CavityMaxi Fuse Mini Fuse Description
F07 50 Amp Red (non
A/C)
60 Amp Blue (A/C) Engine Cooling Fan - 1st Speed
F08 40 Amp Orange Passenger Compartment Blower
F09 15 Amp Blue Rear Power Outlet
F10 15 Amp Blue Horn
F11 15 Amp Blue Fuel Pressure Regulator (MPROP)-DRV
(3.0 Diesel Engine) — If Equipped
F14 20 Amp Yellow Power Outlet
F15 7.5 Amp Brown USB Charger
F16 7.5 Amp Brown KL15 Shifter Transmission Module
(STM) (3.6), KL15 Starter Relay Coil (3.6
Gasoline Engine)
7
MAINTAINING YOUR VEHICLE 365

CavityMaxi Fuse Mini Fuse Description
F16 7.5 Amp Brown KL15 Manual Transmission Automated
(MTA), KL15 Shift Lever Unit, KL15 En-
gine Control Module (ECM), KL15
Starter Relay Coil (3.0 Diesel Engine)
F17 20 Amp Yellow Engine Control Module (ECM), Injectors
(3.6 Gasoline Engine)
F17 20 Amp Yellow Secondary Loads, Engine Control Mod-
ule (ECM) (3.0 Diesel Engine)
F18 7.5 Amp Brown KL30 Engine Control Module (ECM),
KL30 Main Relay Coil (3.6 Gasoline En-
gine)
F18 7.5 Amp Brown KL30 Manual Transmission Automated
(MTA), KL30 Engine Control Module
(ECM), KL30 Main Relay Coil (3.0 Diesel
Engine)
F19 7.5 Amp Brown A/C Compressor (If Equipped)
366 MAINTAINING YOUR VEHICLE

CavityMaxi Fuse Mini Fuse Description
F20 30 Amp Green Windshield Wiper
F21 15 Amp Blue Fuel Pump
F22 20 Amp Yellow Engine Control Module (ECM), Ignition
Coils (3.6 Gasoline Engine)
F22 20 Amp Yellow Engine Control Module (ECM), Primary
Loads (3.0 Diesel Engine)
F23 20 Amp Yellow Electronic Stability Control (ESC) Valves
F24 7.5 Amp Brown KL15 Vacuum pump relay coil (3.6
Gasoline Engine) — If Equipped
F30 15 Amp Blue Heated Mirrors
7
MAINTAINING YOUR VEHICLE 367

CavityMini Fuse Description
F61 20 Amp Yellow Vacuum Pump (3.6 Gasoline Engine) — If Equipped
F62 30 Amp Green Transmission Power RELE (3.6 Gasoline Engine) — If
Equipped
F64 7.5 Amp Brown Urea Pump (3.0 Diesel Engine) — If Equipped
F65 25 Amp White Urea NOX Sensor 1–2 — PM Sensor (3.0 Diesel En-
gine) — If Equipped
F66 5 Amp Beige Shifter Transmission Module (STM) (3.6 Gasoline En-
gine) — If Equipped
7
MAINTAINING YOUR VEHICLE 369

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate) 24 Gallons90 Liters
Engine Oil with Filter
3.6L Engine (SAE 5W-20, API Certified) 6 Quarts5.6 Liters
Cooling System *
3.6L Engine (MOPAR® Antifreeze/
Engine Coolant 10 Year/150,000 Mile
Formula or equivalent) 10.5 Quarts
10 Liters
382 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
ComponentFluid, Lubricant, or Genuine Part
Engine Coolant We recommend you use MOPAR® Antifreeze/Coolant 10 Year/150,000 Mile Formula
OAT (Organic Additive Technology) meeting the requirements of FCA Material
Standard MS.90032.
Engine Oil We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the require-
ments of FCA US Material Standard MS-6395 such as MOPAR®, Pennzoil®, and Shell
Helix®. Refer to your engine oil filler cap for correct SAE grade.
Engine Oil Filter We recommend you use MOPAR® Engine Oil Filters.
Spark Plugs We recommend you use MOPAR® Spark Plugs.
Fuel Selection 87 Octane.
7
MAINTAINING YOUR VEHICLE 383

CAUTION!
•Mixing of engine coolant (antifreeze) other than
specified Organic Additive Technology (OAT) en-
gine coolant (antifreeze), may result in engine
damage and may decrease corrosion protection.
Organic Additive Technology (OAT) engine cool-
ant is different and should not be mixed with
Hybrid Organic Additive Technology (HOAT) en-
gine coolant (antifreeze) or any “globally compat-
ible” coolant (antifreeze). If a non-OAT engine
coolant (antifreeze) is introduced into the cooling
system in an emergency, the cooling system will
need to be drained, flushed, and refilled with fresh
OAT coolant (conforming to MS.90032), by an au-
thorized dealer as soon as possible.
(Continued)
CAUTION! (Continued)
•Do not use water alone or alcohol-based engine
coolant (antifreeze) products. Do not use additional
rust inhibitors or antirust products, as they may not
be compatible with the radiator engine coolant and
may plug the radiator.
• This vehicle has not been designed for use with
propylene glycol-based engine coolant (antifreeze).
Use of propylene glycol-based engine coolant (an-
tifreeze) is not recommended.
384 MAINTAINING YOUR VEHICLE

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission – 3.6L Gasoline Engine Only Use Only ATF+4® Automatic Transmission Fluid. Fail- ure to use ATF+4® fluid may affect the function or
performance of your transmission. We recommend
MOPAR® ATF+4® Fluid.
Brake Master Cylinder We recommend you use MOPAR® DOT 4.
Power Steering Reservoir Use Pentosin CHF 11S power steering fluid meeting
FCA US Material Standard MS-11655.
7
