recommended to use ECO mode to
maximise the use of LPG. Please refer
to the information on “Driving advice,
Eco-driving” in Section 2.
To enable the system to operate
smoothly and to prevent any wear to
the vehicle’s electric petrol pump, the
petrol tank should always be around
1/4 full.

JauneNoir Noir texte
2.4
ENG_UD39254_4
Mise en route / Arrêt du moteur (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
vehicles with an automatic
gearbox
Before starting, move the lever to posi-
tion P.
Refer to the information on the
“Automatic gearbox” in Section 2.
Stopping the engine
With the engine idling, turn the key
back to “Stop” position St.
Special note
Depending on the vehicle, accessories
(e.g. radio) stop working either when
the engine is switched off or when the
driver’s door is opened or when the
doors are locked.Driver’s responsibility
Never leave an animal,
child or adult who is not
self-sufficient alone on your
vehicle, even for a short time.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or locking the
doors, for example.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
Never switch off the ignition
before the vehicle has stopped
completely. Switching off the
engine disables the assistance
equipment: brakes, steering, etc.,
and additional seatbelt devices.
The steering is locked when the key
is removed.
RISK OF DEATH OR SERIOUS
INJURY.
STARTING, STOPPING THE ENGINE (2/4)
Do not park the vehicle or
run the engine in locations
where combustible sub-
stances or materials such
as grass or leaves can come into
contact with a hot exhaust system.

JauneNoir Noir texte
2.5
ENG_UD39254_4
Mise en route / Arrêt du moteur (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
STARTING, STOPPING THE ENGINE (3/4)
Remote engine start-up
If fitted to the vehicle, this function
allows you to switch on the engine re-
motely, press the locking button 1 then,
for approximately 2 seconds, press the
remote engine start-up button 2.
This function also lets you programme
the engine to start, in order to heat or
ventilate the passenger compartment
up to 24 hours before using the vehicle.
1
2
The remote engine start-up operates if:
– the lever is in neutral for vehicles
with a manual or sequential gearbox;
– the lever is in position P for vehicles
with an automatic gearbox;
– the ignition is off and no key is in-
serted into the ignition switch;
– the bonnet is closed;
– all of the opening elements (doors
and luggage compartment) are
closed and locked when you leave
the vehicle.
3
The configuration and the programming
is done using the multimedia display 3:
refer to the multimedia instructions for
your vehicle.

JauneNoir Noir texte
2.6
ENG_UD39254_4
Mise en route / Arrêt du moteur (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
STARTING, STOPPING THE ENGINE (4/4)
Do not use the engine remote start-up function or its programming when:
– the vehicle is in a garage or in a confined space.
Risk of poisoning or suffocation by exhaust gas emissions.
– the vehicle is covered with a protective cover.
Fire hazard.
– the bonnet is open or before it opens.
Risk of burns or serious injury.
Depending on the country, the use of the remote starting function or its programming can be prohibited by the legis-
lation and/or the regulations in force.
Before using this function, check the legislation and/or the regulations for the country in force.

JauneNoir Noir texte
2.7
ENG_UD39881_3
Fonction Stop and Start (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
For manual gearboxes:
– the gearbox is in neutral;
and
– the clutch pedal is released.
If the
 warning light flashes,
this means that the clutch pedal is
not sufficiently released;
and
– the vehicle speed is less than ap-
proximately 7 mph (3 km/h).
In all vehicles, the
 warning light
appears on the instrument panel to warn
you when the engine is on standby.
The vehicle equipment remain opera-
tional while the engine is stopped.
STOP AND START function (1/3)
This system enables a reduced fuel
consumption and lower greenhouse
gas emissions.
The system is activated automatically
when the vehicle is started.
While driving, the system stops the
engine (standby) when the vehicle is
at a standstill (traffic jam, traffic lights,
etc).
Conditions for engine
standby
The vehicle has set off from where it
was parked;
For automatic or sequential gear-
box:
– The gearbox is in position D or N;
and
– the brake pedal is depressed (suffi-
ciently hard);
and
– the accelerator pedal is not de-
pressed;
and
– the vehicle’s speed is zero for around
one second.
The engine remains on standby if posi-
tion P is selected, or if position N is se-
lected with the handbrake engaged and
the brake pedal released.
Engine on standby - braking
assistance is no longer op-
erational.
The ignition must be
switched off before leaving
the vehicle (please see sec-
tion on “Starting, stopping
the engine”).
Keep your vehicle station-
ary when the engine is
on standby (shown by the
warning light
 on the
instrument panel).
If you get out of the vehicle, a beep
notifies you that the engine is on
standby and has not been switched
off.
If the engine stalls while the system
is in operation, pressing the clutch
pedal right down will start it again.

JauneNoir Noir texte
2.8
ENG_UD39881_3
Fonction Stop and Start (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
STOP AND START function (2/3)
Conditions preventing the
standby of the engine
Certain conditions prevent the system
from using the engine standby function,
including when:
– reverse gear is engaged;
– the bonnet is not locked;
– the outdoor temperature is too low or
too high (less than around 0 °C or
higher than around 30 °C);
– the battery is not sufficiently char-
ged;
– if available, the vehicle is in “4WD
Lock” mode (please see the section
“Transmission: 4-wheel drive (4WD)”
in Section 2);
– for vehicles with an automatic or
sequential gearbox, the gradient is
steeper than approximately 12%;
– the engine temperature is too low;
– the anti-pollution system is required;
or
– ...
The warning light
 lights up on
the instrument panel to alert you that
engine standby is not available.
To fill up with fuel, the engine must
be stopped (and not on standby):
always stop the engine (please see
“Starting, stopping the engine”).
Deactivate the Stop and
Start function for any opera-
tion performed in the engine
compartment.
Preventing the engine from
standing by
In certain situations, when negotiating
a junction for instance, it is possible to
keep the engine running so as to be
ready to move off quickly.
Automatic or sequential gearbox
Keep the vehicle stationary without
pressing too hard on the brake pedal.
Manual gearbox
Keep the clutch pedal pressed right
down.
Conditions for coming out of
engine standby
For automatic or sequential gear-
box:
– The brake pedal is released with the
gear lever in position D, or
– the brake pedal is released with
the gear lever in position N and the
handbrake off, or
– the brake pedal is pressed again,
with position N engaged and the
handbrake applied, or
– position R is engaged, or
– the accelerator pedal is pressed.
For manual gearboxes:
– The gearbox is in neutral and the
clutch pedal is slightly depressed, or
– the engine is in gear and the clutch
pedal is pressed right down.

JauneNoir Noir texte
2.9
ENG_UD39881_3
Fonction Stop and Start (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
Deactivating, activating the
function
Press switch 1 to deactivate the func-
tion. Warning light 2 in the switch lights
up.
Pressing again will reactivate the
system. Warning light 2 in switch 1
goes out.
STOP AND START function (3/3)
The system is automatically reacti-
vated each time the vehicle is started
(see “Starting, stopping the engine” in
Section 2).
Operating faults
When the warning light 2 built in to
switch 1 is lit, the system is deacti-
vated.
Please consult an authorised dealer.
Before getting out of the
vehicle, you must switch
off the ignition (please see
section on “Starting, stop-
ping the engine”).
12
Special feature of the automatic
engine re-start
Under certain conditions, the engine
can restart on its own in order to gua-
rantee your safety and comfort.
This can occur especially when:
– The outdoor temperature is too low
or too high (less than around 0°C or
higher than around 30°C);
– the battery is not sufficiently char-
ged;
– the vehicle speed is above 3 mph
(5 km/h) (downhill slope, etc.);
– repeated pressing on the brake
pedal or braking system require-
ment;
– ...
Special note: with the engine on
standby, press switch 1 to automa-
tically restart the engine.Special note: for some of these
conditions the automatic restarting
of the engine is inhibited if a front
door is open.

JauneNoir Noir texte
2.10
ENG_UD18237_9
Particularités des versions essence (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - H79 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
SPECIAL FEATURES OF PETROL VERSIONS
The following operating conditions:
– driving for long periods when the low
fuel level warning light is lit;
– using leaded petrol;
– using oil or fuel additives which are
not approved by the manufacturer.
Or operating faults such as:
– faulty ignition system, running out of
fuel or disconnected spark plugs re-
sulting in the engine misfiring or cut-
ting out when driving;
– loss of power,
may cause the catalytic converter to
overheat, reducing its efficiency which
may irreparably damage it and cause
heat damage to the vehicle.If you notice any of the above operating
faults, have the necessary repairs car-
ried out as soon as possible by an ap-
proved Dealer.
These faults may be avoided by reg-
ularly taking your vehicle to your ap-
proved dealer at the intervals speci-
fied in your Maintenance Service
Document.
Starting problems
To avoid damaging the catalytic con-
verter, do not keep trying to start the
engine (using the start button, or by
pushing or towing the vehicle) without
having identified and corrected the
starting fault.
If the fault cannot be identified, do not
continue to try and start the engine, but
contact an approved dealer.
Do not park the vehicle or
run the engine in locations
where combustible sub-
stances or materials such
as grass or leaves can come into
contact with a hot exhaust system.
